Seagate Part #/MPN: ST10000NM002G
DiscTech Item #: SGT-ST10000NM002G-RF-OE
$100.00
- Refurbished
- Warranty:1 Year DiscTech
- Low Stock:Call for ETA
Enterprise Grade
Capacity: 10TB
Speed: 7.2K RPM
Interface Types: SAS
Form Factor: 3.5" LFF Hard Drive
Sector Size: 512 / 512e
Electrical Interface: SAS-3 12Gbps
On-Board Cache: 256MB
Seagate Exos X16 ST10000NM002G 10TB 3.5" LFF 12Gbps 7.2K RPM FastFormat 512e Enterprise SAS Hard Drive - Refurbished Seagate Exos X16 ST10000NM002G 10TB / 10000GB 3.5" LFF 12Gbps 7.2K RPM FastFormat (512e/4Kn) Enterprise SAS HDD / Hard Drive - Refurbished
EXOS X16
Seagate manufactures hard drives that specifically address the needs of the hyperscale storage market. As the flagship of the Seagate® X class, the Exos™ X16 enterprise hard drives are the highest-capacity hard drives in the fleet.
Best-Fit Applications
easily reformatted to 4Kn (and vice versa) with the FastFormat
feature.
• FastFormat only works with 512e and 4Kn. You can’t use FastFormat with 512-byte native drives.
• FastFormat reformats the drive, so all data on the drive will be lost once you issue the command. Don’t forget to back up your data before issuing FastFormat!
• T10 fast format conversion between 4K and 512E configurations is possible only if sector sizes are exact multiples of 8.
• The new sector size will take effect only after a fast format.
EXOS X16
Seagate manufactures hard drives that specifically address the needs of the hyperscale storage market. As the flagship of the Seagate® X class, the Exos™ X16 enterprise hard drives are the highest-capacity hard drives in the fleet.
Best-Fit Applications
- Hyperscale applications/cloud data centers
- Massive scale-out data centers
- Big data applications
- High-capacity density RAID storage
- Mainstream enterprise external storage arrays
- Distributed file systems, including Hadoop and Ceph Enterprise backup and restore— D2D, virtual tape
- Centralized surveillance
easily reformatted to 4Kn (and vice versa) with the FastFormat
feature.
• FastFormat only works with 512e and 4Kn. You can’t use FastFormat with 512-byte native drives.
• FastFormat reformats the drive, so all data on the drive will be lost once you issue the command. Don’t forget to back up your data before issuing FastFormat!
• T10 fast format conversion between 4K and 512E configurations is possible only if sector sizes are exact multiples of 8.
• The new sector size will take effect only after a fast format.
Compatibility: Compatible with systems that support 10TB 3.5" SAS HDDS
| Exos Enterprise X16 | |
|---|---|
| Standard Model FastFormat (512e/4Kn) | ST10000NM002G |
| Interface | 12Gb/s SAS |
| Capacity | 10TB / 10000GB |
| Features | |
| Helium Sealed-Drive Design | Yes |
| Protection Information (T10 DIF) | Yes |
| SuperParity | Yes |
| Low Halogen | Yes |
| PowerChoice Technology | Yes |
| PowerBalance Technology | Yes |
| Hot-Plug Support | Yes |
| Cache, Multisegmented (MB) | 256 |
| Organic Solderability Preservative | Yes |
| RSA 2048 Firmware Verification | Yes |
| Reliability/Data Integrity | |
| Mean Time Between Failures (MTBF, hours) | 2,500,000 |
| Reliability Rating @ Full 24×7 Operation (AFR) | 0.35% |
| Nonrecoverable Read Errors per Bits Read | 1 Sector per 1015 |
| Power-On Hours per Year (24×7) | 8760 |
| 512e Sector Size (Bytes per Sector) | 512, 520, 528 |
| 4Kn Sector Size (Bytes per Sector) | 4096, 4160, 4224 |
| Performance | |
| Spindle Speed (RPM) | 7200 |
| Interface Access Speed (Gb/s) |
|
| Max Sustainable Transfer Rate OD (MB/s, MiB/s) | 245, 233 |
| Random Rewad/Write 4K QD03 WCD (IOPS) | 170/440 |
| Average Latency (ms) | 4.16 |
| Interface Ports | Dual |
| Rotational Vibration @ 20-1500Hz (rad/sec) | 12.5 |
| Power Consumption | |
| Idle A (W) Average |
|
| Max Operating, Random Read/Write 4K/16Q (W) |
|
| Power Supply Requirements | +12 V and +5 V |
| Evrironmental/Temperature | |
| Temperature, Operating (°C) | 5°C - 60°C |
| Vibration, Nonoperating: 2 to 500Hz (Grms) | 2.27 |
| Shock, Operating 2 ms Read/Write (Gs) | 50 |
| Shock, Nonoperating, 2ms (Gs) | 200 |
| Physical | |
| Height (in/mm, max) | 1.028in/26.1mm |
| Weight (in/mm, max) | 4.010in/101.85mm |
| Depth (in/mm, max) | 5.787in/147.0mm |
| Weigt (g/lb) | 670g/1.477 lb |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Refurbished
1 Year DiscTech Warranty
