Synology Part #/MPN: DS720-PLUS
DiscTech Item #: SYN-DS720-PLUS-BN-3Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:3 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Special Order - Call for Lead TimeSpecial Order - Call for Lead Time
This item has a variable lead time for fulfilment. Please call us to discuss. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Interface Types: SATA, eSATA External, USB 2.0, USB 3.0 3.1 3.2, Ethernet RJ45
Electrical Interface: Ethernet Gigabit - 1Gbps
On-Board Cache: 1GB
Bays/Ports/Slots: 2
Wattage/VA: 72W
Voltage: 110-240V Multi
Synology DiskStation DS720+ 2-bay SATA Quad Core NAS Server - Brand New
Synology DiskStation DS720+ Network Attached Storage Server includes...
- 2x M.2 NVMe Slots
- 2x USB 3.0 ports
- 1x eSATA port
- 2x Ethernet RJ45 1Gb LAN ports (with Link Aggregation / Failover support)
- Intel Quad Core J4125 2.7Ghz
- 2GB Ram
- 2 drive bays, expandable to 7 when paired with an expansion unit
- accepts 3.5" and 2.5" SATA hard drives and 2.5" SATA solid state drives.
DiskStation DS720+ Robust & scalable NAS server for business
DS720+ provides high-performance and a straightforward approach to data-management and protection, letting you get a head start for your business. Whenever you're ready, upgrade capacity easily by adding an expansion unit.
Four (QUAD) core CPU brings high performance
A more powerful CPU speeds up computing-intensive applications. The new 4-core processor boosts photo indexing, database response times, and web PHP response efficiency. Easily categorize your photo memories, smoothly manage files across computers and mobile devices, and enjoy blazing fast web applications.
SuperSpeed USB 3.0 accelerates transfer rates
DS720+ optimizes your working experience by enabling faster and more efficient data transfers. When backing up to external hard drives, DS720+ comes with Super-Speed USB 3.0 ports providing ten times the transfer speed of its predecessor, reducing the time to transfer data to external hard drives.
Dual LAN with failover and Link Aggregation support
Coming with dual LAN ports with failover and Link Aggregation support, DS720+ ensures continual network service in case of LAN connection failure, avoiding possible disruption occurrences. Link Aggregation with trunking enhances connection speeds beyond the limits of any one single cable or port.
Hassle-free scalability up to 32TB (internal, 108TB with expansion)
DS720+ offers hassle-free scalability up to seven drives with Synology DX517 expansion unit when the storage capacity of DS720+ nears its limit. Connected via eSATA with specially designed locking devices, DX570 expands storage capacity up to a maximum of 108TB with minimal time-investment in setup and configuration.
Award winning OS - DiskStation Manager
Synology DiskStation Manager (DSM) is a sleek, browser-based operating system running on every DiskStation and RackStation, which makes managing your Synology NAS a breeze. Featuring an intuitive user interface, DSM makes accessing and sharing your data smarter and simpler. Synology's Package Center lets you download and install useful add-on packages designed specifically for individual or business needs, meaning you can enjoy more entertainment in your life or better productivity at work.
Seamless storage solution for virtualization environments
DS720+ provides seamless storage solutions for virtualization environments, including VMware, Citrix, and Microsoft Hyper-V. With VMware vSphere® 5 & VAAI integration, DS720+ helps offload specific storage operations and optimizes computation power in VMware environments. Windows ODX support speeds up data manipulation as the data transfer is offloaded. iSCSI also lets SMB users consolidate storage into data center storage arrays while providing hosts with the illusion of locally-attached disks.
Compatibility: Any Network Switch or router with RJ45 port
| SPECIFICATIONS | |
|---|---|
| Model Number | DS720+ DS720-PLUS |
| CPU | |
| CPU Model | Intel Celeron J4125 |
| CPU Frequency | Quad Core 2.7 GHz |
| Floating Point | Yes |
| MEMORY | |
| System Memory | 2 GB DDR4 |
| STORAGE | |
| Drive Bay(s) | 2 |
| Maximum Drive Bays with Expansion Unit | 7 |
| Compatible Drive Type | 3.5" SATA III / SATA II HDD 2.5" SATA III / SATA II HDD 2.5" SATA III / SATA II SSD NVMe M2. 2280 SSD |
| Maximum, Internal Raw Capacity | 32 TB (16 TB HDD x 2) (Capacity may vary by RAID types) |
| Hot Swappable Drive | Yes |
| EXTERNAL PORTS | |
| M.2 slots | 2 |
| USB 3.0 Port | 2 |
| eSATA Port | 1 |
| USBCopy | Yes |
| FILE SYSTEM | |
| Internal Drives | EXT4 |
| External Drives | EXT4 EXT3 FAT NTFS HFS+ |
| APPEARANCE | |
| Size (Height x Width x Depth) | 157 mm x 103.5 mm x 232 mm |
| Weight | 1.69 kg |
| OTHERS | |
| RJ-45 1GbE LAN Port | 2 (with Link Aggregation / Failover support) |
| Wake on LAN/WAN | Yes |
| System Fan | 92 mm x 92 mm x 1 pcs |
| Fan Speed Mode | Cool Mode Quiet Mode |
| Wireless Support (dongle) | Yes |
| Noise Level | 19.2 dB(A) |
| Power Recovery | Yes |
| Scheduled Power On/Off | Yes |
| Power Supply Unit / Adapter | 72W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 HZ, Single Phase |
| Power Consumption | 30.72 W (Access) 17.88 W (HDD Hibernation) |
| British Thermal Unit | 104.82 BTU/hr (Access) 61.01 BTU/hr (HDD Hibernation) |
| ENVIRONMENT TEMPERATURE | |
| Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -10°C to 70°C (15°F to 155°F) |
| Relative Humidity | 5% to 95% RH |
| Certification | FCC Class B CE Class B BSMI Class B |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: DS720+
Weight: 4 lb
Warranty: 3 Year Manufacturer
Brand New
The product is brand new.
3 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
