Synology RackStation RS815-PLUS NAS Server

Synology Part #/MPN: RS815-PLUS

DiscTech Item #: SYN-RS815-PLUS-BN-3Y


$979.00
  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

$979.00

Interface Types: SATA, eSATA External, USB 3.0 3.1 3.2, Ethernet RJ45

Encryption/SED Supported

Electrical Interface: Ethernet Gigabit - 1Gbps

On-Board Cache: 2GB

Bays/Ports/Slots: 8

Wattage/VA: 250W

Voltage: 110-240V Multi

Synology RackStation RS815+ 4-bay SATA Quad Core AES-NI NAS Server - Brand New

Synology RackStation RS815+ Network Attached Storage Server includes...

  • 2x USB 3.0 port
  • 1x eSATA port
  • 4x Ethernet RJ45 1Gb LAN ports
  • Intel Quad Core 2.4 GHz
  • 2GB DDR3 Ram, expandable up to 6GB (2 GB + 4 GB)
  • 4 drive bays, expandable to 8 when paired with an expansion unit
  • accepts 3.5" and 2.5" SATA hard drives and 2.5" SATA solid state drives.

RackStation RS815+ High-performance NAS server optimized for intensive tasks and encryption
Featuring a quad-core processor and AES-NI hardware encryption engine, RS815+ deliver the superior performance which is essential for business’s data transmission needs. The ability to expand to 6GB DDR3 RAM and scale storage up to 8 drives with Synology Expansion Unit RX415 give your business the agility to meet evolving workload demands.

Quad-core CPU brings high performance
Powered by a quad-core CPU running at 2.4 GHz, RS815+ delivers average 389.03 MB/s reading and 361.33 MB/s writing. With this superior performance and a RAM module expandable to 6GB (2GB by default), RS815+ is a powerful 1U NAS server for mission-critical tasks of SMBs.

Ideal encrypted data transmission with AES-NI
RS815+ features a hardware encryption engine, which offloads encryption calculation tasks away from the main CPU. That means files and folders are encrypted on the fly without compromising the performance ─delivering encrypted data transmission speeds over 388.66 MB/s reading and 158.9 MB/s writing.

Robust scalability up to 8 drives
When your data storage is nearing its limits, RS815+ can be connected to a dedicated RX415 expansion unit, letting you easily scale up to 8 drives for additional storage on the fly. With a RX415 connected through an eSATA cable with specially-designed locking connectors, raw capacity can be as high as 48TB.

Quad LAN ports for failover and Link Aggregation support
To ensure your business continuity, RS815+ features four built-in Gigabit LAN ports supporting failover, which is engineered to provide reliable redundancy even if LAN connection malfunction occurs on one port, reducing the chance of service disruption and costly downtime. In addition, Link Aggregation powered by four LAN ports increases connection speeds beyond the limits of a single network cable or port.

SSD cache technology
RS815+ enables the combination of hard drives and SSD cache, boosting throughput efficiently while minimizing cost per gigabyte. With full SSD cache support, RS815+ offers a significant reduction in I/O latency without crippling your budget. With only a small upfront investment, businesses can benefit from significant server performance enhancement.

Award winning OS - DiskStation Manager
Synology DiskStation Manager (DSM) is a sleek, browser-based operating system running on every DiskStation and RackStation, which makes managing your Synology NAS a breeze. Featuring an intuitive user interface, DSM makes accessing and sharing your data smarter and simpler. Synology's Package Center lets you download and install useful add-on packages designed specifically for individual or business needs, meaning you can enjoy more entertainment in your life or better productivity at work.

Seamless storage solution for virtualization environments
RS815+ provides seamless storage solutions for virtualization environments, including VMware, Citrix, and Microsoft Hyper-V. With VMware vSphere® 5 & VAAI integration, RS815+ helps offload specific storage operations and optimizes computation power in VMware environments. Windows ODX support speeds up data manipulation as the data transfer is offloaded. iSCSI also lets SMB users consolidate storage into data center storage arrays while providing hosts with the illusion of locally-attached disks.

Fit into business environments easily
With the support of Windows AD, LDAP, and Domain Trust, RS815+ enables seamless account integration. The User Home feature can automatically create a "home" folder for every user account to minimize the administrator's effort in repeatedly creating "home" folders for all accounts. Windows ACL support on RS815+ allows IT administrators to fine tune access controls and set up privileges to files and folders on RS815+ through the familiar Windows user interface. With compatibility for major protocols, RS815+ can eliminate server configuration overhead and enhance IT administrators’ efficiency.

Optimize storage management
With Synology's Storage Manager, RS815+ allows for flexible storage deployment and utilization. You can optimize RAID configuration with Synology Hybrid RAID (SHR) while providing redundant data protection. Other features such as multiple volumes on single RAID and Global Hot Spare also greatly enhance management efficiency and fit deployment of any kind.

Synology CMS (Central Management System)
For enterprises with more than one Synology NAS server, CMS offers the flexibility and convenience for IT administrators to manage all of them from a single point of entry. Through a simple interface, you can obtain a clear overview on resource consumption and logs, helping you identify any issue right away. With group policies, CMS can do much more for your daily tasks. Once a NAS joins a group, it will automatically adopt its rules and behave as intended, without extra configuration.

All-in-one server
With just one RS815+, it's possible to handle a vast amount of tasks. RS815+ helps your company gain a competitive edge by acting as your multi-function server. Directory Server provides LDAP service, while DNS and DHCP packages allow you to host a domain name server and automate network IP assignment at no extra cost. With Synology's Proxy Server, you can regulate content access and monitor who can access which website while saving bandwidth. You can host up to 30 websites with Web Station, safeguard the office environments with Surveillance Station, send and receive mails using your own email domain with Mail Station, share printing capability with Printer Server, make RS815+ act as a VPN server to access company’s resources remotely, and more.

Ensuring business continuity
Uninterrupted availability is a critical goal for all businesses. RS815+ supports Synology High Availability (SHA) technology which combines an active and passive server into one cluster, the former always mirrored to the latter. The Heartbeat mechanism detects regular "heartbeats" between the two servers. If the main server encounters unexpected downtime, the passive server immediately takes over. With multiple LAN ports, RS815+ also ensures redundancy in the event of unexpected network failure.

Powerful backup solutions to enhance efficiency
Backup & Replication feature allows you to back up data from one RS815+ to another DiskStation, or rsync-compatible servers. It also provides the flexibility to restore the server to any particular point in time, and back up modified blocks to optimize storage and processing time. In addition, RS815+ offers you the capability to back up iSCSI LUNs with no extra charge. Businesses can enjoy efficient backup performance with "Point-in-time copy" technology for data consistence and incremental backup to speed up processing time.

Increase business productivity with cloud solutions
With comprehensive cloud solutions, RS815+ lets you create your own private cloud easily. Cloud Station is the perfect package to sync files across multiple devices. Files can be edited in offline mode and later synced to Cloud Station, which keeps up to 32 historical versions, allowing you to restore a file back to previous version or recover deleted files. With the mobile app DS cloud, any change made to a file is automatically synced to your smartphones and tablets. For distributed enterprises, Synology's 2-way sync between different DiskStations ensures employees at different locations share the same information in real-time. IT administrators can handpick individual folders that they want to sync to different devices, manually or automatically based on file format and size. Folders synced by Cloud Station can be encrypted on DSM — no one will be able to access its content without your private key.

Secure your data
RS815+ offers advanced security measures to protect you from potential security holes. Security Advisor analyzes system settings, password strength, network preferences and removes any possible malware. AppArmor blocks malicious programs from accessing unauthorized system resources. You can also customize the trust level in Package Center to avoid installing packages from untrusted sources, safeguarding your NAS from unknown or tampered files. In addition, RS815+ provides other security add-ons, such as AES encryption, 2-Step verification, IP block & allow list, Antivirus packages, firewall, and DoS attack prevention.

Eco-friendly NAS server
All Synology NAS is designed with energy efficiency in mind. RS815+ only consumes 20.57W in HDD Hibernation and 36.78W in access. The support of Wake on LAN/WAN and scheduled power on and off can further reduce power consumption and operation cost. Synology acknowledges the responsibility as a global citizen, so all Synology products are produced with RoHS compliant parts and packed with recyclable packing materials.

SPECIFICATIONS
Model NumberRS815+/RS815-PLUS
CPU SPECIFICATIONS
CPU ModelINTEL Atom C2538
CPU FrequencyQuad Core 2.4 GHz
Floating PointYes
Hardware Encryption Engine (AES-NI)Yes
MEMORY SPECIFICATIONS
System Memory2 GB DDR3
Memory Module Pre-installed2 GB x 1
Total Memory Slots2
Memory Expandable up to6 GB (2 GB + 4GB)
STORAGE SPECIFICATIONS
Drive Bay(s)4
Maximum Drive Bays with Expansion Unit8
Compatible Type3.5in SATA III / SATA II HDD
2.5in SATA III / SATA II HDD
2.5in SATA III / SATA II SSD
Maximum Internal Raw Capacity32 TB (8 TB HDD x 4)
(Capacity my vary by RAID types)
Hot Swappable DriveYes
EXTERNAL PORTS
USB 3.0 Port2
eSATA Port1
FILE SYSTEM
Internal DrivesEXT4
External DrivesEXT4
EXT3
FAT
NTFS
HFS+
APPEARANCE
Size (Height x Width x Depth)44 mm x 430.5 mm x 457.5 mm
Weight6.73 kg
OTHERS
RJ-45 1GbE LAN Port4 (with Link Aggregation / Failover support)
Wake on LAN/WANYes
System Fan40 mm x 40 mm x 3 pcs
Fan Speed ModeCool Mode
Quiet Mode
Wireless Support (dongle)Yes
Noise Level25.3 dB(A)
Power RecoveryYes
Scheduled Power On/OffYes
Power Supply Unit / Adapter250W
AC Input Power Voltage100V to 240V AC
Power Frequency50/60 HZ, Single Phase
Power Consumption36.78 W (Access)
20.57 W (HDD Hibernation)
British Thermal Unit125.50 BTU/hr (Access)
70.19 BTU/hr (HDD Hibernation)
ENVIROMENT TEMPERATURE
Operating Temperature5°C to 35°C
(40°F to 95°F)
Storage Temperature-20°C to 60°C
(-5°F to 140°F)
Relative Humidity5% to 95% RH
CertificationFCC Class A
CE Class A
BSMI Class A

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: RS815+

Weight: 15 lb

Warranty: 3 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

3 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
