Synology RackStation RS10613XS-PLUS NAS Server

Synology Part #/MPN: RS10613XS-PLUS

DiscTech Item #: SYN-RS10613XS-PLUS-BN-5Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Interface Types: SAS Serial Attached SCSI, SATA, USB 2.0, Ethernet RJ45

Encryption/SED Supported

Electrical Interface: Ethernet Gigabit - 1Gbps

On-Board Cache: 8GB

Bays/Ports/Slots: 10

Wattage/VA: 400W

Voltage: 110-240V Multi

Synology RackStation RS10613xs+ 10-bay SAS / SATA Quad Core AES-NI NAS Server - Brand New

Synology RackStation RS10613xs+ Network Attached Storage Server includes...

  • 4x USB 2.0 port
  • 4x Ethernet RJ45 1Gb LAN ports
  • Intel Quad Core 3.3 GHz
  • 8GB DDR3 ECC Ram, expandable up to 32GB (8 GB x 4)
  • 10 drive bays, expandable to 106 when paired with an expansion unit
  • accepts 3.5" and 2.5" SATA hard drives and 2.5" SATA solid state drives along with 3.5” and 2.5” SAS hard drives and 2.5” SAS solid state drives.

RackStation RS10613xs+ The ultimate SAS & SATA storage solution
With superior-performance and hardware specifications, RS10613xs+ provides a reliable, and affordable network attached storage solution for enterprises seeking uninterrupted service and comprehensive business applications.

Superior performance
RS10613xs+ delivers superior performance at over 2,000 MB/sec throughput and 365,119 IOPS under RAID 5 configuration. RS10613xs+ is equipped with 8GB RAM and up to 32GB ECC RAM expansion support, so enterprises can guarantee data accuracy as well as superior ultra-high performance for the mission-critical tasks of the business.

SSD cache technology
RS10613xs+ enables the combination of hard drives and read/write-optimized SSD cache, boosting throughput efficiently while minimizing cost per gigabyte. With full SSD cache reading and writing support, RS10613xs+ offers a significant reduction in I/O latency without crippling your budget. With only a small upfront investment, businesses can benefit from significant server performance enhancement.

Robust scalability up to 636TB
By supporting up to eight Synology RX1213sas, RS10613xs+ provides the ability to seamlessly expand up to 636TB of total storage capacity and expand a single volume up to 108TB on the fly. RS10613xs+ supports up to 106 SATA, SAS, or SSD drives for flexible capacity and balanced performance to meet the needs of varying applications and processes.

Hardware encryption engine enhances file transfer speeds
RS10613xs+ is equipped with an encryption engine which offloads encryption calculation tasks away from the main CPU. Thus, the CPU can be free for other important tasks. In addition, Advanced Encryption Standard (AES) on shared folders with hardware acceleration ensures security without compromising access performance, providing over 2,355MB/s in reading.

Dual 10GbE ports and SAS & SATA III 6Gb/s support
In addition to the default 4 Gigabit ports, RS10613xs+ supports dual 10GbE ports with one add-on PCI Express Gen2 x8 Network Interface Card for maximized bandwidth, bringing you the superior performance that data-intensive applications demand of your storage system. With native SAS & SATA III 6Gb/s interface support, RS10613xs+ ensures the optimum data process under heavy system loading.

Reliable redundancy mechanisms
RS10613xs+ comes with comprehensive redundancy mechanisms to ensure business continuity. Four built-in LAN ports with failover provides the reliable redundancy in the event of unexpected network failure. The high reliability system design including fan-less CPU heat-sink and passive cooling technologies prevents single point of failure. Other features such as redundant data paths, power supplies, system fans, and network ports with failover support ensure continual service uptime.

Synology Replacement Service (SRS)
The Synology Replacement Service (SRS)* provides free shipment of replacement units as early as the next business day. SRS can expedite the process of replacing defective products and minimize service downtime.

Award winning OS - DiskStation Manager
Synology DiskStation Manager (DSM) is a sleek, browser-based operating system running on every DiskStation and RackStation, which makes managing your Synology NAS a breeze. Featuring an intuitive user interface, DSM makes accessing and sharing your data smarter and simpler. Synology's Package Center lets you download and install useful add-on packages designed specifically for individual or business needs, meaning you can enjoy more entertainment in your life or better productivity at work.

Fit into business environments easily
With the support of Windows AD, LDAP, and Domain Trust, RS10613xs+ enables seamless account integration. The User Home feature can automatically create a "home" folder for every user account to minimize the administrator's effort in repeatedly creating "home" folders for all accounts. Windows ACL support on RS10613xs+ allows IT administrators to fine tune access controls and set up privileges to files and folders on RS10613xs+ through the familiar Windows user interface. With compatibility for major protocols, RS10613xs+ can eliminate server configuration overhead and enhance IT administrators’ efficiency.

Seamless storage solution for virtualization environments
RS10613xs+ provides seamless storage solutions for virtualization environments, including VMware, Citrix, and Microsoft Hyper-V. With VMware vSphere® 5 & VAAI integration, RS10613xs+ helps offload specific storage operations and optimizes computation power in VMware environments. Windows ODX support speeds up data manipulation as the data transfer is offloaded. iSCSI also lets SMB users consolidate storage into data center storage arrays while providing hosts with the illusion of locally-attached disks.

Unified storage system
RS10613xs+ enables businesses to cost-effectively manage multi-protocol data by integrating file-level (NAS) and block-level (SAN) storage into one unified storage system. Files can be shared across Windows®, Mac®, and Linux® platforms seamlessly with comprehensive network protocol support (CIFS/SMB, AFP, and NFS). RS10613xs+ provides a cost-effective iSCSI solution, allowing large scale businesses to consolidate storage into data center storage arrays. With thin provisioning available for file-level iSCSI LUN, you can maximize storage utilization by oversubscribing provisions and grow storage space as needed.

Protection by LUN backup, snapshot, and clone
RS10613xs+ enhances the ease of moving and copying data in a virtualized environment with the features - LUN Backup, LUN Snapshot, and LUN Clone. RS10613xs+ offers iSCSI LUN backup at storage level without extra charge. Synology LUN Clone and LUN Snapshot only take up 1/1000 of the original size which highly optimizes storage usage. In addition, Synology's LUN Snapshot lets you create up 256 snapshots per LUN using point-in-time technology without having any impact on system performance. With better support to servers under VMware vSphere or Windows environment, IT managers can expect guaranteed VM status and data consistency through application-consistent snapshots.

Synology CMS (Central Management System)
For enterprises with more than one Synology NAS server, CMS offers the flexibility and convenience for IT administrators to manage all of them from a single point of entry. Through a simple interface, you can obtain a clear overview on resource consumption and logs, helping you identify any issue right away. With group policies, CMS can do much more for your daily tasks. Once a NAS joins a group, it will automatically adopt its rules and behave as intended, without extra configuration.

Increase business productivity with cloud solutions
With comprehensive cloud solutions, RS10613xs+ lets you create your own private cloud easily. Cloud Station is the perfect package to sync files across multiple devices. Files can be edited in offline mode and later synced to Cloud Station, which keeps up to 32 historical versions, allowing you to restore a file back to previous version or recover deleted files. With the mobile app DS cloud, any change made to a file is automatically synced to your smartphones and tablets. For distributed enterprises, Synology's 2-way sync between different DiskStations ensures employees at different locations share the same information in real-time. IT administrators can handpick individual folders that they want to sync to different devices, manually or automatically based on file format and size. Folders synced by Cloud Station can be encrypted on DSM — no one will be able to access its content without your private key.

Ensuring business continuity & reliability
Uninterrupted availability is a critical goal for all businesses. RS10613xs+ offers Synology High Availability (SHA) technology which which combines an active and passive server into one cluster, the former always mirrored to the latter. Shared Folder Sync can replicate data in real-time to another Synology NAS at a remote location, giving your business the Recovery Time Objective (RTO) for prompt disaster recovery. With multiple LAN ports, RS10613xs+ also ensures redundancy in the event of unexpected network failure.

Secure your data
RS10613xs+ offers advanced security measures to protect you from potential security holes. Security Advisor analyzes system settings, password strength, network preferences and removes any possible malware. AppArmor blocks malicious programs from accessing unauthorized system resources. You can also customize the trust level in Package Center to avoid installing packages from untrusted sources, safeguarding your NAS from unknown or tampered files. In addition, RS10613xs+ provides other security add-ons, such as AES encryption, 2-Step verification, IP block & allow list, Antivirus packages, firewall, and DoS attack prevention.

Model NumberRS10613xs+/RS10613xs-PLUS
CPU ModelINTEL Xeon E3-1230 v2
CPU FrequencyQuad Core 3.3 GHz
Floating PointYes
Hardware Encryption Enginge (AES-NI)Yes
System Memory8 GB DDR3 ECC
Memory Module Pre-installed4 GB x 2
Total Memory Slots4
Memory Expandable up to32 GB (8 GB x 4)
Drive Bay(s)10
Maximum Drive Bays with Expansion Unit106
Dedicated SSD Cache Bays2
Compatible Drive Type3.5" SATA III / SATA II HDD
3.5" SAS HDD
2.5" SAS HDD
2.5" SAS SSD
Maximum, Internal Raw Capacity60 TB (6 TB HDD x 10) (Capacity may vary by RAID types)
Hot Swappable DriveYes
USB 2.0 Port4
Expansion Port2
Internal DrivesEXT4
External DrivesEXT4
Size (Height x Width x Depth)88 mm x 445 mm x 570 mm
Weight15.7 kg
RJ-45 1GbE LAN Port4 (with Link Aggregation / Failover support)
Wake on LAN/WANYes
PCIe x8 Slot for Network Card1 (at x8 mode)
System Fan80 mm x 80 mm x 4 pcs
Fan Speed ModeCool Mode
Quiet Mode
Easy Replacement System FanYes
Wireless Support (dongle)Yes
Noise Level54.6 dB(A)
Power RecoveryYes
Scheduled Power On/OffYes
Power Supply Unit / Adapter2 x 400W
AC Input Power Voltage100V to 240V AC
Power Frequency50/60 HZ, Single Phase
Power Consumption142 W (Access)
110 W (HDD Hibernation)
British Thermal Unit484.52 BTU/hr (Access)
375.33 BTU/hr (HDD Hibernation)
Operating Temperature5°C to 35°C
(40°F to 95°F)
Storage Temperature-10°C to 70°C
(15°F to 155°F)
Relative Humidity5% to 95% RH
CertificationFCC Class A
CE Class A
BSMI Class A

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: RS10613XS+

Weight: 35 lb

Warranty: 3 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

3 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
