Seagate ST8000AS0002 8000GB SATA Hard Drive
- Brand NewCondition Levels Explained
The product is brand new.
- Special Order - Call for Lead TimeSpecial Order - Call for Lead Time
This item has a variable lead time for fulfilment. Please call us to discuss. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
- 3 Year ManufacturerWarrantyProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
$275.00
| Capacity: | 8TB |
| Speed: | 5.9K RPM |
| Interface Types: | SATA |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SATA 600 - 6Gbps |
| RAM: | 128MB |
Description
Seagate Archive v2 ST8000AS0002 8000GB 3.5" 6.0 Gbps 5900 RPM Serial ATA Hard Disk Drive - Brand New
Alt MPN: 1NA17Z-002, 1NA17Z-003, 1N917Z-990
Archive HDD
Supersized capacity, energy efficiency and lowest TCO
- Seagate brings over 30 years of trusted storage reliability to the growing need for online long-term storage.
- Industry’s best cost/GB/watt 8TB hard drive.
- Engineered for 24×7 workloads of 180TB per year.
- Drive down costs with up to 1.33TB-per-disk hard drive technology.
- SATA 6Gb/s interface optimizes burst performance.
- Seagate AcuTrac™ servo technology delivers dependable performance.
- Free Seagate DiskWizard™ software allows you to install 5TB, 6TB and 8TB hard drives in Windows without UEFI BIOS.
Best-Fit Applications
- Cost-effective online archiving
- Object storage
- Big Data cold storage
- Cloud active archive
- Web-scale archiving
Compatibility
This drive is compatible with any server that accepts 3.5" x 1.0" (LFF) SATA drives.
Specifications
| SPECIFICATIONS | |
|---|---|
| Model Number | ST8000AS0002 |
| Product Version | Archive HDD v2 |
| Interface Option | SATA 6Gb/s NCQ |
| Capacity | 8TB/8000GB |
| PERFORMANCE | |
| Cache, Multisegmented (MB) | 128 |
| SATA Transfer Rates Supported (Gb/s) | 6.0/3.0/1.5 |
| Average Data Rate, Read/Write (MB/s) | 150 |
| Max Sustained Data Rate, OD Read (MB/s) | 190 |
| CONFIGURATION/ORGANIZATION | |
| Heads/Disks | 12/6 |
| Bytes per Sector | 4096 |
| SMR Technology, Drive-Managed | Yes |
| VOLTAGE | |
| Voltage Tolerance, Inc. Noise (5V) | +/-5% |
| Voltage Tolerance, Inc. Noise (12V) | +/-10% |
| RELIABILITY/DATA INTEGRITY | |
| Load/Unload Cycles | 300,000 |
| Nonrecoverable Read Errors per Bits Read, Max | 1 per 10e14 |
| Workload Rate Limit (TB/year) | 180 |
| Power-On Hours | 8760 (24x7) |
| Mean Time Between Failures (MTBF) (hours) | 800K |
| POWER MANAGEMENT | |
| Startup Power (A) | 2.0 |
| Operating Mode, Typical (W) | 7.5 |
| Idle Average (W) | 5.0 |
| Standby Mode (W) | <1.0 |
| Sleep Mode (W) | <1.0 |
| ENVIRONMENTAL | |
| Temperature -Operating (ambient min °C) -Operating (drive case max °C) -Nonoperating (ambient °C) | 0 60 -40 to 70 |
| Halogen Free | Yes |
| RoHS Compliance | Yes |
| PHYSICAL | |
| Height (mm/in) | 26.11/1.028 |
| Width (mm/in) | 101.6/4.0 |
| Depth (mm/in) | 146.99/5.787 |
| Weight (g/lb) | 780/1.72 |
| POWER MANAGEMENT | |
| Seagate AcuTrac Technology | Yes |
| In-Drive Diagostics (IDD) | Yes |
| Seagate PowerChoice Technology | Yes |
| Deferred SATA Activation | Yes |
| Timestamp | Yes |
| Seagate Instant Secure Erase | Optional |
| SeaTools Diagnostics Software | Yes |
| S.M.A.R.T. Drive Monitoring and Reporting | Yes |
| Hotplug Operation (per SATA Rev. 3.0 Specifications) | Yes |
| Enterprise CS Phone Support | Yes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1NA17Z-002 1NA17Z-003 1N917Z-990
Weight: 1.8 lb
Warranty: 3 Year Manufacturer
Condition
Brand New
Warranty
3 Year Manufacturer Warranty
