Western Digital Caviar RE3 WD3202ABYS SATA Hard Drives
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- In Stock:2Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 320GB |
| Speed: | 7.2K RPM |
| Interface Types: | SATA |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SATA 300 - 3Gbps |
| RAM: | 16MB |
Description
Western Digital Caviar RE3 WD3202ABYS 320GB 7.2K 3.5" Enterprise SATA Hard Drive - Refurbished
Compatibility Summary
WD RE3 drives combine up to 32 MB cache with SATA 3 Gb/s transfer rate for lightning-fast performance in demanding server and storage applications. Technologically advanced acoustics minimize noise. Cool drive operation and enhanced reliability features help protect the drive and the data stored on it.
| Massive capacity - WD RE3 Enterprise SATA drives are available in capacities up to 1 TB. Dual processor - Twice the processing power results in a 20% performance improvement over the previous generation. StableTrac™ - The motor shaft is secured at both ends to reduce system-induced vibration and stabilize platters for accurate tracking during read and write operations. RAFF™ - Our fourth generation RAFF technology includes sophisticated electronics to monitor the drive and correct both linear and rotational vibration in real time for up to a 60% performance improvement in high vibration environments over the previous generation of drives. IntelliSeek™ - Calculates optimum seek speeds to lower power consumption, noise, and vibration. Multi-axis shock sensor - Automatically detects the subtlest shock events and compensates to protect the data. RAID-specific, time-limited error recovery (TLER) - Prevents drive fallout caused by the extended hard drive error-recovery processes common to desktop drives. Third generation dynamic fly height - Each read-write head’s fly height is adjusted in real time for optimum reliability. Thermal extended burn-in test - Each drive is put through extended burn-in testing with thermal cycling to ensure reliable operation. NoTouch™ ramp load technology - The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit. Perpendicular Magnetic Recording (PMR) - WD RE3 drives utilize PMR technology to achieve even greater areal density, reliability, and design margin. |
| Ideal For Ideal for servers, storage arrays, video surveillance, and other demanding write-intensive applications. |
Capacity: 320GB
Compatibility
This drive is compatible with any of our 3.5" SATA drive trays and any computer / server that uses SATA drives.
Specifications
| Specifications | |
|---|---|
| Model number | WD5002ABYS |
| Model Name | RE3 |
| Formatted Capacity | 500 Gbytes |
| Rotational Speed | 7,200 rpm |
| Default Buffer (cache) Size | 16 Mbytes |
| Performance | |
| External (I/O) Transfer Rate (max) | 300 MBytes/sec |
| Average Latency | 4.2 msec |
| Physical | |
| Form Factor(width) | 3.5-inch |
| Form Factor(height) | 1-inch |
| Height | 25.4 mm |
| Width | 101.6 mm |
| Length | 146.05 mm |
| Weight | 0.69 kg |
| Electrical | |
| Power 12VDC (Rd/Wr; Idle; Standby; Sleep) | 490 mA; 470 mA; 5mA; 5mA |
| Power 5VDC (Rd/Wr; Idle; Standby; Sleep) | 500 mA; 420 mA; 160mA; 160mA |
| Environmental | |
| Max Operating Shock (2-msec) | 65 Gs |
| Max Nonoperating Shock (2-msec) | 250 Gs |
| Operating Vibration (max) | .75 Gs |
| Nonoperating Vibration (max) | 4.0 Gs |
| Operating Temperature (max) | 60 deg C |
| Operating Temperature (min) | 0 deg C |
| Nonoperating Temperature (max) | 70 deg C |
| Nonoperating Temperature (min) | -40 deg C |
| Acoustical | |
| Acoustics, Idle (sound power, typ) | 28 dBA |
| MTBF (Hours) | 1,200,000 hours |
| Nonrecoverable Read Errors | 1 per 10^16 bits read |
| Supports S.M.A.R.T. | Yes |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Refurbished
Warranty
1 Year DiscTech Warranty
