Toshiba THNSNJ120PCS3 120GB SATA eSSD
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 5 Year ManufacturerWarrantyProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
| Capacity: | 120GB |
| Speed: | Solid State |
| Interface Types: | SATA |
| Form Factor: | 2.5" x 7mm Fits All laptops |
| SSD Endurance DWPD: | Enterprise Read Intensive / RI |
| Electrical Interface: | SATA 600 - 6Gbps |
Description
Toshiba THNSNJ120PCS3 120GB 2.5in 6Gbps SATA MLC Read-Intensive 1-DWPD eSSD - Brand New
Toshiba THNSNJ120PCS3 120GB 2.5" 6.0 Gbps Serial Advanced Technolgy Attachment Multi-Level Cell Read-Intensive 1-DWPD Enterprise Solid State Disk Drive - Brand New
The HK3R range is designed for use in tiered server storage systems and any read-intensive applications such as fast boot drives and for cache and error logging. The eSSDs are fitted with a 6Gbit/s SATA 3.0 interface and come in a 2.5 inch (6.4cm) form factor. Using state-of-the-art 19nm MLC NAND, the drives achieve sequential read speeds of 500MiB/s and random read speeds of 75,000 IOPS.
All eSSDs of this series feature full power loss protection and end-to-end data protection. The drives also incorporate Toshiba’s robust and highly efficient Quadruple Swing-By Code (QSBC™) for improved error correction and reliability.
- 19 nm MLC NAND Flash
- 6Gbit/s SATA 3.0 Interface
- Quadruple Swing-By Code (QSBC) technology
- Power loss protection
- End-to-end data protection
Compatibility
This drive is compatible with any server that accepts 2.5”x7mm Thin Case SATA drives
Specifications
| Drive Model | THNSNJ120PCS3 |
|---|---|
| Capacity | 120GB |
| Performance | |
| Interface Type | SATA 6.0 Gbps |
| Memory | 19mn MLC NAND Flash Memory |
| Performance: Random read (4KiB) | 75,000 IOPS |
| Performance: Random write (4 KiB) | 10,000 IOPS |
| Performance: Sequential read (64 KiB) | 500 MByte/s |
| Performance: Sequential write (64 KiB) | 280 MByte/s |
| Physical | |
| Form factor | 2.5 inch |
| Height (in/mm) | 0.28/7.0 |
| Width (in/mm) | 2.75/69.85 |
| Depth (in/mm) | 3.95/100.45 |
| Weight (lb/g) | 0.132/60.0 |
| Ambient temperature (operating) | From 0 °C to +55 °C |
| Ambient temperature (non-operating) | From -40 °C to +70 °C |
| Shock resistance (operating) | 9,800 m/s2 {1,000G} / 0.5 ms duration |
| Shock resistance (non-operating) | 9,800 m/s2 {1,000G} / 0.5 ms duration |
| Vibration (operating) | 21.27 m/s2 {2.17Grms} (5 to 800Hz) |
| Vibration (non-operating) | 159.74 m/s2 {16.3Grms} (20 to 2,000Hz) |
| Reliability | |
| MTTF | 2,000,000 Hours |
| Product life | 5 |
| Operating condition | 24 hours/day, 7 days/week |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 1 lb
Warranty: 5 Year Manufacturer
Condition
Brand New
Warranty
5 Year Manufacturer Warranty
