Seagate ST10000NM0016 10TB SATA Hard Drive

(0) No Reviews Yet

Seagate Part #/MPN: ST10000NM0016

DiscTech Item #: SGT-ST10000NM0016-BN-OE


Enterprise Grade

Capacity: 10TB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 254/243

Average Seek Time: 4.16

Electrical Interface: SATA 600 - 6.0Gbps

Seagate Helium Gen V.6 ST10000NM0016 10TB 6Gbps 7.2K RPM Enterprise SATA HDD - Brand New

Seagate Helium Gen V.6 ST10000NM0016 10TB / 10,000GB 6Gb/s 7200 RPM Enterprise Serial ATA Hard Disk Drive - Brand New

Maximum Storage Capacity for Highest Rack Space Efficiency

  • 10TB per drive 1 for 25% more petabytes per rack
  • Industry's lowest power and weight for optimum data center TCO
  • Forged, wrought-aluminum base and a helium sealed-drive design with uniform density and no porosity
  • Superior material and weld-width design for a more robust, hermetically sealed-drive enclosure that protects from helium leaks
  • Digital environmental sensors for measuring internal humidity, pressure and temperature, helping to ensure high reliability, performance and quality
  • Latest hermetic interconnect technology supporting higher data rate heads and higher pin counts for extreme thermal conditions
  • Proven enterprise-class reliability backed by 2.5M-hr MTBF

Best-Fit Applications

  • Hyperscale applications/cloud data centers
  • Massive scale-out data centers
  • High-capacity density RAID storage
  • Mainstream enterprise external storage arrays
  • Distributed file systems, including Hadoop and Ceph
  • Enterprise backup and restore—D2D, virtual tape
  • Centralized surveillance

Alt. PN: 1TT101-002


This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SATA drives.

Hyperscale Model (512e)ST10000NM0016
Special Features
Multi-Step Forged Helium Sealed-Drive DesignYes
Superior Wide-Weld Hermetically Sealed-Drive EnlosureYes
Digital Sensors for Humidity, Helium Pressure and TemperatureYes
Protection Information (T10 DIF) ---
Low HalogenYes
PowerChoice™ Idle Power TechnologyYes
PowerChoice™ Power/Performance Technology Yes
RAID RebuildYes
Hot-Plug SupportYes
Cache, Multisegmented (MB)256
Organic Solderability PreservativeYes
Reliability/Data Integrity
Mean Time Between Failures (MTBF, hours)2.5 Million
Reliabilility Rating @ Full 24x7 Operation (AFR)0.35%
Non-recoverable Read Errors per Bits Read, Max1 sector per 10E15
Power-On Hours8760
512e Sector Size (Bytes per Sector)512
4Kn Sector Size (Bytes per Sector)4096
Spin Speed7200RPM
Interface Access Speed (Gb/s)6.0, 3.0, 1.5
Max. Sustained Transfer Rate OD (MB/s, MiB/s)254, 243
Average Latency (ms)4.16
Interface PortsSingle
Rotational Vibration @ 1500Hz (rad/s)12.5
Height (mm/in, max)26.11mm/1.028in
Width (mm/in, max)101.85mm/4.010in
Depth (mm/in, max)147.0mm/5.787in
Weight (g/lb)650g/1.433lb

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Brand New
