Dell 8MG73 24HF9 Toshiba MG08SCA16TEY 16TB 3.5" 7.2K RPM 512e SAS drive

Toshiba Part #/MPN: MG08SCA16TEY

DiscTech Item #: TOS-MG08SCA16TEY-BN-OE-DEL

$385.00
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Warranty:1 Year DiscTech
    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty

  • In Stock:2Need more?
    Stock Levels

    This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.

Back
$385.00

Enterprise Grade

Capacity: 16TB

Speed: 7,200RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps

On-Board Cache: 512MB

Compatible Systems: Dell 14th Gen. R640/R740, Dell 13th Gen. R730/T630, Dell 12th Gen. R720/T620

Dell 8MG73 / 24HF9 / Toshiba MG08SCA16TEY 16TB 3.5" LFF 12Gbps 7.2K RPM 512e MG08 HDEPN40DAB51 Enterprise SAS Hard Drive - Brand New

Dell 8MG73 / 24HF9 / Toshiba MG08SCA16TEY 16TB 3.5in LFF 12Gbps 7.2K RPM 512e MG08 HDEPN40DAB51 Enterprise SAS Hard Drive

Dell DP/: 8MG73  08MG73 24HF9 024HF9

Alt MP/N: HDEPN40DAB51

12Gbps

MG08 Series
Enterprise Capacity HDD

Using an industry-leading 9-disk design pioneered by Toshiba, the MG08 Series provides 16TB of conventional magnetic recording (CMR) capacity and 7,200 rpm performance. The industry-standard .5-inch form-factor integrates easily into cloud-scale storage infrastructure, business-critical servers and storage, and File and Object storage solutions. Toshiba’s precision industrial laser welding technology is put to use to seal helium inside the 9-disk mechanics. The massive 16TB capacity is delivered using proven CMR recording technology providing optimum application compatibility and data reliability. Available with either a SATA 6.0 Gbit/s or a 12.0 Gbit/s SAS interface, the MG08 Series models integrate easily into standard 3.5-inch drive bays to help reduce the footprint and operational burden of cloud-scale storage infrastructure, and business critical servers and storage systems.

Key Features

  • Industry Standard 3.5-inch 26.1 mm Height Form Factor
  • Conventional Magnetic Recording (CMR) 16TB for broad compatibility
  • Industry-leading 9-disk helium-sealed design for superior storage density
  • 7,200 rpm Performance
  • 550 Total TB Transferred per Year Workload Rating
  • 512e or 4Kn Advanced Format Sector Technology; (512e Model) Includes Toshiba Persistent Write Cache Technology for Data-Loss Protection in Sudden Power-Loss Events

Application

  • Cloud-scale Sever and Storage Infrastructure
  • Software-defined data center infrastructure
  • File- and Object-based storage infrastructure
  • Tiered Storage Infrastructure
  • Workloads and Use-Cases that Benefit from High Capacity per Spindle
  • Capacity-Optimized Cloud-scale and Rack-Scale Storage Systems
  • Compliance Data Life-Cycle Management
  • Data Center Data-Protection and Data Back-up Infrastructure

Compatibility:

This drive is compatible with servers and arrays that accept 3.5in x 1.0in SAS drives

Toshiba MG08
Enterprise Capacity HDD
512 Emulation (512e) Model#MG08SCA16TEY
SPECIFICATIONS
Sector Size512 Emulation (512e)
Form Factor3.5-Inch
InterfaceSAS 12Gbps
Formatted Capacity16TB / 16,000GB
PerformanceInterface Speed
  • 12.0 Gbit/s
  • 6.0 Gbit/s
  • 3.0Gvit/s
  • 1.5 Gbit/s

    • Rotation Speed
  • 7,200 RPM

    • Buffer Size
  • 512 MiB
    • Logical Data Block LengthMG08xxxxxxE (emulation)
  • Host:512 B, Disk; 4096 B
    • Supply VoltageAllowable Voltage
  • 12 V ± 10% / 5 V + 10% / -7%
    • Power ConsumptionRandom Write / Read 4KB Q1 (Typ)
  • 8.28 W Typ
    • Active Idle (Idle-A)
  • 4.73 W Typ.
    • AcousticsActive Idle (Typ)
  • 20 dB Typ
    • ENVIRONMENTAL LIMITS
    Ambient TemperatureOperating
  • 5°C to 55°C

    • Non-Operating
  • -40°C to 70°C
    • Relative HumidityOperating
  • 5% to 90% R.H. (No condensation)

    • Non-Operating
  • 5% to 95% R.H. (No condensation)
    • AltitudeOperating
  • -305 m to 3,048 m

    • Non-Operating
  • -305 m to 12,192 m
    • ShockOperating
  • 686 m/s {70 G}(2 ms duration)

    • Non-Operating
  • 2,450 m/s {250 G} (2 ms duration)
    • VibrationOperating
  • 7.35 m/s {0.75 G} (5 to 300 Hz
  • 2.45 m/s {0.25 G} (300 to 500 Hz)

    • Non-Operating
  • 29.4 m/s {3.0 G} (5 to 500 Hz)
    • RELIABILITY
    MTTF2,500,000 hours
    Non-recoverable Error Rate10 error per 1016 bits read
    Load / Unload600,000 times
    Availability24 hours/day, 7 days/week
    Ratted Annual Workload (Total TB Transferred per Year, R/W)550 TB per year
    MECHANICAL SPECIFICATIONS
    Width (Max)101.85 mm
    Height (Max)26.1 mm
    Length (Max)147.0 mm
    Weight (Max(Typ))720 g / 1.59 lbs
    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: 8MG73 08MG73 HDEPN40DAB51 24HF9 024HF9 4N7V0
