Seagate Part #/MPN: ST4000VN0001
DiscTech Item #: SGT-ST4000VN0001-BN-5Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:5 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 4TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 180
Average Seek Time: 12.0/12.0
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
Alt MPN: 1SF178-500
NAS HDD - Best-Performing, Highest-Capacity Storage for 1- to 8-Bay NAS Systems
- Seagate® NAS HDDs are built and tested to provide industry-leading performance for small NAS systems.
- NASWorks™ technology supports customized error recovery controls, power management and vibration tolerance for optimal performance and reliability in a 1- to 8-bay solution with 20 users or less. NAS error recovery controls optimize drive health by helping to ensure drives are not dropped from the NAS and sent into a RAID rebuild.
- Improved vibration tolerance and emission in multi-drive systems with dual-plane balance.
- Advanced power management supports multiple power profiles for low-power, 24×7 performance.
- Quiet drive operation enhances customer experience in living room or office environments.
Best-Fit Applications
- Home/SOHO NAS desktop towers
- Desktop RAID
- Backup and disaster recovery
- Print and file servers
- Multimedia server/storage
- Archival
- Virtualization
- Small-business file sharing
- Backup servers
Compatibility: This drive is compatible with any Computers and server that accepts 3.5"x1" (LFF) SATA hard drives.
SPECIFICATIONS | |
---|---|
Model Number | ST4000VN0001 |
Capacity | 4TB/4000GB |
Interface Options | SATA 6Gb/s |
Halogen Free | Yes |
NASWORKS | |
Number of Drive Bays Supported | 1 to 8 |
Dual-Plane Balance | Yes |
Vibration Tolerance for NAS | Yes |
NASWorks Error Recovery Control | Yes |
PERFORMANCE | |
Cache, Multisegmented (MB) | 128 |
SATA Transfer Rates Supported (Gb/s) | 6.0 |
Power-On or Standby to Ready (typical, sec) | <17 |
Max Sustained Data Transfer Rate OD (MB/s) | 180 |
VOLTAGE (PER DRIVE) | |
Voltage Tolerance, Including Noise (5V) | ±5% |
Voltage Tolerance, Including Noise (12V) | ±10% |
POWER MANAGEMENT (PER DRIVE) | |
Startup Current (12V, A max) | 2.0 |
Operating Average (W) | 4.8 |
Idle Average (W) | 3.95 |
Standby/Sleep Mode (typical, W) | 0.5 |
ENVIRONMENTAL (PER DRIVE) | |
Temperature(°C) Operating (ambient min) Operating (drive case max) Nonoperating ambient | 0 70 -40 to 70 |
Temperature Gradient, Operating/Nonoperating (°C per hour max) | 20/30 |
Shock Operating: 2ms (max, Gs) Nonoperating: 2ms (max, GS) | 80 300 |
Acoustics Idle (typical, bels) Operational (typical, bels) | 2.3 2.5 |
RELIABILITY (PER DRIVE) | |
Load/Unload | 600,000 |
Nonrecoverable Read Errors per Bits Read, Max | 1 per 10e14 |
Power-On Hours | 8760 |
Mean Time Between Failures (MTBF, hours) | 1,000,000 |
PHYSICAL (PER DRIVE) | |
Height (in/mm, max) | 1.028/26.11 |
Width (in/mm, max) | 4.0/101.6 |
Depth (in/mm, max) | 5.787/146.99 |
Weight (lb/g) | 1.345/610 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1SF178-500
Weight: 1.8 lb
Warranty: 5 Year Manufacturer
Brand New
The product is brand new.
5 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
