Seagate Part #/MPN: ST6000VN001
DiscTech Item #: SGT-ST6000VN001-BN-5Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:5 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 6TB
Speed: 5,400RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 216
Average Seek Time: 4.06
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 256MB
Voltage: 1.8V
Seagate ST6000VN001 6TB 3.5inch Ironwolf NAS SATA HDD - Brand New
Seagate ST6000VN001 6TB 3.5inch Ironwolf NAS SATA HDD
The first 8TB drive optimized for mid-range NAS, server and scale-out cloud storage
- Enterprise-class reliability and performance for cloud-based storage and NAS applications in 1- to 16-bay enclosures
- 1.2 million hours MTBF for enterprise-class reliability
- 300TB-per-year workload rating for mid-range NAS and cloud-based storage
- 5400-RPM spindle speed performance
- Double the cache size—256MB multisegmented on 8TB capacity
- Dual-stage actuators to deliver precision seeks every time
- SATA 6Gb/s interface for easy integration into NAS and RAID rackmount systems
- RV sensor for sustained performance and reliability
Best-Fit Applications
- Cloud-based and NAS storage
- Backup and disaster recovery
- Multi-media server and storage
- File and print server sharing
- Archiving and cloud replication
- On-premise private cloud
- Tiered storage
- Remote access
- Virtualization
- Auxiliary storage
Compatibility:
This drive is compatible with any server that accepts 3.5inx1.0in SATA Drive.
| Enterprise NAS HDD | |
|---|---|
| Rescue Model Number | ST6000VN001 |
| Capacity | 6TB / 6000GB |
| Interface Options | SATA 6Gb/s |
| FEATURES | |
| RV Sensors | Yes |
| 5-Year Optons with Rescue Model only | Yes |
| Humidity Sensor | Yes |
| Super Parity | Yes |
| Low Halogen | Yes |
| AcuTrac Technology | Yes |
| Power Balance Technology | Yes |
| Hot-Plug Support | Yes |
| Cache, Multisegmented (MB) | 256 |
| RELIABILITY/DATA INTEGRITY | |
| Mean Time Between Failures (MTBF, hours) | 1.2M |
| Reliability Rating @ Full 24x7 Operation (AFR) | 0.63% |
| Nonrecoverable Read Errors per Bits Read | 1 sector per 10E15 |
| Power-On Hours per Year | 8760 (24x7) |
| Sector Size (Bytes per Logical Sector) | 512/4096 |
| PERFORMANCE | |
| Spindle Speed (RPM) | 7200 |
| Interface Acces Speed (Gb/s) | 6.0, 3.0, 1.5 |
| Max Sustained Transfer Rate OD (MB/s) | 216 |
| Average Latency (ms) | 4.16 |
| Interface Ports | Single |
| Rotation Vibration @ 1500 Hz (rad/s) | 12.5 |
| POWER CONSUMPTION | |
| Startup Current, Average (12V, A) | 1.8 |
| Idle Power, Average (W) | 6.9 |
| Operating Mode, Typical (W) | 9.0 |
| Standby/Sleep Mode, Typical (W) | 0.6 |
| Power Supply Requirements | +12V and +5V |
| ENVIRONMENTAL | |
| Temperature, Operating (°C) | 5 to 60 |
| Vibration, Nonoperating: 10Hz to 500Hz (Grms) | 5.0 |
| Shock, Operating, 2ms (Read/Write)(Gs) | 70/40 |
| Shock, Nonoperating, 1ms and 2ms(Gs) | 250 |
| PHYSICAL | |
| Height(in/mm, max) | 1.028/26.1 |
| Width(in/mm, max) | 4.010/101.85 |
| Depth(in/mm, max) | 5.878/147.0 |
| Weight(g/lb) | 1.720/780 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 2 lb
Warranty: 5 Year Manufacturer
Brand New
The product is brand new.
5 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
