Seagate 750GB IDE ATA/100 Hard Drive ST3750640A

Seagate Part #/MPN: ST3750640A

DiscTech Item #: SGT-ST3750640A-BN-5Y

$229.00
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Warranty:5 Year Manufacturer
    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

Back
$229.00

Capacity: 750GB

Speed: 7,200RPM

Interface Types: IDE ATA 3.5in

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 78

Average Seek Time: 11 / 12

Electrical Interface: EIDE Ultra ATA100 100MBps

On-Board Cache: 16MB

Seagate Barracuda 7200.10 750GB 7.2K IDE ATA/100 Hard Drive ST3750640A - Brand New

The Seagate Barracuda 7200.10 desktop hard drive features innovative perpendicular recording technology and is the first drive on the market to provide capacities up to 750 GB. Barracuda 7200.10 hard drives deliver superb performance, efficiency, speed and durability for all your application needs.


  • Perpendicular recording technology for maximum drive capacity and reliability

  • 16-MB cache buffer

  • Ultra-fast performance

  • Superb reliability

  • Whisper-quiet operation

  • Enhanced G-Force Protection against handling damage

Drive specification

ST3750640A

Formatted Gbytes (512 bytes/sector)*

750

Guaranteed sectors

1,465,149,168

Bytes per sector

512

Default sectors per track

63

Default read/write heads

16

Default cylinders

16,383

Recording density in BPI (bits/inch max)

926,000

Track density TPI (tracks/inch avg)

145,000

Areal density (Mbits/inch avg)

128,200

Spindle speed (RPM)

7,200

Internal data transfer rate (Mbytes/sec max)

1,030

Sustained transfer rate OD (Mbytes/sec)

78

I/O data transfer rate (Mbytes/sec max)

100

ATA data-transfer modes supported

PIO modes 0–4Multiword DMA modes 0–2Ultra DMA modes 0–5

Cache buffer

16 Mbytes

Height (max)

26.11 mm (1.028 inches)

Width (max)

101.85 mm (4.010 inches)

Length (max)

146.99 mm (5.787 inches)

Weight (max) grams

720

Average latency (msec)

4.16

Power-on to ready (typical)

15 sec

Standby to ready (typical)

15 sec

Track-to-track seek time (msec typical)

0.8 (read), 1.0 (write)

Average seek, read (msec typical)

11.0

Average seek, write (msec typical)

12.0

Startup current (typical) 12V (peak)

2.8 amps

Seek power (typical) watts

9.9

Operating power (typical) watts

9.2

Idle mode (typical) watts

7.2

Standby mode (typical) watts

1.2

Sleep mode

1.2

Voltage tolerance (including noise)

5V ± 5%
12V ± 10%

Ambient temperature

0° to 60°C (op.)
–40° to 70°C (nonop.)

Click here to view the manufacturer's item description/brochure
