Seagate Part #/MPN: ST91000642SS
DiscTech Item #: SGT-ST91000642SS-BN-OE-DEP
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 1TB
Speed: 7,200RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Encryption/SED Supported
Sector Size: 512 / 512e
Sustained Throughput: 115
Average Seek Time: 8.5/9.5
Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps
On-Board Cache: 64MB
Seagate Constellation.2 ST91000642SS 1TB 2.5in 6.0 Gbps 7200 RPM Self-Encrypting Serial-Attached SCSI Dell Enterprise Plus Hard Disk Drive - Brand New OEM
Alt. MPN: 9XU268-257
Dell Enterprise Plus PNs: 0MR5PD MR5PD
Constellation.2™ Design Small and Deliver BIG—2.5-Inch, Eco-Friendly Nearline Drive
Key Advantages
- Second generation of the first 2.5-inch, mainstream capacity, 15mm z-height, nearline enterprise drive for space-constrained data centers
- Choose 6Gb/s SAS for data integrity, scalability and fast data access.
- The industry’s highest-reliability 7200-RPM drive, designed for 24×7 operation with MTBF of 1.4M hours and AFR of 0.62%
- Enterprise-class firmware features and best-in-class rotational vibration tolerance maximize system availability and performance.
- Lowest operating power (under 6.4W) and enhanced PowerChoice™ options for additional power savings during slow or idle periods; Workload Management™ technology helps systems keep drives cool.
- Self-Encrypting Drive (SED) option (AES-256) cuts IT drive retirement costs while securely protecting data where it lives—on the drive.
- FIPS 140-2 Validated™ drives protect Sensitive but Unclassified and Protected class data.
Best-Fit Applications
- Storage-hungry business applications
- Storage area networks (SAN) and network attached storage (NAS)
- Maximum-capacity servers and blade servers
- Rich media content storage
- Enterprise backup and restore—D2D, virtual tape
- Cloud computing
Compatibility:
This drive is compatible with any server that accepts 2.5"x15mm (SFF) SAS drives.
| SPECIFICATIONS | |
|---|---|
| Standard Model Number | ST91000642SS |
| Dell Part Number | 0MR5PD MR5PD |
| SED (AES-256) FIPS 140-2 | Yes |
| Drive Capacity | 1TB/1000GB |
| Drive Interface | SAS 6Gb/s |
| Form Factor | 2.5 Inch |
| FEATURES | |
| Protection Information | Yes |
| Low Halogen | Yes |
| RELIABILITY/DATA INTEGRITY | |
| Mean Time Between Failure (BTBF, hours) | 1.4 million |
| Reliability Rating @ Full 24x7 Operation (AFR) | 0.62% |
| Non=Recoverable Read Errors per Bits Read | 1 sector per 10e15 |
| Power-On Hours per Year | 8760 |
| Bytes per Sector | 512, 520, 528 |
| PERFORMANCE | |
| Spindle Speed (RPM) | 7200 |
| Cache, Multi-Segmented (MB) | 64 |
| Interface Access Speed (Gb/s) | 6.0, 3.0, 1.5 |
| Max. Sustained Transfer Rate (MB/s) | 115 |
| Seek Time, Average Read/Write (ms) | 8.5/9.5 |
| Average Latency (ms) | 4.16 |
| Interface Ports | Dual |
| RV Tolerance (rad/s to 1800Hz) | 16 |
| POWER MANAGEMENT | |
| Idle Power (W) | 3.85 |
| Typical, Random Read (W) | 6.4 |
| Power Supply Requirements | +12V and +5V |
| PowerChoice Technology (W) | As low as 1.87 |
| ENVIRONMENTAL | |
| Temperature, Operating (°C) | 5 TO 60 |
| Vibration, Operating, <400Hz (Gs) | 0.5 |
| Vibration, Non-Operation, <500Hz (Gs) | 3.0 |
| Shock, Operation, 2ms (Gs) | 70 |
| Shock, Non-Operating, 1ms and 2ms (Gs) | 400 |
| Acoustics, Typical Idle (bels) | 2.2 |
| Acoustics, Typical Seek (bels) | 2.8 |
| PHYSICAL | |
| Height (mm/in) | 15.00/0.591 |
| Width (mm/in) | 70.10/2.760 |
| Depth (mm/in) | 100.45/3.955 |
| Weight (g/lb) | 200/0.441 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 0MR5PD MR5PD 9XU268-257
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
