Seagate ST5000LM000 5TB SATA Hard Drive

Seagate Part #/MPN: ST5000LM000

DiscTech Item #: SGT-ST5000LM000-BN-2Y


$249.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$249.00

Capacity: 5TB

Speed: 5,400RPM

Interface Types: SATA

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: uP TO 140

Average Seek Time: 14.0/14.0

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 128MB

Voltage: 1.2V

Seagate Barracuda Compute ST5000LM000 5TB 2.5in 6Gbps 5.4K RPM 512 Serial ATA / SATA HDD - Brand New

Seagate Barracuda Compute ST5000LM000 5TB / 5000GB 2.5" 6Gb/s 5400 RPM 512 Serial Attached Technology Attachment Hard Disk Drive - Brand New

BARRACUDA COPUTE
Amazing Versatility. Unmatched Dependability.

Seagate brings over 20 years of trusted performance and reliability to the Seagate BarraCuda 2.5-inch HDDs – now available in capacities up to 5TB

Key Advantadages

  • Broadest 2.5-inch hard drive portfolio with up to 5TB capacity and both 7mm and 15mm factors suitable for a variety of compute applications
  • Thinnest and lighest 2.5-inch hard drive with up to 2TB storage in a 7mm z-height, providing seamless upgrades of thin light laptop and smaller form factor systems.
  • Fast data rates of up to 140MB/s enables superior PC and user experience and snappier file transfers>
  • 2.5-inch, 15mm z-height hard drives provide 3TB to 5TH in capacity, offering the highest-capacity 2.5-inch hard drives available for external or all-in one storage.
  • 15mm z-height enables slimmer all-in-one desktop PC drives while helping reduce system heat generation and vibration
  • Low startup current configuration for 3TB to 5TB drives enable use in legacy low-current systems like USB-2 external boxes, while simultaneously lowering power consumption
  • 5TB drives can store more than 1.25 million songs and 600 hours of HD video



Best-Fit Applications

  • Laptops
  • Mobile Storage
  • External storage systems
  • All-in-one PCs
  • Ultra-slim desktop PCs




Compatibility:

This drive is compatible with laptops that accept 2.5" x 15mm SFF SATA drives.

Barracuda Compute
Model NumberST5000LM000
Capacity5TB / 5000GB
Bytes per Sector (logical/physical)512 / 4096
Performance
InterfaceSATA 6Gb/s
Data Transfer Rate (MB/s)Up to 140 MB/s
Cache (MB)128
Spindle Speed (RPM)5400
Reliability/Data Integrity
Load/Unload Cycles600,000
Head-Rest MethodQuitStep Ramp Load
Nonrecoverable Read Errors per Bits Read, Max1 per 10E14
Power Management
Startup Current (+5V, A)1.2
Read/Write Power, Average (W)1.9/2.1
Idle Average (W)1.1
Environmental/Temperature
Operating Temperature (°C)0°C - 60°C
Nonoperating Temperature (°C)-40° - 70°C
2ms Operating Shock (Gs)300
1ms Nonoperating Shock (Gs)650
Acoustics, Idle, Typical (bels)2.6
Acoustics, Seek, Typical (bels)2.7
Physical
Height (mm/in)15/0.59
Width (mm/in, max)69.85/2.750
Depth (mm/in, max)100.35/3.951
Weight (g/lb)190/0.42
Special Features
Multi-Tier Caching TechnologyYes
Halogen FreeYes
RoHS ComplianceYes

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 0.5 lb

Warranty: 2 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

2 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
