Seagate Part #/MPN: ST9900705SS
DiscTech Item #: SGT-ST9900705SS-RF-OE-NAP
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 900GB
Speed: 10,000RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Encryption/SED Supported
Sector Size: 512 / 512e
Sustained Throughput: 168
Average Seek Time: 3.7 / 4.1
Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps
On-Board Cache: 64MB
NetApp 47776-03 / Seagate Savvio 10K.5 ST9900705SS 9VX066-041 900GB 10K 6Gbps SFF Serial SCSI / SAS Hard Drive with SED Encryption - Refurbished
Ideal for NAS, SAN and DAS external enterprise storage solutions.
This fifth-generation Savvio 10K.5 drive provides the highest capacity and best reliability available in a small form factor, 10K-RPM enterprise hard drive. This drive enables 3.5-inch to 2.5-inch form factor transition and widespread market adoption of 2.5-inch-based external storage solutions for enterprise OEMs, system designers and end-user organizations. Self-Encrypting Drives (SED) and FIPS 140-2 Validated™ SED security options are available to help you protect your data.
Key Features and Benefits
- Delivers the highest-capacity in a 2.5-inch, 10K-RPM hard drive (up to 900GB) to manage more data without increasing the number of drives
- First SFF drive to offer four capacity points on a single platform
- Industry-leading 0.44% AFR for field-proven reliability
- Improves performance for faster data storage and access
- Reduces power consumption and enables green IT initiatives
- PowerChoice™ technology for T10-compliant power management enables IT organizations to tailor systems for performance and power consumption
- Reduces system design, qualification and inventory costs for OEMs
- Enables data centers to better manage hard drive transitions
- Protection Information protects against inadvertent data change¹
- Seagate Unified Storage architecture reduces system complexity and operating costs by converging disparate interfaces, form factors and security standards
firmware : MS01
Compatibility:
This drive is compatible with any server that accepts small form factor (SFF) SAS hard drives
| Specifications | |
|---|---|
| Model Number | ST9900705SS |
| Interface | 6-Gb/s SAS |
| Cache | 64MB |
| Capacity | 900GB |
| Areal density (avg) | 506Gb/in2 |
| Guaranteed Sectors | 1,758,174,768 |
| Encryption | SED |
PHYSICAL | |
| Height (maximum) | 15.00mm (0.591 in) |
| Width (maximum) | 70.10mm (2.760 in) |
| Length (maximum) | 100.45mm (3.955 in) |
| Weight (typical) | 205g (.451 lb) |
| PERFORMANCE | |
| Spin Speed (RPM) | 10,000 RPM |
| Sustained data transfer rate | 168MB/s |
| Average latency | 3.0ms |
| Random read seek time | 3.7ms |
| Random write seek time | 4.1ms |
| I/O data transfer rate | 600MB/s |
| Unrecoverable read errors | 1 in 10^16 |
| RELIABILITY | |
| MTBF | 2,000,000 hours |
| Annual Failure Rate | 0.44% |
| POWER | |
| 12V start max current | 1.00A |
| 5V start max current | 0.63A |
| Average idle power | 4.42W |
| ENVIRONMENT | |
| Ambient Temperature | |
| Operating | 5°–55°C |
| Nonoperating | -40°–70°C |
| Maximum operating temperature change | 20°C per hour |
| Maximum nonoperating temperature change | 20°C per hour |
| Shock | |
| Operating Shock (max) | 40 Gs for 11ms |
| Nonoperating Shock (max) | 400 Gs for 2ms |
| ACOUSTICS | |
| Acoustics (Idle Volume) | 3.0 bels |
| Features | |
| Storage Type | HDD |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 47776-03 9VX066-041
Weight: 1 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
