Samsung PM1633a Series MZILS15THMLS / MZ-ILS15T0 15.36TB 12Gbps 2.5" SFF Enterprise Read-Intensive 1-DWPD TLC SAS SSD

SAMSUNG Part #/MPN: MZILS15THMLS

DiscTech Item #: SAM-MZILS15THMLS-BN-OE


$4,499.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$4,499.00

Enterprise Grade

Capacity: 15.36TB

Speed: Solid State Memory

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps

SSD Type: TLC

SSD Endurance DWPD: Enterprise Read Intensive

Samsung PM1633a Series MZILS15THMLS / MZ-ILS15T0 15.36TB 12Gbps 2.5" SFF Enterprise Read-Intensive 1-DWPD TLC SAS SSD - Brand New OEM

Alt MPN: MZILS15THMLS / MZ-ILS15T0

PM1633a 2.5” SAS SSD Solid State Drive:
Samsung PM1633a solid-state drive offers up to 1,000 times the performance of 15K RPM hard disk drives at a comparable cost per gigabyte.

Samsung PM1633a SAS SSD delivers:

  • Consistently High Performance – Up to 1,000 times the performance of the fastest 15K RPM hard drives, the Samsung PM1633a SAS SSD provides enterprise IT administrators performance to spare. An optimized Samsung native SAS 3.0 controller supplies the drive with 12 Gb/s of bandwidth and provides enterprises the performance margin to prevent costly and disruptive application support tickets.

  • Exceptional Value – The same low cost per gigabyte as slower SAS HDDs. By utilizing Samsung state-of-the-art 3D V-NAND flash memory, cost effective TLC flash memory can address high-end enterprise applications, outperforming older planar MLC flash memory, and providing solid state performance and reliability at hard drive cost. With no moving parts, the PM1633a SAS SSD delivers over 10 times the reliability of spinning disks, reducing the administrative cost overhead associated with drive replacement.

  • Breakthrough Storage Density – Capacities up to 16TB in a 2.5” small form factor (SFF) drive. With 60% higher capacity per drive, and a smaller 2.5” form factor, up to 384TB can be stored in a 2U server. This breakthrough in storage density more than triples the density available with high capacity HDDs, using an industry standard form factor, and without sacrificing enterprise reliability, availability, and serviceability (RAS).


  • Compatibility:

    This drive is compatible with any server that accepts 2.5"x15mm (SFF) SAS drives.

    Samsung PM1633a SSD Technical Specifications
    Form Factor2.5”
    Capacity15.36TB
    Host Interface SAS 3.0 @ 12 Gb/s
    MTBF2,000,000 hours
    Power Consumption (Active/Idle)11 W / 4.5 W
    Endurance1 DWPD for 5 Years
    UBER1 in 10^17
    Random Read Up to 195,000 IOPS
    Random WriteUp to 31,000 IOPS
    Sequential ReadUp to 1,200 MB/s
    Sequential WriteUp to 900 MB/s
    Physical Dimensions70 x 100 x 15 mm
    Weight140 grams

    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: MZILS15THMLS-00003

    Weight: 1 lb

    Warranty: 1 Year DiscTech

    Brand New

    Condition Levels Explained

    The product is brand new.

    1 Year DiscTech Warranty

    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty
