Ubiquiti Networks PBM365 PowerBridge M365 Bridge

Ubiquiti Networks Part #/MPN: PBM365

DiscTech Item #: UBI-PBM365-BN-1Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Interface Types: Ethernet RJ45

Electrical Interface: Ethernet Gigabit - 1Gbps

On-Board Cache: 64MB

Wattage/VA: 8W

Voltage: 24V

Ubiquiti Networks PBM365 PowerBridge M365 3.65GHz Bridge - Brand New

Ubiquiti Networks PBM365 PowerBridge M365 3.65GHz Bridge - Brand New

PowerBridge M airMAX Bridge
Featuring a panel antenna design and dual-polarity performance, the PowerBridge M is ideal for Point-to-Point (PtP) bridging applicaions that require a compact form factor

Designed to Perform The PowerBridge®is a slim-profile, high-performance panel antenna that provides a wind-loading advantage and improved aesthetics over dish deployment.

Plug and Play Installation The PowerBridge M features an all-in-one design for easy installation.

Advanced Software Technology Ubiquiti’s airMAX technology is proven in millions of depolyments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.

Model NumberPBM365
Processor SpecsAtheros MIPS 24Kc
400 MHz
Memory64 MB SDRAM
8 MB Flash
Networking Interface1 x 10/100 Base-TX (CAT. 5, RJ-45) Ethernet Interface
Wireless ApprovalsFCC Part 90Y
RoHS ComplianceYes
Enclosure Size445 x 416 x 34 mm
Weight3.82 kg
Enclosure CharacteristicsOutdoor UV Stabilized Plastic
Mounting KitPole-Mount Kit Included
Max Power Consumption8 W
Power Supply24V
1A surge protection integrated PoE adapter included
Power MethodPassive PoE (pairs 4,5+; 7,8 return)
Operating Temperature-30 to +80° C
Operating Humidity5 to 95% Condensing
Shock and VibrationETSI300-019-1.4
Frequency Range3.3 - 3.8 GHZ
Gain20 dBi
PolarizationDual Linear
Cross-pol Isolation28dB Minimum
Max VSWR1.5:1
HPOL Beamwidth13.5 deg
VPOL Beamwidth13.5 deg
Elevation Beamwidth13.5 deg

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 9 lb

Warranty: 1 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

1 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
