Seagate Cheetah NS.2 ST3450802FC 450GB Fibre / Fiber Channel Hard Drive

Seagate Part #/MPN: ST3450802FC

DiscTech Item #: SGT-ST3450802FC-BN-OE


Enterprise Grade

Capacity: 450GB

Speed: 10,000RPM

Interface Types: Fibre Channel - External HSSDC DB9

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 150

Average Seek Time: 3.8/4.4

Electrical Interface: FC-AL - 4Gbps

On-Board Cache: 16MB

Seagate Cheetah NS.2 ST3450802FC 450GB 10K RPM 4Gbps Fibre / Fiber Channel Hard Drive - Brand New

Seagate Cheetah NS.2 ST3450802FC 450GB 10,000 RPM 4.0Gbps Fibre / Fiber Channel Hard Disk Drive - Brand New

Cheetah® NS.2

Lowest power, highest reliability for 3.5-inch Tier 1 solutions

Key Advantages

  • Lowest-power 3.5-inch Tier 1 drive (over 20 percent lower than any other 3.5-inch Tier 1 drive)
  • Highest-capacity Tier 1 drive (600 GB)
  • Highest reliability rating in the industry
  • Seagate PowerTrim™ technology dynamically reduces power usage.
  • Supports 6-Gb/s SAS 2.0 (600 GB and 450 GB) and 4-Gb/s FC

Best-Fit Applications

  • Email
  • Business processing
  • Transaction processing
  • Decision support
  • Storage area networks
  • Networked attached storage
  • Internet and e-commerce

Lowest Cost of Ownership

  • The Seagate Cheetah NS.2 drive is thelowest-power, highest-capacity and highest-reliability solution for 3.5-inch Tier 1 requirements.
  • Lower watts/GB ratio helps achieve reduced power and cooling costs while optimizing capacity requirements.

MTBF Improvement

  • Seagate continues to focus on reliability and data protection. MTBF is increased to 1.6 million hours.
  • Enhanced error correction code better maintains performance throughout the life of the drive and reduces the probability of lost data.
  • Seagate-exclusive Background Media Scan proactively scans the media for potential defects during drive idle time. It enables incipient errors to be corrected before data is lost.
  • Our Quick and Robust Download feature loads new firmware in less than 2 seconds, and built-in protection ensures no corruption in the event of a power failure during firmware switch.


This drive is compatible with any server that accepts 3.5" x 1" LFF Fibre / Fiber Channel hard drives.

Model NumberST3450802FC
External Transfer Rate (MB/s)400
Spindle Speed (RPM)10K
Average Latency (ms)3.00
Seek Time - Average Read/Write (ms)3.8/4.4
Seek Time - Track-to-Track Read/Write (ms)0.2/0.2
Transfer Rate - Maximum Internal (Mb/s)1840
Transfer Rate - Typical Sustained (MB/s)150
Cache, Multisegmented (MB)16
Configuration / Reliability
Nonrecoverable Read Errors per Bits Read1 sector per 10E16
Reliability Rating at Full 24x7 Operation (Annualized Failure Rate/MTBF hours)0.55%/1,600,000
Typical Operating (W)9.54
Idle (W)5.96
Temperature, Operating (°C)5 to 55
Temperature, Nonoperating (°C) –40 to 70
Shock, Operating (Read Only): 2 ms (Gs) 60
Shock, Nonoperating: 2 ms (Gs) 300
Acoustics, Idle (bels—sound power)3.3
Vibration, Operating (Gs)1.0
Vibration, Nonoperating (Gs)3.0
Height (in/mm)1.0/25.4
Width (in/mm) 4.0/101.6
Depth (in/mm)5.76/146.52
Weight (lb/kg)1.51/0.686

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 9FR004-080

Weight: 1.8 lb

Warranty: 1 Year DiscTech
