Dell Enterprise Plus 33KFP / Seagate ST600MM0088 600GB 2.5" 10K SAS HDD
- New PullCondition Levels Explained
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
- In Stock:1Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 600GB |
| Speed: | 10K RPM |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SAS-3 12Gbps |
| RAM: | 128MB |
Description
Dell Enterprise Plus 33KFP / Seagate ST600MM0088 600GB 2.5" 12Gbps 10K RPM eMLC SAS HDD - New Pull OEM
Dell Enterprise Plus 33KFP / Seagate ST600MM0088 600GB 2.5" 12Gbps 10K RPM eMLC SAS HDD - New Pull OEM
ALT PN: 1FD200-157
DPN: 033KFP, 33KFP
High-Performing, Up to 600GB, Small Form Factor 10K Hard Drive
- Stores twice the amount of Tier 1 data over previous generation, without increasing drive count, in 2.5-inch form factor
- Enables faster transaction processing, which can result in increased revenue generation and improved customer satisfaction
- Latest 12Gb/s SAS interface for improved scalability
- Industry’s highest MTBF at 2.0M hours
- Support for all drive formats, including 512 Native, 512 Emulation and 4K Native
- Provides up to 18% improvement in SDR performance over prior generation
- SAS-based Protection Information (PI) helps protect against inadvertent data change.
Best-Fit Applications
- High-performance Tier 1 enterprise servers
- Blade, rack and tower servers hosting transaction-based applications
- Power- and space-constrained data centers
- Compliance and data security initiatives
Compatibility
This drive is compatible with any server that accepts 2.5"x15mm (SFF) SAS drives.
Specifications
| SPECIFICATIONS | |
|---|---|
| Standard Model | ST600MM0088 |
| Capacity | 600GB |
| PERFORMANCE | |
| Spindle Speed (RPM) | 10K |
| Average Latency (ms) | 2.9 |
| Sustained Transfer Rate (Outer to Inner Diameter, MB/s) | 215 to 108 |
| Cache, Multisegmented (MB) | 128 |
| CONFIGURATION/RELIABILITY | |
| Disks | 2 |
| Heads | 3 |
| Interface | 12Gb/s SAS |
| External Transfer Rate (MB/s) | 1200 |
| Nonrecoverable Read Errors per Bits Read | 1 per 10e16 |
| Annualized Failure Rate (AFR) | 0.44% |
| TURBOBOOST ENHANCED CACHE FEATURE | |
| I/O Acceleration and Response Time Optimization | - |
| NAND Flash Type | - |
| NAND Flash Size | - |
| Intelligent NAND Endurance Management | - |
| POWER MANAGEMENT | |
| Typical Op (A) +5V/+12V | 0.44/0.41 |
| Typical Operation (W) | 7.15 |
| Power Idle (W) | 3.91 |
| Performance Efficiency Index (Idle W/GB) | 0.0065 |
| ENVIRONMENTAL | |
| Temperature, Operating (°C) | 5 to 55 |
| Temperature, Nonoperating (°C) | -40 to 70 |
| Shock, Operating: 11ms (Gs) | 40 |
| Shock, Nonoperating: 2ms (Gs) | 400 |
| Acoustics Idle (bels—sound power) | 3.1 |
| Vibration, Operating: <500Hz (Gs) | 0.5 |
| Vibration, Nonoperating: <500Hz (Gs) | 3 |
| PHYSICAL | |
| Height (in/mm, max) | 0.591/15.00 |
| Width (in/mm, max) | 2.760/70.10 |
| Depth (in/mm, max) | 3.955/100.45 |
| Weight (lb/kg) | 0.417/0.189 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1FD200-157 033KFP 33KFP
Weight: 1.5 lb
Warranty: 1 Year DiscTech
Condition
New Pull
Warranty
1 Year DiscTech Warranty
