Samsung PM9A3 MZ-QL23T80 3.84TB U.2 PCIe 4.0 x4 Gen4 NVMe Read Intensive RI TCG Opal SED SSD MZQL23T8HCLS-00A07
- In Stock:4Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 3 Year ManufacturerWarrantyProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
| Capacity: | 3.84TB |
| Speed: | Solid State |
| Interface Types: | NVMe U.2 |
| Form Factor: | 2.5" x 7mm Fits All laptops |
| SSD Endurance DWPD: | Enterprise Read Intensive / RI |
| Electrical Interface: | PCIe 4.0 32GBps |
Description
Samsung PM9A3 MZ-QL23T80 MZQL23T8HCLS-00A07 3.84TB U.2 NVMe Gen4 PCIe 4.0 x4 Read Intensive TCG Opal SED SSD - Brand New
Samsung 3.84TB U.2 NVMe / Gen4 / Read Intensive / Enterprise SSD / PCIe 4.0 x4 / PM9A3 Series /MZQL23T8HCLS-00A07 / MZ-QL23T80 TCG Opal SED / Self Encryption Drive SSD / Solid State Drive - Brand New
High-Performance
PCI Express Gen 4 x4 interface delivers up to twice the read performance of PCIe Gen 3 SSDs, and dedicated hardware accelerators for three times the random write performance of the previous generation.
Enterprise Features
- Protects your data confidentiality and integrity with TCG encryption management
- Secure boot
- End-to-end data protection
- Power loss protection circuitry
Data Center Needs
Data center architects face challenging requirements when delivering reliable computing and storage resources at the lowest total cost. Data center servers require high levels of I/O performance to keep their CPUs fully utilized, and high system density, to minimize total cost. The storage systems that supply that I/O performance need to deliver consistent performance and latency to all tenant virtual machines and containers 24/7, 365 days a year.
Samsung provides data centers with solid-state drives (SSDs) that deliver exceptional performance in public cloud applications, such as infrastructure as a service (IaaS), content delivery networks (CDN), shared hosting, No SQL databases, and cloud data storage. Compared to SATA SSDs, these high-performing NVMe SSDs deliver more than ten times the read performance and lower latency, while still maintaining SATA cost and low-power consumption per IOP.
As a pioneer in NVMe SSDs, Samsung has been delivering the advantages of industry standard NVMe performance longer than anyone else. Samsung also has the added advantage of being a vertically integrated supplier of SSDs, enabling the highest levels of quality and support.
Compatibility
Compatible with systems accecpt 2.5in 7mm U.2 SSD
Specifications
| FEATURES | |
|---|---|
| DRIVE CONFIGURATION | |
| PERFORMANCE SPECIFICATIONS | |
| RELIABILITY SPECIFICATIONS | |
| ENVIRONMENTAL SPECIFICATIONS | |
| POWER REQUIREMENTS | |
| PHYSICAL DIMENSION | |
| PCI Express Gen4 | Single port x4 lanes, Compliant with PCI Express Base Specification Rev. 4.0 |
| NVM Express | Compliant with NVM Express Specification Rev. 1.4 |
| Power-Loss Data Protection | Enhanced |
| End-to-End Data Protection | Yes |
| SSD Enhanced S.M.A.R.T. | Supported |
| Encryption | Hardware based AES-XTS 256-bit Encryption Engine |
| Wear Leveling | Static and Dynamic |
| Compliance | RoHS / Halogen-Free, TCG Opal 2.0 |
| Form Factor | U.2 |
| Interface | PCI Express Gen4 x4 |
| Bytes per Sector | 512 (default), 4096 Bytes |
| Gen4 | |
| Sequential Read (128KB) | Up to 6800 MB/s |
| Sequential Write (128KB) | Up to 4000 MB/s |
| Random Read (4KB, Sustained) | Up to 1000K IOPS |
| Random Write (4KB, Sustained) | Up to 200K IOPS |
| Latency (Random Read/Write, typical) | 80/35 μs |
| Latency (Sequential Read/Write, typical) | 20/20 μs |
| Drive Ready Time (typical) | 8s |
| Uncorrectable Bit Error Rate | 1 sector per 1017 bits read |
| MTBF | 2,000,000 hours |
| Component Design Life | 5 years |
| Endurance (3840/1920/960GB) | 1 DWPD |
| TBW (@4KB Random Write) | 3840GB: 7008 TB 1920GB: 3504 TB 960GB: 1752 TB |
| Data Retention | 3 months |
| Temperature, Case (Tc) | Operating: 0 ~ 70°C Non-operating: -40 ~ 85°C |
| Humidity (non-condensing) | 5 ~ 95% |
| Linear Shock (0.5ms, 1/2 sine wave) | Non-operating: 1,500 G |
| Vibration (10 ~ 2,000 Hz, Sinusoidal) | Non-operating: 20 G |
| Supply Voltage / Tolerance | 12V ±5% |
| Active (max. RMS) | 1.35W |
| Idle (typical) | Up to 4W |
| Width | 69.85 ± 0.25 mm |
| Length | 100.20 ± 025 mm |
| Thickness | 7.0 +0.00/-0.50mmT |
| Weight | Up to 90 g |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: MZQL23T8HCLS-00A07 MZQL23T8HCLS
Weight: 1 lb
Warranty: 3 Year Manufacturer
Condition
The product is brand new.
Warranty
3 Year Manufacturer Warranty
