Synology VisualStation VS360HD Surveillance Station

Synology Part #/MPN: VS360HD

DiscTech Item #: SYN-VS360HD-BN-3Y


Out of Stock

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Out of Stock

Interface Types: USB 2.0, USB 3.0 3.1 3.2, Ethernet RJ45, HDMI, VGA, 3.5mm Headphone

Electrical Interface: Ethernet Gigabit - 1Gbps

Wattage/VA: 36W

Voltage: 110-240V Multi

Synology VisualStation VS360HD 36-Channel Compact Surveillance Station - Brand New

Synology VisualStation VS360HD 36-Channel Compact Surveillance Station includes ...

  • 1x VGA Video Output port
  • 1x HMDI Video Output port
  • 2x USB 2.0 ports
  • 1x USB 3.0 Port
  • 1x Ethernet RJ45 1GbE LAN port

Ultra compact PC-less live view and playback solution

Paired with any Synology NVR server, VisualStation VS360HD, a video decoder, allows you to create an amazingly compact monitoring and playback station for your local teams —without a computer. VS360HD is ideal for deployments in harsh environments and where space is limited. In addition, it allows the main recording servers to remain hidden from prying eyes. VS360HD includes HDMI and VGA output to display video feeds, supporting 720p at up to 36 channels/360FPS or even 5 megapixels with fewer channels/FPS.

Model NumberVS360HD
Video Output
  • VGA X 1
  • HDMI x 1
  • Supported Video Resolution1080p 60Hz
    Audio Input3.5 mm Stereo Audio Jack x 1
    Audio Output3.5 mm Stereo Audio Jack x 1
    USB 2.0 Port2
    USB 3.0 Port1
    Size32 mm x 130 mm x 130 mm
    Weight0.3 kg/0.7 lb
    RJ-45 1GbE LAn Port1
    Power Supply Unit / Adapter36W
    AC Input Power Voltage100V to 240V AC
    Power Frequency50/60 HZ, Single Phase
    Power Consumption
  • 4.76 W (36ch full-load)
  • 3.61 W (Power on Idle)
    Maximum IP cam36
    Total FPS (H.264)
  • 360 FPS @ 720p (1280x720), 36 Channels
  • 160 FPS @ 1080p (1920×1080), 16 Channels
  • 90 FPS @ 3M (2048x1536), 9 Channels
  • 60 FPS @ 5M (2591x1944), 6 Channels
  • Total FPS (MJPEG)
  • 150 FPS @ 720p (1280x720), 15 Channels
  • 40 FPS @ 1080p (1920×1080), 4 Channels
  • 20 FPS @ 3M (2048x1536), 2 Channels
  • 10 FPS @ 5M (2591x1944), 1 Channel
  • Video Compression Format
  • MPEG-4
  • H.264
  • Audio Codec
  • PCM
  • G711
  • G726
  • AMR
  • AAC
  • Live View / Recording PlaybackYes
    Snapshot SupportYes
    eMap SupportYes
    PTZ Control / PatrolYes
    Log ViewerYes
