Seagate ST6000VN001 6TB 3.5inch Ironwolf NAS HD

Seagate ST6000VN001 SATA Hard Drives Image 1 image
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

  • 5 Year ManufacturerWarranty
    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.

$170.00

Capacity:6TB
Speed:5.4K RPM
Interface Types:SATA
Form Factor:3.5" LFF Hard Drive
Electrical Interface:SATA 600 - 6Gbps
RAM:256MB

Description

Seagate ST6000VN001 6TB 3.5inch Ironwolf NAS SATA HDD - Brand New

Seagate ST6000VN001 6TB 3.5inch Ironwolf NAS SATA HDD

The first 8TB drive optimized for mid-range NAS, server and scale-out cloud storage

  • Enterprise-class reliability and performance for cloud-based storage and NAS applications in 1- to 16-bay enclosures
  • 1.2 million hours MTBF for enterprise-class reliability
  • 300TB-per-year workload rating for mid-range NAS and cloud-based storage
  • 5400-RPM spindle speed performance
  • Double the cache size—256MB multisegmented on 8TB capacity
  • Dual-stage actuators to deliver precision seeks every time
  • SATA 6Gb/s interface for easy integration into NAS and RAID rackmount systems
  • RV sensor for sustained performance and reliability

Best-Fit Applications

  • Cloud-based and NAS storage
  • Backup and disaster recovery
  • Multi-media server and storage
  • File and print server sharing
  • Archiving and cloud replication
  • On-premise private cloud
  • Tiered storage
  • Remote access
  • Virtualization
  • Auxiliary storage

Compatibility

This drive is compatible with any server that accepts 3.5inx1.0in SATA Drive.

Specifications

Enterprise NAS HDD
Rescue Model NumberST6000VN001
Capacity6TB / 6000GB
Interface OptionsSATA 6Gb/s
FEATURES
RV SensorsYes
5-Year Optons with Rescue Model onlyYes
Humidity SensorYes
Super ParityYes
Low HalogenYes
AcuTrac TechnologyYes
Power Balance TechnologyYes
Hot-Plug SupportYes
Cache, Multisegmented (MB)256
RELIABILITY/DATA INTEGRITY
Mean Time Between Failures (MTBF, hours)1.2M
Reliability Rating @ Full 24x7 Operation (AFR)0.63%
Nonrecoverable Read Errors per Bits Read1 sector per 10E15
Power-On Hours per Year8760 (24x7)
Sector Size (Bytes per Logical Sector)512/4096
PERFORMANCE
Spindle Speed (RPM)7200
Interface Acces Speed (Gb/s)6.0, 3.0, 1.5
Max Sustained Transfer Rate OD (MB/s)216
Average Latency (ms)4.16
Interface PortsSingle
Rotation Vibration @ 1500 Hz (rad/s)12.5
POWER CONSUMPTION
Startup Current, Average (12V, A)1.8
Idle Power, Average (W)6.9
Operating Mode, Typical (W)9.0
Standby/Sleep Mode, Typical (W)0.6
Power Supply Requirements+12V and +5V
ENVIRONMENTAL
Temperature, Operating (°C)5 to 60
Vibration, Nonoperating: 10Hz to 500Hz (Grms)5.0
Shock, Operating, 2ms (Read/Write)(Gs)70/40
Shock, Nonoperating, 1ms and 2ms(Gs)250
PHYSICAL
Height(in/mm, max)1.028/26.1
Width(in/mm, max)4.010/101.85
Depth(in/mm, max)5.878/147.0
Weight(g/lb)1.720/780
Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 2 lb

Warranty: 5 Year Manufacturer

Condition

Brand New

Warranty

5 Year Manufacturer Warranty
