Tripp Lite BCPRO600 600VA Standby UPS Tower Battery Backup

TRIPP LITE Part #/MPN: BCPRO600

DiscTech Item #: TRI-BCPRO600-BN-2Y


$149.00
  • Special Order - Ships in 1-2 business days
    Special Order - Ships in 1-2 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.

$149.00

Interface Types: IEC 5-15P

Bays/Ports/Slots: 6

U Height: 2U

Wattage/VA: 345W

Voltage: 110-120V

Tripp Lite BC Pro BCPRO600 120V 600VA 345W Standby UPS Tower Battery Backup - Brand New

Tripp Lite BC Pro BCPRO600 120V / 120 Volt 600VA / 600 Volt-Amps 345W / 345 Watts Standby UPS / Uninterruptible Power Supply Tower Battery Backup with 6 USB Ports (3 UPS Battery Backup Outlets and 3 Additional Surge-Only Outlets) - Brand New

BC Pro 120V 600VA 345W Standby UPS, Tower, USB port, 6 Outlets

  • 600VA tower 120V standby UPS
  • Maintains AC output during power failures
  • 3 UPS battery supported outlets, 3 surge-only outlets
  • USB port, TEL/DSL/ethernet protection, 97% efficient
  • NEMA 5-15P input plug and 6 NEMA 5-15R outlets
  • 2-year limited warranty
  • $200,000 Ultimate Lifetime Insurance

Overview
Tripp Lite's BCPRO600 standby UPS offers complete power protection for desktop PCs, network workstations and a wide variety of consumer and professional electronics. Uninterruptible Power Supply / UPS circuits switch to battery backup mode within milliseconds to keep connected equipment running without interruption or data loss during power failures. Surge-only outlets offer convenient protection for printers and other desktop accessories not requiring battery support. AC and dataline surge suppression prevents connected equipment damage. USB communications port supports built-in power management and auto-shutdown features of Windows and Mac OS X or full featured monitoring and data-saving auto-shutdown options using Tripp Lite's free PowerAlert monitoring software.

Features

  • BCPRO600 tower 120V standby UPS offers AC power protection from blackouts, brownouts, overvoltages and transient surges
  • 600VA / 345 watt UPS output capacity
  • Uninterruptible Power Supply / UPS operation maintains battery-derived AC output during blackouts, brownouts and overvoltages to prevent data loss and system downtime for connected equipment
  • Built-in USB port enables data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download from PowerAlert Platform
  • HID-compliant USB port also enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
  • 5.7 minutes runtime at 100% load (345 watts), 14.5 minutes runtime at 50% load (175 watts)
  • 42 minutes runtime for a desktop computer system consuming 80 watts continuous
  • 6 built-in total NEMA 5-15R outlets
  • 3 UPS battery backup outlets, plus 3 additional surge-only outlets
  • Right angle NEMA 5-15P input connection with 6ft / 1.8m line cord
  • Network grade AC surge and lightning protection is available from all outlets; Built-in data line surge suppression protects a single dialup, DSL or ethernet line
  • 97% line mode efficiency rating uses less energy and BTU emissions
  • Supports Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application/OS or hard power off/on reboot of connected equipment, ideal for unattended kiosk applications
  • Front panel LEDs indicate line / battery mode and battery replace status; Audible alarm with alarm cancel / self-test button
  • Hot swappable user battery replacement
  • Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment
  • Small tower housing supports desk or floor placement

Package Includes

  • BCPRO600 Standby UPS System
  • USB cable
  • Phone cable
  • Instruction manual

TRIPP LITE UPS BATTERY BACKUP
Model NumberBCPRO600
OVERVIEW
UPS TypeStandby
OUTPUT
Output Volt Amp Capacity (VA)600
Output Watt Capacity (Watts)345
Nominal Voltage Details115v nominal output in battery mode
Frequency Compatibility60 Hz
Output Voltage Regulation (Battery Mode)+/-5%)
UPS Output Receptacles (Surge Suppression Only)3 UPS outlets, 3 surge-only outlets
Hot-Swap PDU optionsPDUB15 (2U / 8 5-15R outlets)
Output AC Waveform (AC Mode)Sine wave
Output AC Waveform (Battery Mode)PWM sine wave
Nominal Output Voltage(s) Supported
  • 110V
  • 115V
  • 120V
  • Output Receptacles(6) 5-15R
    Individually Controllable Load Banks

    Select UPS models have their receptacles divided into one or more load banks (labeled LOAD 1, ect.) which may be remotely switched OFF and ON using Tripp Lite UPS software without interrupting power to equipment connected to the other outlets
    No
    INPUT
    Rated input current (Maximum Load)12A
    Nominal Input Voltage(s) Supported120V AC
    UPS Input Connection Type
  • 5-15P
  • Right-Angled
  • UPS Input Cord Length (ft.)6
    Recommended Electrical Service15A 120V
    Input PhaseSingle-Phase
    BATTERY
    Full Load Runtime (min.)

    The amount of runtime th UPS will offer when you
    5.7 min. (345w)
    Half Load Runtime (min.)

    The amount of runtime th UPS will offer when you
    14.5 min. (175w)
    DC System Voltage (VDC)12
    Battery Recharge Rate (Included Batteries)Less than 4.5 hours from 10% to 90%
    Internal UPS Replacement Battery CartridgeRBC51
    Battery AccessBattery access door
    Battery Replacement DescriptionHot-swappable, user replaceable batteries
    Expandable RuntimeNo
    USER INTERFACE, ALERTS & CONTROLS
    Switches2 Switches control off/on power status and alarm-cancel/self-test operation
    Alarm Cancel Operation
  • Power-fail alarm can be silenced using alarm-cancel switch
  • once silenced, alarm will re-sound to indicate low-battery status
  • Audible AlarmAudible alarm indicates power failure and overload conditions
    LED Indicators3 LEDs indicate line power, battery power and battery low/replace status
    SURGE / NOISE SUPPRESSION
    UPS AC Suppression Joule Rating510
    UPS AC Suppression Response TimeInstantaneous
    UPS Dataline Suppression1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
    EMI / RFI AC Noise Suppression

    Technology found in select UPS systems that protects against EMI (electromagnetic interference) and RFI (radio frequency interference) line noise and protects equipment against associated incremental hardware damage, data corruption and audio/video transmission problems.
    Yes
    PHYSICAL
    Installation Form Factors Supported with Included AccessoriesTower
    Installation Form Factors Supported with Optional AccessoriesWallmount (UPSWM - tower mounting kit)
    Primary Form FactorTower
    Primary UPS Depth (mm)191
    Primary UPS Height (mm)274
    Primary UPS Width (mm)132
    Shipping Dimensions (hwd / in.)13.90 x 8.0 x 10.20
    Shipping Weight (lbs.)15.90
    UPS Housing MaterialPVC
    UPS Power Module Dimensions (hwd, in.)10.8 x 5.2 x 7.5
    UPS Power Module Weight (kg)6.89
    UPS Power Module Weight (lbs.)15.2
    ENVIRONMENTAL
    Operating Temperature Range+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius.
    Storage Temperature Range+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius.
    Relative HumidityUp to 90%, non-condensing
    AC Mode BTU / Hr. (Full Load)

    The amount of heat a UPS generates when operating under a full load on mains (AC) power. Measured in British Thermal Units (BTU).
    14
    AC Mode Efficiency Rating (100% Load)>97%
    COMMUNICATIONS
    Communications InterfaceUSB (HID enabled)
    PowerAlert SoftwareFor local monitoring via the UPS’s built-in USB communications port, download PowerAlert Local software at http://www.tripplite.com/poweralert
    Communications CableUSB interface cable included
    WatchDog CompatibilitySupports Watchdog application, OS and hard-reboot restart options for remote applications
    Network UPS Tools CompatibilityNUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
    LINE / BATTERY TRANSFER
    Transfer Time

    The time it takes for a UPS to switch from AC on-line mode to DC battery-powered mode. Measured in milliseconds (ms)
    2-4 milliseconds
    Low Voltage Transfer to Battery Power (Setpoint)99 (adjustable to 83 via back panel potentiometer)
    High Voltage Transfer to Battery Power (Setpoint)139
    SPECIAL FEATURES
    Cold Start (Startup in Battery Mode During a Power Failure)Cold-start operation supported
    High Availability UPS FeaturesHot swappable batteries
    Green Energy-Saving FeaturesGreater than 95% efficiency - GREEN UPS
    CERTIFICATIONS
    UPS Certifications
  • Tested to UL1778 (USA)
  • Tested to CSA (Canada)
  • Tested to NOM (Mexico)
  • Meets FCC Part 15 Category B (EMI)
  • WARRANTY
    Product Warranty Period (U.S. & Canada)2-year limited warranty
    Connected Equipment Insurance (U.S., Canada & Puerto Rico)$200,000 Ultimate Lifetime Insurance

    Click here to view the manufacturer's item description/brochure

    Weight: 16 lb

    Warranty: 2 Year Manufacturer

    Brand New

    Condition Levels Explained

    The product is brand new.

    2 Year Manufacturer Warranty

    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.
