Seagate Part #/MPN: ST2000NM0054
DiscTech Item #: SGT-ST2000NM0054-NP-OE
- New PullCondition Levels Explained
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 2TB
Speed: 7,200RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: Up to 226
Average Seek Time: 4.16
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
On-Board Cache: 128MB
Seagate ST2000NM0054 2TB 3.5in 12Gbps 7.2K RPM Enterprise (512E) SED SAS HDD - New Pull
Seagate ST2000NM0054 2000GB 3.5" 12.0Gbps 7200 RPM Enterprise 512 Emulation Self-Encrypting Drive Serial Attached SCSI Hard Disk Drive -Brand New
Capacity-Optimised Enterprise Hard Drive for Bulk-Data Applications
- Highest-capacity large form factor enterprise drive – 50% more capacity over generation with 2TB – for demanding data growth.
- Fastest high capacity HDD with best-in-class random and sequential read/write performance.
- Eighth-generation drive technology for reliable access to bulk storage of unstructured data.
- 12Gb/s SAS interface for easy integration into replicated and RAID storage systems.
- Enhanced error correction, super parity and end-to-end SAS-based data integrity for accurate data storage
- Industry-leading rotational vibration tolerance ensures consistent performance.
- Improved power and cooling efficiencies with low power and consumption and on-demand PowerChoice™ technology based on T10/T13 power management standards.
- Engineered for 24x7 workloads of 550TB/yr – 10x that of desktop drives.
- Robust performance with processors, ramp load technology, top-cover-attached motor and humidity sensor for optimum performance in all chassis.
- Self-Encrypting Drive (AES-256) validation and Seagate Instant Secure Erase cuts IT drive retirement costs while protecting data at rest securely
Best-Fit Applications
- Hyperscale applications
- High-capacity RAID storage
- Mainstream enterprise external storage arrays (SAN, NAS, DAS)
- Cloud data centres – replicated bulk data storage
- Enterprise backup and restore – D2D, virtual tape
- Centralised surveillance
Compatibility:
This drive is compatible with any server that accepts 3.5" x 1.0" (LFF Hard Drive) SAS drives.
| Drive Model | ST2000NM0054 |
|---|---|
| Capacity | 2TB/2000GB |
| Self- Encrypting Drive | AES-256 |
| Interface | SAS 12Gb/s |
| Features | |
| Protection Information (T10 DIF) | Yes |
| Humidity Sensor | Yes |
| Super Parity | Yes |
| Low Halogen | Yes |
| PowerChoice™ Technology | Yes |
| Cache, Multisegmented (MB) | 128 |
| Reliability/Data Integrity | |
| Mean Time Between Failures (MTBF) | 1.4M |
| Reliability Rating @ Full 24x7 Operation (AFR) | 0.63% |
| Nonrecoverable Read Errors per Bits Read | 1 sector per 10 |
| Power-On Hours per Year | 8760 (24x7) |
| Sector Size (Bytes per Sector) | 512, 520, 528 |
| Performance | |
| Spindle Speed (RPM) | 7,200 |
| Interface Access Speed (Gb/s) | 12.0 |
| Max Sustained Transfer Rate OD (MB/s) | Up to 226 |
| Average Latency (ms) | 4.16 |
| Interface Ports | Dual |
| Rotation @ 1500 Hz (rad/s) | 12.5 |
| Power Consumption | |
| Idle Power, Average (W) | 4.84 |
| Typical Operating, Random Read (W) | 8.93 |
| Power Supply Requirements | +12V and +5V |
| Environmental | |
| Temperature, Operating (°C) | 5 to 60 |
| Vibration, NonoperatingL 10Hz to 500Hz (Grms) | 4.9 |
| Shock, Operating, 2ms (Read/Write) (Gs) | 70/40 |
| Shock, Nonoperating, 1ms and 2ms (Gs) | 300 |
| Physical | |
| Height (mm/in) | 26.1/1.028 |
| Width (mm/in) | 101.85/4.010 |
| Depth (mm/in) | 147.0/5.878 |
| Weight (g/lb) | 605/1.344 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 1.8 lb
Warranty: 1 Year DiscTech
New Pull
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
