Ubiquiti Networks Part #/MPN: US-48-750W
DiscTech Item #: UBI-US-48-750W-BN-1Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Interface Types: Ethernet RJ45, SFP
Electrical Interface: Ethernet Gigabit - 1Gbps
Bays/Ports/Slots: 48
U Height: 1U
Wattage/VA: 750W
Voltage: 110-240V Multi
Ubiquiti Networks US-48-750W 750W 48 Gigabit RJ45 Port PoE w/SFP UniFi Rackmountable Ethernet Switch - Brand New
Ubiquiti Networks US-48-750W 750W 48 Gigabit RJ45 Port PoE w/SFP UniFi Rackmountable Ethernet Switch - Brand New
UniFi Switch
Build and expand your network with Ubiquiti Networks® UniFi® Switch, part of the UniFi line of products. The UniFi Switch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks.
Switching Performance
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss
Poe+ Flexibility
The UniFi Switch models are available with 24 or 48 PoE Gigabit Ethernet ports of auto-sensing IEEE 802.3af/at or configurable 24V passive PoE to simplify your infrastructure
By default, the UniFi Switch automatically detects 802.3af/at devices so they automatically receive PoE. For 48V passive PoE devices, manually enable 24V passive PoE using the UniFi Controller software.
Fiber Connectivity
The UniFi Switch provides fiber connectivity options for easy expansion of your networks. Each UniFi Switch model includes two SFP ports for uplinks of up to 1 Gbps.
Each 48-port model adds two SFP+ ports for high-capacity uplinks of up to 10 Gbps, so you can directly connect to a high-performance storage server or deploy a long-distance uplink to another switch.
UniFi Switch 48 (750W Model) Model: US-48-750W
- (48) Gigabit RJ45 ports
- (2) SFP+ ports
- (2) SFP ports
- (1) Serial console port (reserved for future use)
- Non-blocking throughput: 70 Gbps
- Switching capacity: 140 Gbps
- Forwarding rate: 104.16 Mpps
- Maximum power consumption: 750W
- Supports POE+ IEEE 802.3at/af and 24V Passive PoE
- Rackmountable
| MODEL OVERVIEW | |
|---|---|
| Model Name | US-48-750W |
| Dimensions | 485.04 x 44.45 x 347.6 mm (191.1 x 1.75 x 13.69 in) |
| Weight | 5.3 kg (11.68 lb) |
| Total Non-Blcking Throughput | 70 Gbps |
| Switching Capacity | 140 Gbps |
| Forward Rate | 104.16 Mpps |
| Max. Power Consumption | 750W |
| Power Method | 100-240VAC/50-60 Hz, Universal Input |
| Power Supply | AC/DC, Internal, 750W DC |
| LEDs Per Port - Serial Console Port - RJ45 Data Ports - SFP+/SFP Data Ports | |
| Networking Interfaces | (48) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1/10 Gbps SFP+ Ethernet Ports (2) 1 Gbps SFP Ethernet Ports |
| Management Interface | (1) RJ45 Serial Port (Reserved for Future Use), Ethernet In/Out Band |
| Certifications | CE, FCC, IC |
| Rackmount | Yes, 1U High |
| ESD/EMP Protection | Air: ±24 kV, Contact: ±24 kV |
| Operating Temperature | -5 to 40° C (23 to 104°F) |
| Operating Humidity | 5 to 95% Non-Condensing |
| Shock and Vibration | ETSI300-019-1.4 Standard |
Click here to view the manufacturer's item description/brochure
Weight: 12 lb
Warranty: 1 Year Manufacturer
Brand New
The product is brand new.
1 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
