SanDisk SDLLOC6R-020T 2000GB SAS SSD


DiscTech Item #: SAN-SDLLOC6R-020T-BN-5Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Enterprise Grade

Capacity: 2TB

Speed: Solid State Memory

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx9mm Fits Most laptops

Sector Size: 512 / 512e

Sustained Throughput: Up to 500

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps


SSD Endurance DWPD: Enterprise Read Intensive

SanDisk Optimus Eco SDLLOC6R-020T 2TB 2.5" 6Gbps eMLC Read-Intensive 3-DWPD SAS SSD - Brand New

Alt Part Number:  SDLLOC6R-020T-5CA1

SanDisk Optimus Eco SDLLOC6R-020T 2000GB 2.5" 6.0 Gbps Enterprise Multi-Level Cell Read-Intensive 3-DWPD Serial Attached SCSI Solid State Disk Drive - Brand New


Optimus Eco SAS SSDs

Cost-Effective, High-Performance SSDs for Fast Access to Large Datasets - Optimus Eco™ SAS solid state drives (SSDs) provide the capacity, speed, and reliability to ensure a cost-effective high-performance storage solution for mixed-use and read-intensive application workloads. They support end-user access to data-streams and to large data sets that have been written to disk with each Optimus Eco SSD providing 400GB to 1.6TB of capacity for mixed-use workloads such as on-line transaction processing (OLTP) databases, financial transactions, email/messaging, and virtual desk. The Optimus Eco at the 2TB capacity is ideal for read-intensive application workloads, such as indexing, media-streaming, and video on demand (VOD).

On-line Transaction Processing (OLTP) Databases - Databases supporting online transaction processing (OLTP) workloads, such as those used inside “integrated systems,” must keep pace with large amounts of data, as they are updated throughout the day, for 24/7 operations.

These databases must scale, and be reliable, preserving data as it is being written, and recording it for later analysis and use by the business. Accuracy and data integrity are key to these workloads and to their successful deployments across the organization. Often, they serve as the “databases of record” for many important enterprise applications.

Video on Demand (VOD) - Video on demand allows users to access video from virtually any device, including PCs, smartphones, and entertainment consoles that are connected to the Internet. Optimus Eco SSDs reduce the time it takes to stream video data, enhancing the end-user experience.

Optimus Eco/Read-Intensive Application Workloads

  • Web Servers
  • Media Streaming
  • Virtual Tape Libraries (VTL)
  • Video on Demand (VOD)
  • Web-based Applications
  • File Servers


This drive is compatible with any server that accepts 2.5"x9mm SAS drives.


Drive ModelSDLLOC6R-020T
Form Factor2.5" 9.5mm
Interface6Gb/s SAS
Interface PortsDual/Wide
Sequential Read/Write (MB/s)Up to 500/500 MB/s /1 GB/s Wide-Port
Random Read/Write (IOPS)Up to 90K/35K IOPS
19nm eMLC User Capacities2TB/2000GB
Sector Sizes512, 520, 528 byte
Data Reliability (BER)1 unrecoverable error in 100,000,000,000,000,000 bits read
MTBF2.5M hours
Data Fail RecoveryF.R.A.M.E. (Flexible Redundant Array of Memory Elements)
Power Fail RecoveryEverGuard Technology: Backup Power Circuitry
Data Path ProtectionDataGuard Technology, T10 DIF
Random Workload3 DWPD
Active (Typ)7W
Shock1000 g half-sine, 0.5 msec, 3 shocks along each axis, X, Y, Z, in each direction
Vibration2.17g rms, 7-800 Hz
Operating Temperature0°C to 70°C
Storage Temperature-40°C to 90°C
Humidity5% to 95%, non-condensing, relative humidity
Altitude5486.4 m [18,000 ft]
Length (mm/in)100.20/3.945
Width (mm/in)69.85/2.75

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: SDLLOC6R-020T-5CA1

Weight: 1.5 lb

Warranty: 5 Year Manufacturer
