Seagate Savvio ST9600205FC Fibre Channel Hard Drive

Seagate Part #/MPN: ST9600205FC

DiscTech Item #: SGT-ST9600205FC-BN-OE


$139.00
$139.00

Enterprise Grade

Capacity: 600GB

Speed: 10,000RPM

Interface Types: Fibre Channel - Internal - Arbitrated Loop ASA II

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 168

Average Seek Time: 3.4 / 3.8

Electrical Interface: FC-AL - 4Gbps

On-Board Cache: 64MB

Seagate Savvio 10K.5 ST9600205FC 600GB 10K 6Gbps SFF Fibre Channel Hard Drive - Brand New

The Seagate® Savvio® 10K.5 hard drive enables OEMs, system builders and data centers to:

  • Improve storage efficiency
  • Ease capacity, interface and form factor transitions
  • Ensure data integrity and protection throughout the storage process even if the device is lost or stolen

Key Features and Benefits

  • Delivers the highest-capacity in a 2.5-inch, 10K-RPM hard drive (up to 900GB) to manage more data without increasing the number of drives
  • First SFF drive to offer four capacity points on a single platform
  • Industry-leading 0.44% AFR for field-proven reliability
  • Improves performance for faster data storage and access
  • Reduces power consumption and enables green IT initiatives
  • PowerChoice™ technology for T10-compliant power management enables IT organizations to tailor systems for performance and power consumption
  • Reduces system design, qualification and inventory costs for OEMs
  • Enables data centers to better manage hard drive transitions
  • Protection Information protects against inadvertent data change¹
  • Optional Self-Encrypting Drive (SED) models² help companies be compliant with corporate and federal data security mandates and protect data-at-rest throughout the life of the storage device should the device be lost, stolen, and/or retired
  • Seagate Unified Storage architecture reduces system complexity and operating costs by converging disparate interfaces, form factors and security standards

¹ Protection Information (Pl) feature requires Pl-compliant host or controller support.


Compatibility:

This drive is compatible with any server that accepts small form factor (SFF) Fibre Channel hard drives

Specifications
Model number ST9600205FC
Model Name Savvio 10K.5
Formatted Capacity 600 Gbytes
Rotational Speed 10,000 rpm
Default Buffer (cache) Size 64 Mbytes
Performance
External (I/O) Transfer Rate (max) 600 MBytes/sec
Sustained Transfer Rate


168 MBytes/sec

Average Seek Time, Read 3.4 msec typical
Average Seek Time, Write 3.8 msec typical
Track-to-Track Seek, Read 0.2 msec typical
Track-to-Track Seek, Write 0.4 msec typical
Average Latency 3 msec
Physical
Form Factor(width) 2.5-inch
Form Factor(height) .583-inch
Height 15.00 mm
Width 70.10 mm
Length 100.45mm
Weight 0.215 kg
Electrical
Power (amps +5v/+12)0.46/0.45
Environmental
Max Operating Shock (2-msec) 40 Gs
Max Nonoperating Shock (2-msec) 400 Gs
Operating Vibration (max) .5 Gs
Nonoperating Vibration (max) 3.0 Gs
Operating Temperature (max) 55 deg C
Operating Temperature (min) 5 deg C
Nonoperating Temperature (max) 70 deg C
Nonoperating Temperature (min) -40 deg C
Reliability
Nonrecoverable Read Errors 1 per 10^16 bits read
Supports S.M.A.R.T.Yes

Click here to view the manufacturer's item description/brochure

Weight: 1 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
