Toshiba Part #/MPN: MG04ACA500A
DiscTech Item #: TOS-MG04ACA500A-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 5TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 4Kn
Sustained Throughput: 205
Average Seek Time: 4.17
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128KB
Toshiba MG04ACA500A 5TB 6Gbps 7.2K RPM 4Kn Enterprise SATA HDD - Brand New
Toshiba MG04ACA500A 5TB / 5000GB 6.0 Gb/s 7200 RPM 4K (Native) Enterprise Serial ATA Hard Disk Drive - Brand New
Alt MPN: HDEPR20GEA51
Enterprise Capacity HDD
The MG04ACA Enterprise Capacity HDD models provide capacities up to 6 TB and 7,200 rpm performance, in a robust design engineered for nearline business-critical workloads. The MG04ACA series utilizes industry-standard 3.5-inch 26.1mm height form factor and Advanced Format sector technologies for optimum capacity and data reliability. 512e models support Toshiba Persistent Write Cache technology which helps enhance performance with handling data in the event of a sudden loss of power. Equipped with SATA 6.0 Gbit/s interface, the Enterprise Capacity MG04ACA models help save rack space and reduce the footprint and operational burden of business critical servers and storage systems. 512e or 4Kn Advanced Format sector technology models are available. 4Kn models (MG04ACAxxxA) offer optimum performance and compatibility with the 4K applications and operating environments. 512e models (MG04ACAxxxE) provide support for legacy applications and operating environments that require 512B sector lengths.
Key Features
- Industry Standard 3.5-inch 26.1 mm Height Form Factor
- Large-Capacity
- 7,000 RPM Performance
- SATA 6.0 Gbit/s Interface
- 550 Total TB Transferred per Year Workload Rating
- 512e or 4Kn Advanced Format Sector Technology
Applications
- Engineered for Mid-line / Nearline Business Critical Workloads
- Tier 2 Business-Critical Servers and Storage Systems
- Servers Supporting Application Workloads that Benefit from High Capacity per Spindle
- Capacity-Optimized Data Center Storage Systems
Compatibility:
This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SATA drives.
| Toshibia Enterprise HDD | |
|---|---|
| Model Number | MG04ACA500A |
| Basic Specifications | |
| Interface | SATA-2.6 / 3.0 |
| Interface Speed | 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s |
| Formatted Capacity | 5TB / 5000GB |
| Logical Data Block Length (HOST) | 4,096 B |
| Logical Data Block Length (DISK) | 4,096 B |
| Environmental Compliance | RoHS Compatible |
| Performances | |
| Buffer Sizee | 128 MiB |
| Rotation Speed | 7,200 rpm ±0.1 % |
| Average Latency Time | 4.17 ms |
| Data Transfer Speed (Sustained) | 205 MiB/s |
| Reliability | |
| Unrecoverable Error Rate | 10 per 10e16 bits read |
| MTTF | 1,400,000 hors |
| 24 x 7 Operation | Yes |
| Workloads | 550 TB/y |
| Power Requirements | |
| Supply Voltage | 5 V ±5 % , 12 V ±5 % |
| Power Consumption (Read / Write) | 11.3 W |
| Power Consumption (Idle-B) | 6.0 W Typ |
| Energy Consumption Efficiency / Category Name | 0.00120 / C |
| Dimensions | |
| Height | 26.1 mm Max |
| Width | 101.6 mm ± 0.25 mm |
| Lenth | 147 mm Max |
| Weight | 720 g Max |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HDEPR20GEA51
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
