Synology DiskStation DX513 NAS Expansion Unit

Synology Part #/MPN: DX513

DiscTech Item #: SYN-DX513-BN-3Y


$599.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$599.00

Interface Types: SATA, eSATA External

Form Factor: 3.5inx1.0in LFF Hard Drive

Electrical Interface: SATA 600 - 6.0Gbps

Bays/Ports/Slots: 5

Wattage/VA: 200W

Voltage: 110-240V Multi

Synology DiskStation DX513 5-Bay SATA NAS Expansion Unit - Diskless - Brand New

Synology DiskStation DX513 Expansion Unit includes...

  • 1x eSATA port
  • 5 drive bays
  • accepts 3.5" and 2.5" SATA hard drives and 2.5" SATA solid state drives.

DX513 Expansion Unit for Increasing Capacity of the Synology DiskStation
Synology® DX513 delivers an effortless solution for volume expansion and data backup for selected Synology DiskStation models. The DX513 seamlessly scales up the storage capacity of the DiskStation by additional 5 hard drives on-the-fly when connected directly to an expansion cable.

Highlights

  • Online Volume Expansion
  • Dedicated Local Backup Solution
  • Reliable Plug-n-use Design
  • Hot-swappable HDD Design
  • Auto power on/off with DiskStation Models

Volume Expansion & Backup
When running out of hard drive capacity on the Synology DiskStation, Synology DX513 provides an easy way to immediately scale capacity by additional 5 hard drives. The RAID volume on the Synology DiskStation can be expanded directly without having to reformat the existing hard drives, ensuring the Synology DiskStation continues its service during the capacity expansion.


Compatibility:

Supported models ...

DS1815+DS1813+DS1812+DS1515+
DS1513+DS1512+DS1511+DS1010+
DS716+DS713+DS712+DS710+
DS1515DS715NVR216

Some models support independent volumes creation only.

SPECIFICATIONS
Model NumberDX513
STORAGE
Drive Bay(s)5
Compatible Drive Type3.5in SATA III / SATA II HDD
2.5in SATA III / SATA II HDD
2.5in SATA III / SATA II SSD
Maximum Internal Raw Capacity40 TB (8 TB HDD x 5)
(Capacity may vary by RAID types)
Hot Swappable DriveYes
RAID Management through Synology DSMYes
EXTERNAL PORTS
eSATA port1
APPEARANCE
Size (Height x Width x Depth)157 mm x 248 mm x 233 mm
Weight3.91 kg/ 8.62 lb
POWER
Power RecoverySynchronized with the Synology DiskStation
Power Supply Unit / Adapter200W
AV Input Power Voltage100V to 240V AC
Power Frequency50/60 Hz, Single Phase
Power Consumption
  • 45.1 W (Access)
  • 16.5 W (HDD Hibernation)
  • 2 W (Deep Sleep)
  • British Thermal Unit
  • 153.89 BTU/hr (Access)
  • 56.30 BTU/hr (HDD Hibernation)
  • 6.82 BTU/hu (Deep Sleep)
  • OTHERS
    System Fan80 mm x 80 mm x 2 pcs
    Easy Replacement System FanYes
    Noise Level21.5 dB(A)
    Certification
  • FCC Class B
  • CE Class B
  • BSMI Class B

  • Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Weight: 10 lb

    Warranty: 3 Year Manufacturer

    Brand New

    Condition Levels Explained

    The product is brand new.

    3 Year Manufacturer Warranty

    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.
