Synology RackStation RS4017XS-PLUS / RS4017XS+ 16-bay NAS Server

Synology Part #/MPN: RS4017XS+

DiscTech Item #: SYN-RS4017XS-PLUS-BN-5Y

  • Special Order - Ships in 3-5 business days
    Special Order - Ships in 3-5 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.


Interface Types: SATA, USB 3.0, Ethernet RJ45

Electrical Interface: Ethernet 10Gigabit - 10Gbps

Bays/Ports/Slots: 16

Wattage/VA: 800W

Voltage: 110-240V Multi

Synology RackStation RS4017XS-PLUS / RS4017XS+ 16-bay SATA Eight-Core Redundant 10GbE NAS Server - Diskless - Brand New

Synology RackStation RS4017XS-PLUS / RS4017XS+ 16-bay SATA Eight-Core Redundant 10GbE NAS Server - Diskless - Brand New

Synology RackStation RS3617RPxs Redundant Network Attached Storage Server includes...

  • 2x USB 3.0 ports
  • 4x Ethernet RJ45 1Gb LAN ports
  • Eight Core 2.2 (base) / 2.7 (turbo) GHz
  • 16 drive bays, expandable to a maximum of 40 bays when paired with an expansion unit
  • 8GB DDR4 ECC Ram, expandable up to 64GB (16 GB X 4)
  • accepts 3.5" and 2.5" SATA hard drives and 2.5" SATA solid state drives.

RackStation RS4017xs+
Highly scalable NAS designed for virtualization, data-intensive applications and service continuity for large scale businesses

Powerful storage solution
RS4017xs+ provides rock-solid storage solution with ultra-high performance at over 844,000 sequential read IOPS and 5,900 MB/s sequential read throughput1. DDR4 ECC UDIMM and 10GbE connectivity guarantees data accuracy and performance for mission-critical environment.

Robust scalability and reliability
Storage capacity of RS4017xs+ can be further scaled up when connected to two Synology Expansion Unit RX1217 or RX1217RP2, providing a total drive number of 40 without disrupting host services.

Fully certified storage virtualization solutions
Synology iSCSI storage fully supports most virtualization solutions to enhance work efficiency with easy management interface. VMware vSphere 6 and VAAI integration helps offload storage operations and optimizes computation efficiency. Windows Offloaded Data Transfer (ODX) speeds up data transfer and migration rate. OpenStack Cinder support turns your Synology NAS into a block-based storage component.

Btrfs: Next generation storage efficiency
Btrfs file system introduces the most advanced storage technologies to meet the management needs of modern large scale businesses:

  • Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
  • Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
  • File or folder level data restoration makes data recovery fast and flexible
  • Automatic file self-healing detects and recovers corrupted files without user intervention

Model NumberRS4017XS+ / RS4017XS-PLUS
CPU ModelIntel Xeon D-1531
CPU Architecture64-bit
CPU Frequency8 Core 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI)Yes
System Memory8 GB DDR4 ECC UDIMM
Memory Module Pre-installed8 GB x 1
Total Memory Slots4
Memory Expandable up to64 GB (16 GB x 4)
Drive Bay(s)40
Maximum Drive Bays with Expansion Unit16
Compatible Drive Type3.5in SATA HDD
2.5in SATA HDD
2.5in SATA SSD
Maximum Internal Raw Capacity192 TB (12 TB HDD x 16) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units480 TB (191 TB + 12TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size
  • 200 TB (32GB RM required, for RAID 5 or RAID 6 groups only)
  • 108 TB
  • Hot Swappable DriveYes
    Internal DrivesBtrfs
    External DrivesBtrfs
    exFAT (purchased separately)
    Size (Height x Width x Depth)132.3 mm x 482 mm x 656.5 mm
    Weight17.4 kg
    RJ-45 1GbE LAN Port4 (with Link Aggregation / Failover support)
    RJ-45 10GbE LAN Port2 (with Link Aggregation / Failover support)
    PCIe Slot for Network Card2 x Gen3 x8 slots (x8 link)
    System Fan80 mm x 80 mm x 3 pcs
    Fan Speed ModeFull-Speed Mode
    Cool Mode
    Quiet Mode
    Easy Replacement System FanYes
    Noise Level44.7 dB(A)
    Power RecoveryYes
    Scheduled Power On/OffYes
    Power Supply Unit / Adapter2 x 800W
    AC Input Power Voltage100V to 240V AC
    Power Frequency50/60 HZ, Single Phase
    Redundant Power SupplyYes
    Operating Temperature5°C to 35°C
    (40°F to 95°F)
    Storage Temperature-20°C to 60°C
    (-5°F to 140°F)
    Relative Humidity5% to 95% RH
    CertificationFCC Class A
    CE Class A
    BSMI Class A

    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: RS4017XSPLUS RS4017XS-PLUS

    Weight: 40 lb

    Warranty: 5 Year Manufacturer

    Brand New

    Condition Levels Explained

    The product is brand new.

    5 Year Manufacturer Warranty

    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.
