Seagate Part #/MPN: ST8000NM0075
DiscTech Item #: SGT-ST8000NM0075-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 8TB
Speed: 7,200RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: Up to 237
Average Seek Time: 4.16
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
On-Board Cache: 256MB
Seagate ST8000NM0075 8TB 3.5 inches 12Gbps 7.2K RPM Enterprise SAS 512E HDD – Refurbished
Capacity-Optimized Enterprise Hard Drive for Bulk-Data Applications
- 8TB, 3.5-inch enterprise drive with industry-leading 6-disk technology, resulting in 33% more storage in the same storage slot
- Advanced Write Caching feature to utilize enhanced algorithms, resulting in the industry’s highest nearline storage workload performance efficiencies—100% performance improvement in random writes over last-generation drive
- Widely accepted, proven ninth-generation conventional perpendicular recording technology for reliable access to unstructured data in bulk storage applications
- SAS 12Gb/s interfaces in industry-standard advanced formats for easy integration into replicated and RAID multi-drive storage servers and systems
- State-of-the-art cache, on-the-fly error-correction algorithms, super parity and end-to-end SAS-based data integrity for accurate data storage
- Industry-leading rotational vibration tolerance design helps ensure consistent performance in dense multi-drive systems
- Engineered for 24×7 workloads of 550TB/yr—10× that of desktop drives
- Robust performance with dual processors, ramp load technology, top-cover attached motor and humidity sensor for optimum performance in all chassis
- Seagate SeaTools™ diagnostic software to provide drive self-tests ensuring unnecessary downtime and maximizing TCO
Best-Fit Applications
- Hyperscale applications/cloud data centers with replicated storage
- Massive scale-out data centers and big data analytics
- High-capacity density RAID storage
- Mainstream enterprise external storage arrays (SAN, NAS, DAS)
- Distributed file systems, including Hadoop and Ceph
- Enterprise backup and restore—D2D, virtual tape
- Centralized surveillance
Alt. PN: 1RM212
Compatibility:
This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SAS drives.
Product Specifications | |
---|---|
Model Number (512 Emulation) | ST8000NM0075 |
Interface Options | SAS 12Gb/s |
Capacity | 8TB/8000GB |
Features | |
Protection Information (T10 DIF) | Yes |
Humidity Sensor | Yes |
Super Parity | Yes |
Low Halogen | Yes |
PowerChoice Technology | Yes |
Power Balance Technology | Yes |
Cache, Multisegmented (MB) | 256 |
Advanced Write Caching (2M Internal NOR Flash) | Yes |
Reliability/Data Integrity | |
Mean Time Between Failures (MTBF, hours) | 2.0M |
Reliability Rating @ Full 24x7 Operation (AFR) | 0.44% |
Nonrecoverable Read Errors per Bits Read | 1 sector per 10E15 |
Power-On Hours per Year | 8760 (24x7) |
Sector Size (Bytes per Logical Sector) | 512, 520, 528 and 4096 |
Performance | |
Spindle Speed (RPM) | 7200 |
Interface Access Speed (Gb/s) | 12.0, 6.0, 3.0 |
Random Read/Write -16QD WCE (IOPS) | 164/342 |
Max. Sustained Transfer Rate OD (MB/s) | up to 237 |
Average Latency (ms) | 4.16 |
Interface Ports | Dual |
Rotation Vibration @ 1500 Hz (rad/s) | 12.5 |
Power Consumption | |
Idle Power, Average (W) | 9 |
Typical Operating, Random Read (W) | <10 |
Power Supply Requirements | +12V and +5V |
Environmental | |
Temperature, Operating (°C) | 5 to 60 |
Vibration, Nonoperating: 10Hz to 500Hz (Grms) | 5.0 |
Shock, Operating, 2ms (Read/Write)(Gs) | 70/40 |
Shock, Nonoperating, 1ms and 2ms (Gs) | 300 |
Physical | |
Height (in/mm, max) | 1.028/26.1 |
Width (in/mm, max) | 4.010/101.85 |
Depth (in/mm, max) | 5.878/147 |
Weight (g/lb) | 780/1.720 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1RM212
Weight: 1.8 lb
Warranty: 1 Year DiscTech
