Seagate Part #/MPN: ST10000NM0156
DiscTech Item #: SGT-ST10000NM0156-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 10TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Encryption/SED Supported
Sector Size: 512 / 512e
Sustained Throughput: 254
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 256MB
Seagate Helium ST10000NM0156 10TB 3.5" LFF 6Gbps 7.2K RPM Enterprise 512e SED SATA Hard Drive - Brand New
Seagate Helium ST10000NM0156 10TB / 10000GB 3.5" LFF / Large Form Factor 6.0 Gb/s 7200 RPM Enterprise 512e / 512 Emulation SED / Self-Encrypting SATA / Serial ATA HDD / Hard Drive - Brand New
Enterprise Capacity 3.5 HDD (Helium)
Maximum Storage Capacity for Highest Rack Space Efficiency
- 10TB per drive 1 for 25% more petabytes per rack
- Industry's lowest power and weight for optimum data center TCO
- Highest 10TB HDD performance with enhanced caching, making it perfect for OLTP and HPC application
- Hyperscale SATA model tuned for large data transfers
- PowerBalance™ feature optimizes IOPS/Watt
- Advanced Write Caching feature for 20% boost in random write performance
- Forged, wrought-aluminum base and a helium sealed-drive design with no porosity and uniform density
- Superior material and weld-width design for a more robust, hermetically sealed-drive enclosure that protects from helium leaks
- Digital environmental sensors for measuring internal humidity, pressure and temperature, helping to ensure high reliability, performance and quality
- Latest hermetic interconnect technology supporting higher data rate heads and higher pin counts for extreme thermal conditions
- Proven enterprise-class reliability backed by 2.5M-hr MTBF
Best-Fit Applications
- Hyperscale applications/cloud data centers
- Massive scale-out data centers
- OLTP and HPC applications
- High-capacity density RAID storage
- Mainstream enterprise external storage arrays
- Distributed file systems, including Hadoop and Ceph
- Enterprise backup and restore—D2D, virtual tape
- Centralized surveillance
Compatibility:
This drive is compatible with any server that accepts 3.5inx1.0in SATA Drive.
| Enterprise Capacity 3.5 HDD (Helium) | |
|---|---|
| SED Model (512e) | ST10000NM0156 |
| Specification | |
| Capacity | 10TB / 10,000GB |
| Interface | SATA 6Gb/s Standard |
| Features | |
| Helium Sealed-Drive Design With Wide Weld | Yes |
| Digital Environmental Sensors | Yes |
| Protection Information (T10 DIF) | --- |
| SuperParity | Yes |
| PowerChoice™/PowerBalance™ Technology | Yes |
| Low Halogen/Hot-Plug Support | Yes |
| Cache, Multisegmented (MB) | 256 |
| Organic Solderability Preservative | Yes |
| Reliability/Data Integrity | |
| Mean Time Between Failures (MTBF, hours) | 2.5 Million |
| Reliability Rating@ Full 24×7 Operation (AFR) | 0.35% |
| Nonrecoverable Read Errors per Bits Read | 1 Sector per 1015 |
| Power-On Hours per Year (24x7) | 8760 |
| 512e Sector Size (Bytes per Sector) | 512 |
| 4Kn Sector Size (Bytes per Sector) | 4096 |
| Performance | |
| Spindle Speed (RPM) | 7200 |
| Interface Access Speed (Gb/s) | 6.0, 3.0, 1.5 |
| Max. Sustained Transfer Rate OD (MB/s, MiB/s) | 256MB/s |
| Random Read/Write 4K QD16 WCD (IOPS) | 170 370 |
| Average Latency (ms) | 4.16 |
| Interface Ports | Single |
| Rotational Vibration@ 1500Hz (rad/s) | 12.5 |
| Power Consumption | |
| Idle A (W) Average | 4.5W |
| Max Operating Power, Random Write (WCD) 4K/4Q RR50% / RW50% | 8.0 |
| Max Operating Power, Random Read 4K/16Q (W) | 8.4 |
| Power Supply Requirements | +12v AND &PLUS5 V |
| Environmental | |
| Temperature, Operating (°C) | 5°C - 60°C |
| Vibration, Nonoperating: 10Hz to 500Hz (Grms) | 2.27 |
| Shock, Operating 2ms (Read/Write) (Gs) | 70/40Gs |
| Shock, Nonoperating, 1ms/2ms (Gs) | 250Gs |
| Physical | |
| Height (mm/in, max) | 26.11mm/1.028in |
| Width (mm/in, max) | 101.85mm/4.010in |
| Depth (mm/in, max) | 147.0mm/5.787in |
| Weight (g/lb) | 650g/1.433lb |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
