Synology DiskStation DS720-PLUS NAS Server

Synology Part #/MPN: DS720-PLUS

DiscTech Item #: SYN-DS720-PLUS-BN-3Y

  • Special Order - Call for Lead Time
    Special Order - Call for Lead Time

    This item has a variable lead time for fulfilment. Please call us to discuss. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.


Interface Types: SATA, eSATA External, USB 2.0, USB 3.0 3.1 3.2, Ethernet RJ45

Electrical Interface: Ethernet Gigabit - 1Gbps

On-Board Cache: 1GB

Bays/Ports/Slots: 2

Wattage/VA: 72W

Voltage: 110-240V Multi

Synology DiskStation DS720+ 2-bay SATA Quad Core NAS Server - Brand New

Synology DiskStation DS720+ Network Attached Storage Server includes...

  • 2x M.2 NVMe Slots
  • 2x USB 3.0 ports
  • 1x eSATA port
  • 2x Ethernet RJ45 1Gb LAN ports  (with Link Aggregation / Failover support)
  • Intel Quad Core J4125 2.7Ghz
  • 2GB Ram
  • 2 drive bays, expandable to 7 when paired with an expansion unit
  • accepts 3.5" and 2.5" SATA hard drives and 2.5" SATA solid state drives.

DiskStation DS720+ Robust & scalable NAS server for business
DS720+ provides high-performance and a straightforward approach to data-management and protection, letting you get a head start for your business. Whenever you're ready, upgrade capacity easily by adding an expansion unit.

Four (QUAD) core CPU brings high performance
A more powerful CPU speeds up computing-intensive applications. The new 4-core processor boosts photo indexing, database response times, and web PHP response efficiency. Easily categorize your photo memories, smoothly manage files across computers and mobile devices, and enjoy blazing fast web applications.

SuperSpeed USB 3.0 accelerates transfer rates
DS720+ optimizes your working experience by enabling faster and more efficient data transfers. When backing up to external hard drives, DS720+ comes with Super-Speed USB 3.0 ports providing ten times the transfer speed of its predecessor, reducing the time to transfer data to external hard drives.

Dual LAN with failover and Link Aggregation support
Coming with dual LAN ports with failover and Link Aggregation support, DS720+ ensures continual network service in case of LAN connection failure, avoiding possible disruption occurrences. Link Aggregation with trunking enhances connection speeds beyond the limits of any one single cable or port.

Hassle-free scalability up to 32TB (internal, 108TB with expansion)
DS720+ offers hassle-free scalability up to seven drives with Synology DX517 expansion unit when the storage capacity of DS720+ nears its limit. Connected via eSATA with specially designed locking devices, DX570 expands storage capacity up to a maximum of 108TB with minimal time-investment in setup and configuration.

Award winning OS - DiskStation Manager
Synology DiskStation Manager (DSM) is a sleek, browser-based operating system running on every DiskStation and RackStation, which makes managing your Synology NAS a breeze. Featuring an intuitive user interface, DSM makes accessing and sharing your data smarter and simpler. Synology's Package Center lets you download and install useful add-on packages designed specifically for individual or business needs, meaning you can enjoy more entertainment in your life or better productivity at work.

Seamless storage solution for virtualization environments
DS720+ provides seamless storage solutions for virtualization environments, including VMware, Citrix, and Microsoft Hyper-V. With VMware vSphere® 5 & VAAI integration, DS720+ helps offload specific storage operations and optimizes computation power in VMware environments. Windows ODX support speeds up data manipulation as the data transfer is offloaded. iSCSI also lets SMB users consolidate storage into data center storage arrays while providing hosts with the illusion of locally-attached disks.

Compatibility: Any Network Switch or router with RJ45 port

Model NumberDS720+ DS720-PLUS
CPU ModelIntel Celeron J4125
CPU FrequencyQuad Core 2.7 GHz
Floating PointYes
System Memory2 GB DDR4
Drive Bay(s)2
Maximum Drive Bays with Expansion Unit7
Compatible Drive Type3.5" SATA III / SATA II HDD
NVMe M2. 2280 SSD
Maximum, Internal Raw Capacity32 TB (16 TB HDD x 2) (Capacity may vary by RAID types)
Hot Swappable DriveYes
M.2 slots2
USB 3.0 Port2
eSATA Port1
Internal DrivesEXT4
External DrivesEXT4
Size (Height x Width x Depth)157 mm x 103.5 mm x 232 mm
Weight1.69 kg
RJ-45 1GbE LAN Port2 (with Link Aggregation / Failover support)
Wake on LAN/WANYes
System Fan92 mm x 92 mm x 1 pcs
Fan Speed ModeCool Mode
Quiet Mode
Wireless Support (dongle)Yes
Noise Level19.2 dB(A)
Power RecoveryYes
Scheduled Power On/OffYes
Power Supply Unit / Adapter72W
AC Input Power Voltage100V to 240V AC
Power Frequency50/60 HZ, Single Phase
Power Consumption30.72 W (Access)
17.88 W (HDD Hibernation)
British Thermal Unit104.82 BTU/hr (Access)
61.01 BTU/hr (HDD Hibernation)
Operating Temperature5°C to 35°C
(40°F to 95°F)
Storage Temperature-10°C to 70°C
(15°F to 155°F)
Relative Humidity5% to 95% RH
CertificationFCC Class B
CE Class B
BSMI Class B

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: DS720+

Weight: 4 lb

Warranty: 3 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

3 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
