Seagate ST3500071FCV NL35 Series 500GB Fibre Channel Hard Drive

Seagate Part #/MPN: ST3500071FCV

DiscTech Item #: SGT-ST3500071FCV-BN-OE


$125.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$125.00

Enterprise Grade

Capacity: 500GB

Speed: 7,200RPM

Interface Types: Fibre Channel - Internal - Arbitrated Loop ASA II

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Average Seek Time: 8.5/9.5

Electrical Interface: FC-AL - 2Gbps

On-Board Cache: 8MB

Seagate ST3500071FCV NL35 Series 500GB 7.2K 2Gbps Fibre Channel Hard Drive - Brand New

NL35 Series drives combine Tunneling Magnetoresistive (TMR) heads and a Fibre Channel interface to provide high performance, high capacity data storage for a variety of systems including engineering workstations, network servers, mainframes, and supercomputers.

NL35 Series drives support the Fibre Channel Arbitrated Loop (FC-AL) and SCSI Fibre Channel Protocol as described in the ANSI specifications, this document, and the Fibre Channel Interface Manual (part number 77767496) which describes the general interface characteristics of this drive. NL35 Series drives are classified as intelligent peripherals and provide level 2 conformance (highest level) with the ANSI SCSI standard.

NL35 Series drives use a dedicated landing zone at the innermost radius of the media to eliminate the possibility of destroying or degrading data by landing in the data zone. The drive automatically goes to the landing zone when power is removed.

Alternate Part Number: 9Y8207-031

EMC# 118032512-A02


Compatibility:

This drive is compatible with any of our Fibre / Fiber Channel adapters and also with any of our Fibre / Fiber hot-swap trays.

Series Overview ST3500071FCV
Drive Capacity 500GB
Drive Interface

Fibre Channel

Number of Data Heads

8

Transfer Rate to Host

2 Gb/sec

Bytes per track

686

Performance
Rotational Speed 7,200 RPM
Average Latency 4.17 ms
Buffer Size 8MB
Avg. Read 8.5 msec
Avg. Write9.5 msec
Physical Size
Dimensions (W) x (D) x (H) 101.6 mm (4 in) x 146.558 mm (5.77 in) x 25.654 mm (1.01 in)
Weight726 g (1.6 lb)
Environmental
Temp - Operating 5° to 55 °C
Temp - Non-Operating -40° to 70°C

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 9Y8207-031 118032512-A02

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
