Toshiba MG08 Series MG08ACA16TA 16TB 4Kn SATA Hard Drive

Toshiba Part #/MPN: MG08ACA16TA

DiscTech Item #: TOS-MG08ACA16TA-BN-5Y

$610.00
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Warranty:5 Year Manufacturer
    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

Back
$610.00

Enterprise Grade

Capacity: 16TB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 4Kn

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 512MB

Toshiba MG08ACA16TA 16TB 3.5-Inch LFF 6Gbps 7.2K RPM 4Kn MG08 Series Enterprise SATA Hard Drive - Brand New

Toshiba MG08ACA16TA 16TB / 16000 3.5" LFF / Large Form Factor 6.0 Gb/s 7200 RPM 4Kn / 4K Native MG08 Series Enterprise SATA / Serial ATA HDD / Hard Drive - Brand New

MG08 Series
Enterprise Capacity HDD

Using an industry-leading 9-disk design pioneered by Toshiba, the MG08 Series provides 16TB of conventional magnetic recording (CMR) capacity and 7,200 rpm performance. The industry-standard .5-inch form-factor integrates easily into cloud-scale storage infrastructure, business-critical servers and storage, and File and Object storage solutions. Toshiba’s precision industrial laser welding technology is put to use to seal helium inside the 9-disk mechanics. The massive 16TB capacity is delivered using proven CMR recording technology providing optimum application compatibility and data reliability. Available with either a SATA 6.0 Gbit/s or a 12.0 Gbit/s SAS interface, the MG08 Series models integrate easily into standard 3.5-inch drive bays to help reduce the footprint and operational burden of cloud-scale storage infrastructure, and business critical servers and storage systems.

Key Features

  • Industry Standard 3.5-inch 26.1 mm Height Form Factor
  • Conventional Magnetic Recording (CMR) 16TB for broad compatibility
  • Industry-leading 9-disk helium-sealed design for superior storage density
  • 7,200 rpm Performance
  • 550 Total TB Transferred per Year Workload Rating
  • 512e or 4Kn Advanced Format Sector Technology; (512e Model) Includes Toshiba Persistent Write Cache Technology for Data-Loss Protection in Sudden Power-Loss Events

Application

  • Cloud-scale Sever and Storage Infrastructure
  • Software-defined data center infrastructure
  • File- and Object-based storage infrastructure
  • Tiered Storage Infrastructure
  • Workloads and Use-Cases that Benefit from High Capacity per Spindle
  • Capacity-Optimized Cloud-scale and Rack-Scale Storage Systems
  • Compliance Data Life-Cycle Management
  • Data Center Data-Protection and Data Back-up Infrastructure

Compatibility:

This drive is compatible with servers and arrays that accept 3.5in x 1.0in SATA drives

Toshiba MG08
Enterprise Capacity HDD
4K Native (4Kn) Model#MG08ACA16TA
SPECIFICATIONS
Sector Size4K Nativen (4Kn)
Form Factor3.5-Inch
InterfaceSATA-3.3
Formatted Capacity16TB / 16,000GB
PerformanceInterface Speed
  • 12.0 Gbit/s
  • 6.0 Gbit/s
  • 3.0Gvit/s
  • 1.5 Gbit/s

    • Rotation Speed
  • 7,200 RPM

    • Buffer Size
  • 512 MiB
    • Logical Data Block LengthMG08xxxxxxA (fiexed length)
  • 4096 B
    • Supply VoltageAllowable Voltage
  • 12 V ± 10% / 5 V + 10% / -7%
    • Power ConsumptionRandom Write / Read 4KB Q1 (Typ)
  • 8.28 W Typ
    • Active Idle (Idle-A)
  • 4.73 W Typ.
    • AcousticsActive Idle (Typ)
  • 20 dB Typ
    • ENVIRONMENTAL LIMITS
    Ambient TemperatureOperating
  • 5°C to 55°C

    • Non-Operating
  • -40°C to 70°C
    • Relative HumidityOperating
  • 5% to 90% R.H. (No condensation)

    • Non-Operating
  • 5% to 95% R.H. (No condensation)
    • AltitudeOperating
  • -305 m to 3,048 m

    • Non-Operating
  • -305 m to 12,192 m
    • ShockOperating
  • 686 m/s {70 G}(2 ms duration)

    • Non-Operating
  • 2,450 m/s {250 G} (2 ms duration)
    • VibrationOperating
  • 7.35 m/s {0.75 G} (5 to 300 Hz
  • 2.45 m/s {0.25 G} (300 to 500 Hz)

    • Non-Operating
  • 29.4 m/s {3.0 G} (5 to 500 Hz)
    • RELIABILITY
    MTTF2,500,000 hours
    Non-recoverable Error Rate10 error per 1016 bits read
    Load / Unload600,000 times
    Availability24 hours/day, 7 days/week
    Ratted Annual Workload (Total TB Transferred per Year, R/W)550 TB per year
    MECHANICAL SPECIFICATIONS
    Width (Max)101.85 mm
    Height (Max)26.1 mm
    Length (Max)147.0 mm
    Weight (Max(Typ))720 g / 1.59 lbs
    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Weight: 1.8 lb

    Warranty: 5 Year Manufacturer
