Synology Part #/MPN: RS2416-PLUS
DiscTech Item #: SYN-RS2416-PLUS-BN-3Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:3 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Interface Types: SATA, USB 2.0, USB 3.0 3.1 3.2, Ethernet RJ45
Form Factor: 3.5inx1.0in LFF Hard Drive
Encryption/SED Supported
Electrical Interface: Ethernet Gigabit - 1Gbps
On-Board Cache: 2GB
Bays/Ports/Slots: 12
Wattage/VA: 500W
Voltage: 110-240V Multi
Synology RackStation RS2416+ 12-Bay SATA Quad Core AES-NI NAS Server - Diskless - Brand New
Synology RackStation RS2416+ 12-bay Network Attached Storage Server includes ...
- 2x USB 2.0 ports
- 2x USB 3.0 ports
- 1x Expansion Port
- 4x Ethernet RJ45 1GbE LAN ports
- 2GB DDR3 Ram, expandable up to 6GB (2 GB + 4GB)
- 12 drive bays, expandable to 24 when paired with an expansion unit
- Intel Atom C2538 Quad Core 2.4 GHz CPU
- Accepts 3.5" and 2.5" SATA hard drives and 2.5" SATA solid state drives.
RackStation RS2416+
Cutting-edge data protection and integrity for modern business
Designed for growing businesses, RS2416+/RS2416RP+ is a powerful network-attached storage solution featuring schedulable snapshots and resilient data integrity powered by the Btrfs file system, on-the-fly scalability up to 24 drives, as well as reliable performance required by modern workplaces.
| SPECIFICATIONS | |
|---|---|
| Model Number | RS2416+/RS2416-PLUS |
| CPU | |
| CPU Model | Intel Atom C2538 |
| CPU Architecture | 64-bit |
| CPU Frequency | Quad Core 2.4 GHz |
| Floating Point | Yes |
| Hardware Encryption Engine (AES-NI) | Yes |
| MEMORY | |
| System Memory | 2 GB DDR3 |
| Memory Module Pre-installed | 2 GB x 1 |
| Total Memory Slots | 2 |
| Memory Expandable up to | 6 GB (2 GB + 4 GB) |
| STORAGE | |
| Drive Bay(s) | 12 |
| Maximum Drive Bays with Expansion Unit | 24 |
| Compatible Drive Type | |
| Maximum Internal Raw Capacity | 96 TB (8 TB HDD x 12)(Capacity may vary by RAID types) |
| Maximum Raw Capacity with Expansion Units | 192 TB (8 TB HDD x 24) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | 108 TB |
| Hot Swappable Drive | Yes |
| EXTERNAL PORTS | |
| USB 2.0 Port | 2 |
| USB 3.0 Port | 2 |
| Expansion Port | 1 |
| APPEARANCE | |
| Size (Height x Width x Depth) | 88 mm x 430 mm x 692 mm |
| Weight | 12.56 kg |
| OTHERS | |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| Wake on LAN/WAN | Yes |
| System Fan | 80 mm x 80 mm x 4 pcs |
| Fan Speed Mode | |
| Easy Replacement System Fan | Yes |
| Wireless Support (dongle) | Yes |
| Power Recovery | Yes |
| Noise Level | 41.5 dB(A) |
| Scheduled Power On/Off | Yes |
| Power Supply Unit / Adapter | 500W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 HZ, Single Phase |
| Power Consumption | |
| British Thermal Unit | |
| Redundant Power Supply (for xs+ and RP model) | No |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: RS2416+
Weight: 29 lb
Warranty: 3 Year Manufacturer
Brand New
The product is brand new.
3 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
