Seagate Part #/MPN: ST3000VX000
DiscTech Item #: SGT-ST3000VX000-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Capacity: 3TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 210
Average Seek Time: <8.5/<9.5
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 64MB
Seagate ST3000VX000 3TB 3.5in 6Gbps 7.2K RPM SV35 Series SATA HDD - Brand New
Seagate ST3000VX000 3000GB 3.5" 6.0 Gbps 7200 RPM SV35 Series Serial ATA Hard Disk Drive - Brand New
Alt MPN: 1CU166
SV35 Series™ - Surveillance-Optimized Storage
Key Advantages
- The industry’s only surveillance-optimized hard drive platform with 3TB capacity options
- A hard drive series tested and tuned for high write-cycle workloads typical in video surveillance storage systems
- 24×7 operational capabilities while maintaining high MTBF of 1M hours
- Performance driven by a 7200-RPM base platform, with 64MB DDR2 DRAM and optimized write caching surveillance algorithms
- 1TB-per-disk technology takes your surveillance storage further with lower cost/GB to support HD resolutions, enhanced performance and best-in-class support.
- Seagate AcuTrac™ servo technology provides accurate read-write operation even in challenging operating environments.
- 2A current-limited startup to support the use of embedded system power supplies
- Spin control features enable power-on in standby mode or drive spin-down to conserve power and improve reliability during archival periods
Best-Fit Applications
- NVR
- Embedded SDVR
- Hybrid SDVR
- PC-based SDVR
Compatibility:
This drive is compatible with any server that accepts 3.5"x1.0" (LFF Hard Drive) SATA Drives.
| SPECIFICATIONS | |
|---|---|
| Model number | ST3000VX000 |
| Interface Options | SATA Gb/s NCQ |
| Capacity | 3TB/3000GB |
| PERFORMANCE | |
| Spindle Speed (RPM) | 7200 |
| Cache, Multisegmented (MB) | 64 |
| SATA Transfer Rates Supported (Gb/s) | 6.0/3.0/1.5 |
| Seek Average, Read (ms) | <8.5 |
| Seek Average, Write (ms) | <9.5 |
| Average Data Rate, read/write (MB/s) | 156 |
| Max Sustained Data Rate, OD read, (MB/s) | 210 |
| CONFIGURATON/RELIABILITY | |
| Heads/Disks | 6/3 |
| Bytes per Sector | 4096 |
| VOLTAGE | |
| Voltage Tolerance, Including Noise (5V) | ±5% |
| Voltage Tolerance, Including Noise (12V) | ±10%/-7.5% |
| RELIABILITY/DATA INTEGRITY | |
| Load/Unload Cycles | 300,000 |
| Nonrecoverable Read Errors per Bits Read, Max | 1 per 10e14 |
| MTBF (hours) | 1M |
| Annualized Failure Rate (AFR) | <1% |
| Power-On Hours | 8760 |
| POWER MANAGEMENT | |
| Startup Power (A) | 2.0 |
| Operating Mode, Typical (W) | 8.0 |
| Idle2 Average (W) | 5.40 |
| Standby Mode (W) | 0.75 |
| Sleep Mode (W) | 0.75 |
| ENVIRONMENTAL | |
| Temperature Operating (ambient, min °C) Operating (drive case, max °C) Nonoperating (ambient, min °C) Nonoperating (ambient, max °C) | 0 60 -40 70 |
| PHYSICAL | |
| Height (mm/in) | 26.11/1.028 |
| Width (mm/in) | 101.6/4.0 |
| Depth (mm/in) | 146.99/5.787 |
| Weight (g/lb) | 626/1.38 |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: 1CU166
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
