Dell TMVN7 / Seagate ST2000NX0463 2TB 2.5" SFF 12Gbps 7.2K RPM 512n Enterprise SAS HD
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 2TB |
| Speed: | 7.2K RPM |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SAS-3 12Gbps |
| RAM: | 128MB |
Description
Dell TMVN7 / Seagate ST2000NX0463 2TB 2.5" SFF 12Gbps 7.2K RPM 512n ISE Enterprise SAS HDD - Brand New OEM
Dell Part Number: TMVN7 0TMVN7 1VD230-150
Enterprise Capacity 2.5 HDD
Design Small and Deliver BIG – 2.5-Inch Nearline Drive
- Up to 2TB capacity in 15mm z-height, 2.5-inch form factor for space-constrained data centers.
- Designed for high-density storage solutions requiring environmentally sound low power consumption and low weight for maximum storage efficiency.
- Choose 12Gb/s SAS for high data integrity, scalability and fast data access.
- Third-generation, enterprise-class reliability for 24x7 environmental robustness.
- Highest efficiency with over 50% improvement in watts/TB, and 18% sequential performance improvement compared to the previous generation.
- Improved rotational vibration tolerance and head micro-actuation maximizes system availability and performance.
- Lowest enterprise operating power and enhanced PowerChoice options for additional power savings during idle periods.
Best-Fit Applications
- Storage-hungry business applications
- Storage area networks (SAN) and network attached storage (NAS).
- Maximum-capacity entry-level servers and blade servers
- Rich media content storage
- Enterprise backup and restore – D2D, virtual tape
- Cloud computing
Compatibility:
This drive is compatible with any server that accepts 2.5in x 15mm (SFF) SAS drives.
Specifications
| Seagate | |
|---|---|
| Part Number | ST2000NX0463 |
| Dell Part Number | TMVN7 |
| Specification | 512n |
| Features | ISE (Instant Secure Erase) |
| Capacity | 2 TB/2,000 GB |
| Features | |
| PowerChoice on demand power option | Yes |
| Protection Information | Yes |
| Low Halogen | Yes |
| RAID Rebuild | Yes |
| Reliability/Data Integrity | |
| Mean Time Between Failures (MTBF, hours) | 1.4 million |
| Reliability Rating @ Full 24x7 operation (AFR) | 0.63% |
| Nonrecoverable Read Errors per Bits Read | 1 sector per 10e15 |
| Power-On Hours per Year | 8760 |
| Bytes per Sector | 512, 520, 528 |
| Performance | |
| Spindle Speed (RPM) | 7200 |
| Cache Buffer, Multisegmented (MB) | 128 |
| Interface Access Speed (Gb/s) | 12.0, 6.0, 3.0 |
| Max. Sustained Transfer Rate (MB/s) | 136 |
| Average Latency (ms) | 4.16 |
| Interface Ports | Dual |
| RV Tolerance (rad/s to 1800Hz) | 16 |
| Power Management | |
| Idle Power (W) | 3.53 |
| Typical Operating, Random Read (W) | 6.02 |
| PowerChoice Technology (Standby) (W) | 1.52 |
| Power Supply Requirements | +12V and +5V |
| Environmental | |
| Temperature, Operating (°C) | 5 to 55 |
| Vibration, Operating, 5Hz to 500Hz (Gs) | 0.5 |
| Vibration, Nonoperating, 5Hz to 500Hz (Gs) | 3.0 |
| Shock, Operating, 2ms (Gs) | 25 |
| Shock, Nonoperating, 2ms (Gs) | 400 |
| Acoustics, Typical Idle (bels) | 2.8 |
| Acoustics, Typical Seel (bels) | 3.2 |
| Physical | |
| Height (in/mm) | 0.591/15.00 |
| Width (in/mm) | 2.760/70.10 |
| Depth (in/mm) | 3.955/100.45 |
| Weight (lb/kg) | 0.437/0.198 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: TMVN7 0TMVN7 1VD230-150
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
