Ubiquiti Networks NSM2 NanoStation M

Ubiquiti Networks NSM2 Indoor/Outdoor Wireless Bridge Image 1 image
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

  • 1 Year ManufacturerWarranty
    Product Warranties Explained

    The product has a manufacturer warranty for the time period specified.

$89.00

Interface Types:Ethernet RJ45
Electrical Interface:Ethernet Gigabit - 1Gbps
Bays/Ports/Slots:2
RAM:32MB
Voltage:24V

Description

Ubiquiti Networks NSM2 NanoStation M 2.4GHz Indoor/Outdoor Wireless Bridge - Brand New

Ubiquiti Networks NSM2 NanoStation M 2.4GHz Indoor/Outdoor Wireless Bridge - Brand New

Overview

Leading-Edge Industrial Design
Ubiquiti Networks™ set the bar for the world's first low-cost and efficient broadband Customer Premises Equipment (CPE) with the original NanoStation™. The NanoStationM and NanoStationlocoM take the same concept to the future with sleek and elegant form factors, along with integrated airMAX™ (MIMO TDMA protocol) technology.

The low cost, high performance, and small form factor of NanoStationM and NanoStationlocoM make them extremely versatile and economical to deploy.

Utilize airMAX Technology
Unlike standard Wi-Fi protocol, Ubiquiti’s Time Division Multiple Access (TDMA) airMAX protocol allows each client to send and receive data using pre-designated time slots scheduled by an intelligent AP controller.

This “time slot” method eliminates hidden node collisions and maximizes airtime efficiency. It provides many magnitudes of performance improvements in latency, throughput, and scalability compared to all other outdoor systems in its class.

Intelligent QoS Priority is given to voice/video for seamless streaming.

Scalability High capacity and scalability

Long DistanceCapable of high speed, carrier-class links.

Latency Multiple features dramatically reduce noise.

Dual Ethernet Connectivity
The NanoStationM provides a secondary Ethernet port with software-enabled PoE output for seamless IP video integration.

Intelligent PoE
Remote hardware reset circuitry of the NanoStationM allows the device to be remotely reset from the power supply location.

The NanoStationM may also be powered by the Ubiquiti Networks TOUGHSwitch PoE. In addition, any NanoStationM can easily become 48V, 802.3af compliant through use of the Ubiquiti Instant 802.3af Adapter (sold separately).

Specifications

SYSTEM INFORMATION
Model NumberNSM2
Processor SpecsAtheros MIPS 24KC
400 MHz
Memory32 MB SDRAM
8 MB Flash
Networking Interface(2) 10/100 Ethernet Port
REGULATORY/COMPLIANCE INFORMATION
Wireless ApprovalsFCC Part 15.247
IC R210
CE
RoHS ComplianceYes
PHYSICAL/ELECTRICAL/ENVIRONMENTAL
Dimensions (mm)294 x 31 x 80
Weight0.4 kg
Power Supply24V
0.5A
Max Power Consumption8 W
Gain11 dBi
RF Connector ------------
PolarizaionDual Linear
Enclosure Characteristics
MountingPole Mounting Kit Included
Power MethodPassive Power over Ethernet
(pairs 4,5+; 7,8 return)
Operating Temperature-30 to 75°C
Operating Humidity5 to 95% Condensing
Shock & VibrationETS1300-019-1.4
OPERATING FREQUENCY SUMMARY (MHz)
Worldwide2412 - 2462
USA2412 - 2462
USA DFS -----------
OUTPUT POWER
Power Specification2.4 GHz
ANTENNA INFORMATION
Gain10.4 - 11.2 dBi
Cross-pol Isolation23 dB Minimum
Max VSWR1.6:1
Beamwidth55° (H-pol)
53°(V-pol)
27°(Elevation)
Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 1 lb

Warranty: 1 Year Manufacturer

Condition

Brand New

Warranty

1 Year Manufacturer Warranty
