Toshiba MG04SCA500A 5TB SAS Hard Drive
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 5TB |
| Speed: | 7.2K RPM |
| Interface Types: | SAS |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SAS-2 6Gbps |
| RAM: | 64MB |
Description
Toshiba MG04SCA500A 5TB 3.5in 6Gbps 7.2K RPM 4Kn Enterprise SAS HDD - Brand New
Toshiba MG04SCA500A 5TB / 5000GB 3.5" 6.0 Gb/s 7200 RPM 4K Native Enterprise Serial Attached SCSI Hard Disk Drive - Brand New
MG04SCAxx0x Series
The MG04SCA Enterprise Capacity HDD models provide capacities up to 5 TB and 7,200 rpm performance, in a robust design engineered for nearline business-critical workloads. The MG04SCA series utilizes industry-standard 3.5-inch 26.1 mm height form factor and Advanced Format sector technologies for optimum capacity and data reliability. Toshiba Persistent Write Cache technology helps enhance performance with handling data in the event of a sudden loss of power. Equipped with 6.0 Gbit/s SAS interface, the Enterprise Capacity MG04SCA models help save rack space and reduce the footprint and operational burden of business critical servers and storage systems.
512e or 4Kn Advanced Format sector technology models are available. 4Kn models (MG04SCAxxxA) offer optimum performance and compatibility with the 4K applications and operating environments. 512e models (MG04SCAxxxE) provide support for legacy applications and operating environments that require 512 B sector lengths.
Key Features
- Industry Standard 3.5-inch 26.1 mm Height Form Factor
- Large Capacity (5 / 4 / 3 / 2 TB Models)
- 7,200 rpm Performance
- Dual-Port 6.0 Gbit/s SAS Interface
- 550 total TB Transferred per Year Workload Rating
- 512e or 4Kn Advanced Format Sector Technology
- Introducing Toshiba Persistent Write Cache Technology for Data-Loss Protection in Sudden Power-Loss Events
Applications
- Engineered for Mid-line / Nearline Business Critical Workloads
- Tier 2 Business-Critical Servers and Storage Systems
- Servers Supporting Application Workloads that Benefit from High Capacity per Spindle
- Capacity-Optimized Data Center Storage Systems
Compatibility
This drive is compatible with any server that accepts 3.5inx1.0in SAS Drive.
Specifications
| Toshiba Enterprise HDD | |
|---|---|
| Standard Model Numbers | MG04SCA500A |
| Basic Specifications | |
| Interface | SAS-3.0 |
| Interface Speed | 6Gbps |
| Formatted Capacity | 5TB / 5000GB |
| Interface Speed | 6.0 Gbit/s Max |
| Rotation Speed | 7,200 rpm ± 0.1 % |
| Average Latency Time | 4.17 ms |
| Buffer Size | 64 MiB |
| Data Transfer Speed (Sustained) | 205 MiB/s |
| Logical Data Block Length (HOST) | 4,096 / 4,160 / 4,224 B |
| Allowable Voltage | 5 V ± 5% 12 V ± 5 % |
| Power Consumption Read/Write | 11.3 W Max |
| Power Consumption Low Power Idle | 6.2 W Typ |
| Reliability | |
| MTTF | 1,400,000 hours |
| Non-recoverable Error Rate | 10 errors per 10^16 bits read |
| 24 x 7 Operation | Yes |
| Workloads | 550 TB/y |
| Mechanical Specifications | |
| Height | 26.1 mm Max |
| Width | 101.6 mm ± 0.25 mm Max. |
| Length | 147 mm Max |
| Weight | 720 g Max |
| Environmental Requirements | |
| Temperature (Operating) | 5 to 55°C |
| Temperature (Non-operating) | -40 to 70°C |
| Humidity (Operating) | 5 to 90 % R.H. |
| Humidity ( Non-operating ) | 5 to 95 % R.H. |
| Shock ( Operating ) | 686 m/s2 { 70 G } ( 2 ms duration ) |
| Shock ( Non-operating ) | 2,940 m/s { 300 G } ( 2 ms duration ) |
| Vibration ( Operating ) | 7.35 m/s { 0.75 G } ( 5 to 300 Hz ) |
| Vibration ( Non-operating ) | 49 m/s { 5 G } ( 5 to 500 Hz ) |
| Altitude ( Operating ) | -305 to 3,048 m { -1,000 to +10,000 feet } |
| Altitude ( Non-operating ) | -305 to 12,192 m { -1,000 to +40,000 feet } |
| Environmental Features | |
| RoHS | Compatible |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 2.5 lb
Warranty: 1 Year DiscTech
Condition
The product is brand new.
Warranty
1 Year DiscTech Warranty
