Seagate Exos X16 ST16000NM001G 16TB 512e SATA Hard Drive

Seagate ST16000NM001G 2KK103-003 2KK103-002 2KK103-881 16TB SATA Hard Drive Exos Image 1 imageSeagate ST16000NM001G 2KK103-003 2KK103-002 2KK103-881 16TB SATA Hard Drive Exos Image 2 imageSeagate ST16000NM001G 2KK103-003 2KK103-002 2KK103-881 16TB SATA Hard Drive Exos Image 3 imageSeagate ST16000NM001G 2KK103-003 2KK103-002 2KK103-881 16TB SATA Hard Drive Exos Image 4 imageSeagate ST16000NM001G 2KK103-003 2KK103-002 2KK103-881 16TB SATA Hard Drive Exos Image 5 imageSeagate ST16000NM001G 2KK103-003 2KK103-002 2KK103-881 16TB SATA Hard Drive Exos Image 6 image
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Special Order - Call for Lead Time
    Special Order - Call for Lead Time

    This item has a variable lead time for fulfilment. Please call us to discuss. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

  • 1 Year DiscTechWarranty
    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty

$399.00

Capacity:16TB
Speed:7.2K RPM
Interface Types:SATA
Form Factor:3.5" LFF Hard Drive
Electrical Interface:SATA 600 - 6Gbps
RAM:256MB
Click to see more 16TB SATA 7.2K RPM Drives

Description

Seagate Exos X16 ST16000NM001G 16TB 3.5-Inch LFF 6Gbps 7.2K RPM Enterprise 512e Fast Format SATA Hard Drive - Brand New
 Alt MPN: 2KK103-003

Seagate Exos X16 ST16000NM001G 16TB / 16000GB 3.5" LFF / Large Form Factor 6.0 Gb/s 7200 RPM Enterprise 512e / 512 Emulation Fast Format SATA / Serial ATA HDD / Hard Drive - Brand New

Scalable. Responsive. Innovative.
Exos X16

Seagate manufactures hard drives that specifically address the needs of the hyperscale storage market. As the flagship of the Seagate X class, the Exos X16 enterprise hard drives are the highest-capacity hard drives in the fleet.

Maximum Storage Capacity for Highest Rack Space Efficiency

Industry’s first 16TB drive for 33% more petabytes per rack.

Highest 16TB hard drive performance with enhanced caching, making it perfect for cloud data center and massive scale-out data center applications

Hyperscale SATA model tuned for large data transfers and low latency

PowerBalance feature optimizes Watts/TB

Helium sealed-drive design delivers lower total cost of ownership through lower power and weight.

Next-generation helium side-sealing weld technology for added handling robustness and leak protection.

Digital environmental sensors to monitor internal drive conditions for optimal operation and performance

Data protection and security: Seagate Secure features for safe, affordable, fast and easy drive retirement

Proven enterprise-class reliability with 2.5M-hr MTBF rating

Best-Fit Applications

  • Hyperscale applications/cloud data centers
  • Massive scale-out data centers
  • Big data applications
  • High-capacity density RAID storage
  • Mainstream enterprise external storage arrays
  • Distributed file systems, including Hadoop and Ceph
  • Enterprise backup and restore— D2D, virtual tape
  • Centralized surveillance

Compatibility

This drive is compatible with any server that accepts 3.5inx1.0in SATA Drive.

Specifications

Exos Enterprise X16
Standard Model FastFormat (512e/4Kn)ST16000NM001G
Interface6Gb/s SATA
Capacity16TB / 16000GB
Features
Helium Sealed-Drive DesignYes
Protection Information (T10 DIF) ---
SuperParityYes
Low HalogenYes
PowerChoice TechnologyYes
PowerBalance TechnologyYes
Hot-Plug SupportYes
Cache, Multisegmented (MB)256
Organic Solderability PreservativeYes
RSA 2048 Firmware VerificationYes
Reliability/Data Integrity
Mean Time Between Failures (MTBF, hours)2,500,000
Reliability Rating @ Full 24×7 Operation (AFR)0.35%
Nonrecoverable Read Errors per Bits Read1 Sector per 1015
Power-On Hours per Year (24×7)8760
512e Sector Size (Bytes per Sector)512
4Kn Sector Size (Bytes per Sector)4096
Performance
Spindle Speed (RPM)7200
Interface Access Speed (Gb/s)
  • 6.0
  • 3.0
    • Max Sustainable Transfer Rate
  • 261
  • 249
    • Random Rewad/Write 4K QD03 WCD (IOPS)170/440
    Average Latency (ms)4.16
    Interface PortsSingle
    Rotational Vibration @ 20-1500Hz (rad/sec)12.5
    Power Consumption
    Idle A (W) Average5.00W
    Max Operating, Random Read/Write 4K/16Q (W)
  • 10.0
  • 6.3
    • Power Supply Requirements+12 V and +5 V
    Evrironmental/Temperature
    Temperature, Operating (°C)5°C - 60°C
    Vibration, Nonoperating: 2 to 500Hz (Grms)2.27
    Shock, Operating Read/Write (Gs)50
    Shock, Nonoperating, 1ms/2ms (Gs)200
    Physical
    Height (in/mm, max)1.028in/26.1mm
    Weight (in/mm, max)4.010in/101.85mm
    Depth (in/mm, max)5.787in/147.0mm
    Weigt (g/lb)670g/1.477lb
    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: 2KK103-003 2KK103-002 2KK103-881

    Weight: 1.8 lb

    Warranty: 1 Year DiscTech
