Seagate ST2000NX0243 2000GB SATA Hard Drive

Seagate Part #/MPN: ST2000NX0243

DiscTech Item #: SGT-ST2000NX0243-FR-1Y


$149.00
  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

$149.00

Enterprise Grade

Capacity: 2TB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 4Kn

Sustained Throughput: 136

Average Seek Time: 4.16

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 128MB

Seagate ST2000NX0243 2TB 2.5in 6Gbps 7200RPM Enterprise Capacity (4Kn) SATA HDD - Factory Recertified

Seagate ST2000NX0243 2000GB 2.5" 6.0 Gbps 7.2K RPM Enterprise Capacity 4K Native Serial Attached Technology Attachment Hard Disk Drive - Factory Recertified

Design Small and Deliver BIG—2.5-Inch Nearline Drive

  • Up to 2TB capacity in 15mm z-height, 2.5-inch form factor for space-constrained data centers.
  • Designed for high-density storage solutions requiring environmentally sound low power consumption and low weight for maximum storage efficiency.
  • Third-generation, enterprise-class reliability for 24x7 environmental robustness.
  • Highest efficiency for over 50% improvement in watts/TB, and 18% sequential performance improvement compared to the previous generation.
  • Improved rotational vibration tolerance and head micro-actuation maximizes system availability and performance.
  • Lowest enterprise operation power and enhanced PowerChoice™ options for additional power savings during idle periods.

Best-Fit Applications

  • Storage-hungry business applications.
  • Storage area networks (SAN) and network attached storage (NAS)
  • Maximum-capacity entry-level servers and blade servers
  • Rich media content storage
  • Enterprise backup and restore—D2D, virtual tape
  • Cloud computing


Compatibility:

This drive is compatible with any server that accepts 2.5" x 15mm (SFF Hard Drive) SATA drive.

Drive ModelST2000NX0243
Capacity2TB/2000GB
InterfaceSATA 6Gbps
Self-Encrypted DriveNo
Features
PowerChoice™ on-demand power optionYes
Low HalogenYes
RAID Rebuild™Yes
Reliability/Data Integrity
Mean Time Between Failures (MTBF, hours)1.4 million
Reliability Rating @ Full 24x7 operation (AFR)0.63%
Nonrecoverable Read Errors per Bits Read1 sector per 10E15
Power-On Hours per Year8760
Bytes per Sector4K
Performance
Spindle Speed (RPM)7200
Cache Buffer, Multisegmented (MB)128
Interface Acces Speed (Gb/s)6.0
Max. Sustained Transfer Rate (MB/s)136
Average Latency (ms)4.16
Interface PortsSingle
RV Tolerance(rad/s to 1800Hz)16
Power Management
Idle Power (W)3.87
Typical Operating, Random Read (W)5.22
PowerChoice™ Technology (Standby) (W)1.14
Power Supply Requirements+12V and +5V
Enviromental
Temperature, Operating (˚C)5 to 55
Vibration, Operating, 5Hz to 500Hz (Gs)0.5
Vibration, NonOperation, 5Hz to 500Hz (Gs)3.0
Shock, Operating, 2ms (Gs)25
Shock, Nonoperating, 2ms (Gs)400
Acoustics, Typical Idle (bels)2.8
Acoustics, Typical Seek (bels)3.2
Physical
Height (in/mm)0.591/15.00
Width (in/mm)2.760/70.10
Depth (in/mm)3.955/100.45
Weight (lb/g)0.437/198

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 1.5 lb

Warranty: 1 Year DiscTech

Factory Refurbished
