Western Digital RED WD60EFZX 6TB 128MB Cache 3.5" NAS SATA 6 Gb/s
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 6TB |
| Speed: | 5.4K RPM |
| Interface Types: | SATA |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SATA 600 - 6Gbps |
| RAM: | 128MB |
Description
Western Digital RED WD60EFZX 6TB 128MB Cache 3.5" NAS SATA 6 Gb/s - Brand New
WD Red is designed specifically for small NAS systems that have 1 to 8 drive bays. The drives are designed and extensively tested for compatibility in the unique 24x7 operating environment and for the demanding system requirements of home and small office NAS.
Storage for 1 to 8 bay NAS solutions - WD Red is designed specifically for NAS systems that have 1 to 8 drive bays in both 3.5-inch and 2.5-inch form factors. The drives are designed and extensively tested for compatibility in the unique 24x7 operating environment and for the demanding system requirements of home and small office NAS.
NASware grows to 3.0 - WD Red now supports small NAS systems from 1 to 8 bays thanks to NASware 3.0, which further improves drive compatibility and reliability. At 48 TB of total capacity in an 8 bay system, WD Red expands your NAS experience.
B3D Active Balance Plus - Our enhanced dual-plane balance control technology significantly improves the overall drive performance and reliability. Hard drives that are not properly balanced may cause excessive vibration and noise in a multi-drive system, reduce the hard drive life span, and degrade the performance over time. (EFRX models only)
Innovative design
WD drives are innovatively designed and manufactured with lead-free, conflict-free and halogen-free materials.
IntelliSeek
Calculates optimum seek speeds to lower power consumption, noise and vibration.
NoTouch Ramp Load technology
The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit.
Package includes a hard drive only - no screws, cables, manuals included. Please purchase mounting hardware and cables separately if necessary.
Model: WD60EFZX
Compatibility:
This hard drive is compatible with: Windows 7/Vista/XP/2000, Windows Server, Linux, and Mac OS.
Specifications
| Product Specifications | ||
| Interface | SATA 6 Gb/s | |
| Performance Specifications | ||
| Rotational Speed | IntelliPower | |
| Buffer Size | 128 MB | |
| Load/unload Cycles | 600,000 minimum | |
| Transfer Rates | ||
| Buffer To Host (Serial ATA) | 6 Gb/s (Max) | |
| Physical Specifications | ||
| Capacity | 6 TB | |
| User Sectors Per Drive | ||
| Physical Dimensions | ||
| English | ||
| Height | 1.028 Inches | |
| Depth | 5.787 Inches | |
| Width | 4.00 Inches | |
| Weight | 1.66 Pounds | |
| Metric | ||
| Height | 26.1 mm | |
| Depth | 147 mm | |
| Width | 101.6 mm | |
| Weight | 0.75 kg | |
| Environmental Specifications | ||
| Shock | ||
| Operating Shock (Read) | 30G, 2 ms | |
| Non-operating Shock | 300G, 2 ms | |
| Power Management | ||
| Read (Peak Watts) | ||
| Write (Peak Watts) | ||
| Acoustics | ||
| Idle Mode | 31 dBA (average) | |
| Seek Mode 0 | 34 dBA (average) | |
| Temperature (English) | ||
| Operating | 41° F to 131° F | |
| Non-operating | -40° F to 158° F | |
| Temperature (Metric) | ||
| Operating | 5° C to 55° C | |
| Non-operating | -40° C to 70° C | |
| Electrical Specifications | ||
| Current Requirements | ||
| Power Dissipation | ||
| Read/Write | 10.40 Watts | |
| Idle | 8.60 Watts | |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
