Samsung MZ-V7S2T0B/AM 2TB SED PCIe Solid State Drive


DiscTech Item #: SAM-MZ-V7S2T0BAM-BN-5Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Enterprise Grade

Capacity: 2TB

Speed: Solid State Memory

Interface Types: NVMe M.2

Form Factor: M.2 x 80mm

Encryption/SED Supported

Sector Size: 512 / 512e

Sustained Throughput: 3500/3000

Electrical Interface: PCIe - v3.0 - 16GBps

On-Board Cache: 2GB


SSD Endurance DWPD: Consumer / Value

Samsung 970 EVO Plus MZ-V7S2T0B/AM 2TB M.2 MLC SED PCIe NVMe Solid State Drive - Brand New

Samsung 970 EVO Plus MZ-V7S2T0B/AM 2TB / 2000GB M.2 2280 Consumer / Value Endurance 0.3-DWPD / Drive Writes Per Day V-NAND MLC / Multi-Level Cell SED / Self-Encrypting PCIe / PCI Express 3.0 NVMe / NVM Express 1.3 SSD / Solid State Drive - Brand New

Always Evolving SSD
The ultimate in performance, upgraded. Faster than the 970 EVO, the 970 EVO Plus is powered by the latest V-NAND technology and firmware optimization. It maximizes the potential of NVMe bandwidth for unbeatable computing. Comes in capacities of up to 1TB, with reliability of up to 600 TBW.

Level Up Performance
The 970 EVO Plus reaches sequential read/write speeds up to 3,500/3,300 MB/s, up to 53% faster than the 970 EVO. Powered by the latest V-NAND technology—which brings greater NAND performance and higher power efficiency—along with optimized firmware, a proven Phoenix controller, and Intelligent TurboWrite boost speed.

Design Flexibility
The next advancement in NVMe SSDs. The 970 EVO Plus fits up to 1TB onto the compact M.2 (2280) form factor, greatly expanding storage capacity and saving space for other components. Samsung's innovative technology empowers you with the capacity to do more and accomplish more.

Exceptional Endurance
The new standard in sustainable perfromance. Get up to 600 TBW for lasting performance. The 970 EVO Plus provides exceptional endurance powered by the latest V-NAND technology and Samsung's reputation for quality.

Unparalleled Reliability
Achieve a new level of drive confidence. Samsung's advanced nickel-coated controller and heat spreader on the 970 EVO Plus enable superior heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimize performance drops.

Samsung Magician
Advanced drive management made simple. The Samsung Magician software will help you keep an eye on your drive. A suite of user-friendly tools helps keep your drive up to date, monitor drive health and speed, and even boost performance.


This Drive is designed to work in any Personal Computer or Consumer Application that uses M.2 x 80mm PCIe drives.

970 EVO Plus
Model#MZ-V7S2T0BAM / MZ-V7S2T0B/AM
Product TypeSolid State Drive (SSD)
Series970 EVO Plus
Usage ApplicationClient PCs
InterfacePCIe Gen 3.0 x 4, NVMe 1.3
Capacity2TB / 2,000GB (1GB = 1 Billion byte by IDEMA)
  • Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
  • Sequential Read SpeedUp to 3,500 MB/s
  • Performance may vary based on system hardware & configuration
  • Sequential Write SpeedUp to 3,300 MB/s
  • Performance may vary based on system hardware & configuration
  • Random Read SpeedRandom Read (4KB, QD32):
  • Up to 620,000 IOPS

  • Random Read (4KB, QD1):
  • Up to 19,000 IOPS

  • Performance may vary based on system hardware & configuration
    Random Write SpeedRandom Write (4KB, QD32):
  • Up to 560,000 IOPS

  • Random Write (4KB, QD1):
  • Up to 62,000 IOPS

  • Performance may vary based on system hardware & configuration
    ControllerSamsung Phoenix Controller
    NAND FlashSamsung V-NAND 3-bit MLC
    Cache MemorySamsung 1GB Low Power DDR4 SDRAM
    Trim SupportSupported
    AES EncryptionAES 254-bit Encryption (Class0) TCG/Opal IEEE1667 (Encrypted Drive)
    S.M.A.R.T SupportSupported
    GC (Garbage Collection)Auto Garbage Collection Algorothm
    WWN SupportNot Supported
    Device Sleep Mode SupportYes
    Temperature ProofYes
    Gaming SSDsYes
    Average Power Consumption (System Level)Average
  • 6 W
  • Maximum
  • 9 W (Burst Mode)
  • Actual Power consumption may vary depending on system hardware & configuration
    Power consumption (idle)Max
  • 30 mW
  • Actual Power consumption may vary depending on system hardware & configuration
    Voltage 3.3 V ± 5 % Allowable voltage
    Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
    Operating Temperature 0 - 70 ℃ Operating Temperature
    Shock 1,500 G & 0.5 ms (Half sine)
    Form FactorM.2 (2280)
    Dimensions (W x H x D) 80.15 x 22.15 x 2.38 (mm)
    Weight Max 8.0 g Weight
    SoftwareMagician Software for SSD management

    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: MZ-V7S2T0BAM

    Weight: 1.5 lb

    Warranty: 5 Year Manufacturer

    Brand New

    Condition Levels Explained

    The product is brand new.

    5 Year Manufacturer Warranty

    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.
