Seagate Barracuda ST15150W 68pin SCSI Hard Disk DriveSeagate ST173404LW SCSI Hard Drive

Seagate Part #/MPN: ST15150W

DiscTech Item #: SGT-ST15150W-RF-OE

$149.00
  • Refurbished
    Condition Levels Explained

    These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

  • Warranty:1 Year DiscTech
    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty

  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

Back
$149.00

Enterprise Grade

Capacity: 4GB

Speed: 10,000RPM

Interface Types: SCSI 68pin HD68

Form Factor: 3.5inx1.6in (Rare)

Sector Size: 512 / 512e

Sustained Throughput: 26.7 to 40.2

Average Seek Time: 6.15 / 6.85

Electrical Interface: SCSI II Fast - 10MBps 16-bit

On-Board Cache: 4MB

Seagate Barracuda ST15150W 4.2GB 7200rpm FAST Wide SCSI-2 68pin 3.5" Half Height 1.6" Hard Drive - Refurbished Seagate Barracuda ST15150W 4.2GB 7200rpm FAST Wide SCSI-2 68pin 3.5" Half Height 1.6" Thick Hard Drive - Refurbished

General Description:

Barracuda drives are low cost, high performance, random access storagedevices designed to meet the needs of the original equipment manufacturer(OEM) marketplace.The Barracuda drive's interface supports multiple initiators, disconnect/reconnect, self-configuring host software, and automatic features that re-lieve the host from knowing the physical characteristics of the targets (logicalblock addressing is used).The head and disc assembly (HDA) is environmentally sealed at the factory.Air circulates within the HDA through a non-replaceable filter to maintain acontamination-free HDA environment

Standard features
Barracuda 4 drives have the following standard features:
• Integrated SCSI controller
• Single-ended or differential SCSI drivers and receivers
• Asynchronous and synchronous data transfer protocols
• Firmware downloadable using a SCSI interface
• Selectable sector size from 180 to 4,096 bytes per sector
• Programmable sector reallocation scheme
• Flawed sector reallocation at format time
• Programmable auto write and auto read reallocation
• Reallocation of defects on command (post format)
• 96-bit Reed-Solomon error correction code
• Sealed head and disc assembly (HDA)
• No preventive maintenance or adjustments required
• Dedicated head landing zone
• Automatic shipping lock
• Automatic thermal compensation
• Embedded Grey Code track address to eliminate seek errors
• Self-diagnostics performed at power-on
• 1:1 interleave
• Zone bit recording (ZBR)
• Vertical, horizontal, or top-down mounting
• Dynamic spindle brake
• Active termination for single-ended models
• 1,024 Kbyte data buffer (see Section 5.5)
4.1 Performance
• Programmable multi-segmentable cache buffer
• 7,200 RPM spindle; average latency = 4.17 msec
• Command queuing of up to 64 commands
• Background processing of queue
• Supports start and stop commands
• Provides synchronized spindle capability
• Low audible noise for office environment
• Low power consumption
4.1.1 Reliability
• 800,000 hour MTBF
• Adaptive seek velocity; improved seek performance
• LSI circuitry
• Balanced low-mass rotary voice-coil actuator



Alt Pt# 9A8003



Model # ST15150W - Internal drive characteristics • Drive capacity, Mbytes unformatted 5,062 • Read/write data heads, maximum (physical) 21 • Bytes per track, average bytes 64,160 • Bytes per surface, Mbytes unformatted 232.4 • Cylinders/tracks per surface, user accessible 3,711 • Tracks per inch 4,048 • Bits per inch 73,820 • Servo heads 1 • Internal data rate per physical head, Mbits/sec, 47.5 to 72.0 variable with zone •Disc rotation speed 7,200 ± 0.5% • Avg rotational latency, msec 4.17 • Integrated SCSI controller • Single-ended or differential SCSI drivers and receivers • Asynchronous and synchronous data transfer protocols • Selectable sector size from 180 to 4,096 bytes per sector • Programmable sector reallocation scheme • Flawed sector reallocation at format time • Programmable auto write and auto read reallocation • Reallocation of defects on command (post format) • 96-bit Reed-Solomon error correction code • Sealed head and disc assembly (HDA) • No preventive maintenance or adjustments required • Dedicated head landing zone • Automatic shipping lock • Automatic thermal compensation • Embedded Grey Code track address to eliminate seek errors • Self-diagnostics performed at power-on • 1:1 interleave • Zone bit recording (ZBR) • Vertical, horizontal, or top-down mounting • Dynamic spindle brake • Active termination for single-ended models • 1,024 Kbyte data buffer (see Section 5.5) 4.1 Performance • Programmable multi-segmentable cache buffer • 7,200 RPM spindle; average latency = 4.17 msec • Command queuing of up to 64 commands • Background processing of queue • Supports start and stop commands • Provides synchronized spindle capability • Low audible noise for office environment • Low power consumption 4.1.1 Reliability • 800,000 hour MTBF • Adaptive seek velocity; improved seek performance • LSI circuitry • Balanced low-mass rotary voice-coil actuator
Click here to view the manufacturer's item description/brochure

Alternate MPNs: 9A8003

Weight: 2.5 lb

Warranty: 1 Year DiscTech

Refurbished

Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
