Seagate Cheetah ST3400755FC NS 400GB 10K 3.5" 4Gbps 40pin FC-AL Fibre / Fiber Channel Hard Drive
- In Stock:5Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
$219.00
| Capacity: | 400GB |
| Speed: | 10K RPM |
| Interface Types: | Fibre Channel - Internal - Arbitrated Loop ASA II |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | FC-AL - 4Gbps |
| RAM: | 16MB |
Description
Seagate Cheetah ST3400755FC NS 400GB 10K 3.5" 4Gbps 40pin FC-AL Fibre / Fiber Channel Hard Drive - Brand New OEM
Key Advantages
- 400 GB of transactional storage enables 33 percent more capacity in a single drive.
- Smaller platters and 10K spindle speed allow 33 percentsavings in operational power.
- 10x improvement in unrecoverable error rate at 1x10E16
- The industry’s highest reliability in the 3.5-inch form factor
Best-Fit Applications
- Network attached storage (NAS)
- High-capacity, performance and application servers
- Clustered systems
- Medical imaging, CAD, simulation
- Rich media content storage—audio, video, image
- Collaboration—email, messaging
- Infrastructure—Web, print, file
Compatibility
This drive is compatible with any of our Fibre / Fiber Channel adapters and also with any of our Fibre / Fiber hot-swap trays.
Specifications
| Specifications | |
| Model number | ST3400755FC |
| Model Name | Cheetah NS |
| Form Factor(width) | 3.5-inch |
| Form Factor(height) | 1-inch |
| Height | 25.4 mm |
| Width | 101.6 mm |
| Length | 146.05 mm |
| Weight | 0.771 kg |
| Formatted Capacity | 400 Gbytes |
| External (I/O) Transfer Rate (max) | 4.0 Gb/s |
| Average Seek Time, Read | 3.9 msec typical |
| Average Seek Time, Write | 4.2 msec typical |
| Track-to-Track Seek | 0.35 msec typical |
| Default Buffer (cache) Size | 16 Mbytes |
| Max Operating Shock (2-msec) | 60 Gs |
| Max Nonoperating Shock (2-msec) | 250 Gs |
| Operating Temperature (max) | 55 deg C |
| Operating Temperature (min) | 5 deg C |
| Nonoperating Temperature (max) | 70 deg C |
| Nonoperating Temperature (min) | -40 deg C |
| Acoustics, Idle (sound power, typ) | 3.0 Bels |
| MTBF (Hours) | 1,400,000 hours |
| Nonrecoverable Read Errors | 1 per 10^16 bits read |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: 9EA004-080
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Condition Levels Explained
The product is brand new.
Warranty
1 Year DiscTech Warranty
