Western Digital Part #/MPN: WD1000FYPS
DiscTech Item #: WDC-WD1000FYPS-FR-6M
- Factory Refurbished
- Warranty:6 Month DiscTech
- Special Order - Ships in 5-10 business days
Enterprise Grade
Capacity: 1TB
Speed: 5.4K RPM
Interface Types: SATA
Form Factor: 3.5" LFF Hard Drive
Sector Size: 512 / 512e
Average Seek Time: 8.9ms
Electrical Interface: SATA 300 - 3Gbps
On-Board Cache: 16MB
Western Digital RE2-GreenPower WD1000FYPS 1000GB / 1TB 5.4K Enterprise SATA 3.0Gb/s 3.5" Hard Drive - Factory Refurbished
As demand for storage continues to expand, the need for more efficient power solutions becomes paramount. WD RE2-GreenPower makes it possible for large scale data centers to increase storage capacity without exceeding available power, and in many cases actually reduce power consumption. WD RE2-GreenPower drives help combat the four major challenges large data installations face—total drive slots, maximum capacity, power allotment, and available operations expense budget—while lowering the overall total cost of ownership.
Key Features:
Reduced power consumption - The combination of WD's IntelliSeek, IntelliPark, and IntelliPower technologies bring optimized performance at industry leading low power consumption; power is reduced as much as 40%.
Helps enable eco-friendly servers - Each WD RE2-GreenPower drive consumes an average of 4-5 watts less than competitor drives making it possible for energy-conscious customers to build servers with higher capacities, ensured reliability, and promote energy conservation.
Lower total cost of ownership - Large data-hungry organizations such as financial institutions and web service providers may realize up to $10 savings per drive per year in electricity costs (U.S). A large data center with 10,000 drives could realize up to $100,000 in saving per year.
IntelliPower - A fine-tuned balance of spin speed, transfer rate, and caching algorithms designed to deliver both significant power savings and solid performance. Additionally, GreenPower drives consume less current during start up allowing more drives to spin up simultaneously resulting in faster system readiness.
RAID-specific time-limited error recovery (TLER) - Pioneered by WD, this feature prevents drive fallout caused by the extended hard drive error-recovery processes common to desktop drives.
Ideal For
Large data centers, web service providers, commercial grade surveillance systems and organizations requiring huge amounts of storage with limited budget and power allotment.
Compatibility:
This drive is compatible with any computer/server that accepts 3.5" SATA hard drives.
Performance Specifications | ||
Rotational Speed | IntelliPower * | |
Buffer Size | 16 MB | |
*x A fine-tuned balance of spin speed, transfer rate, and caching algorithms designed to deliver both significant power savings and solid performance. Additionally, GreenPower drives consume less current during start up allowing more drives to spin up simultaneously resulting in faster system readiness. | ||
Seek Times | ||
Read Seek Time | 8.9 ms | |
Transfer Rates | ||
Buffer To Host (Serial ATA) | 3 Gb/s (Max) | |
Physical Specifications | ||
Formatted Capacity | 1,000,204 MB | |
Capacity | 1 TB | |
Interface | SATA 3 Gb/s | |
User Sectors Per Drive | 1,953,525,168 | |
Physical Dimensions | ||
English | ||
Height | 1.028 Inches | |
Depth | 5.787 Inches | |
Width | 4.00 Inches | |
Weight | 1.61 Pounds | |
Metric | ||
Height | 26.1 mm | |
Depth | 147 mm | |
Width | 101.6 mm | |
Weight | 0.73 kg | |
Environmental Specifications | ||
Shock | ||
Operating Shock (Read) | 65G, 2 ms | |
Non-operating Shock | 250G, 2 ms | |
Acoustics | ||
Idle Mode | 24 dBA (average) | |
Seek Mode 0 | 29 dBA (average) | |
Seek Mode 3 | 25 dBA (average) | |
Vibration | ||
Operating | ||
Linear | 20-300 Hz, 0.75 G (0 to peak) | |
Random | 0.004 g²/Hz (10 to 300 Hz) | |
Electrical Specifications | ||
Current Requirements | ||
12 VDC | ||
Read/Write | 340 mA | |
Idle | 254 mA | |
Standby | 6 mA | |
Sleep | 6 mA | |
5 VDC | ||
Read/Write | 675 mA | |
Idle | 195 mA | |
Standby | 180 mA | |
Sleep | 180 mA | |
Power Dissipation | ||
Read/Write | 7.40 Watts | |
Idle | 4.00 Watts | |
Standby | 0.97 Watts | |
Sleep | 0.97 Watts |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 6 Month DiscTech
Factory Refurbished
6 Month DiscTech Warranty
