Western Digital Part #/MPN: SDASB8Y-256G
DiscTech Item #: WDC-SDASB8Y-256G-C9-OE
- Certified 95Condition Levels Explained
These products can not qualify as new, however, we have tested and evaluated their health, performance and usage statistics and determined that they have at least 95% of their designed service life remaining. e.g. in SSDs they are guaranteed to have at least 95% endurance remaining.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:10Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Capacity: 256GB
Speed: Solid State Memory
Interface Types: SATA
Form Factor: 2.5inx7mm Fits All laptops
Sector Size: 512 / 512e
Electrical Interface: SATA 600 - 6.0Gbps
SSD Type: TLC
SSD Endurance DWPD: Consumer / Value
Western Digital SA530 SDASB8Y-256G 256GB 2.5 TLC 3D NAND SATA SSD - Certified 95
Western Digital SA530 SDASB8Y-256G 256GB 2.5 TLC 3D NAND SATA SSD - Certified 95
Western Digital® PC SA530 3D NAND SATA SSD
Exceptional Storage Options for a Broad Range of Computing Applications
High Performance and High Capacity for Computing Based on Western Digital 96-layer 3D NAND, the Western Digital PC SA530 3D NAND SATA SSD delivers high performance, high capacity, and superior endurance. In capacities of up to 1TB, the Western Digital PC SA530 achieves this while expending less power than our previous generations of SATA SSDs.
The Western Digital PC SA530 combines Western Digital’s state-of-the-art 96-layer 3D NAND technology with our proven SSD platform. It also incorporates nCache™ 2.0, a tiered caching technology designed to improve responsiveness for corporate and consumer workloads. nCache 2.0 uses a combination of both SLC (single level cell) and TLC flash blocks to improve endurance, increase efficiency, and boost performance. Writing data first to the SLC cache reduces write amplification on the TLC blocks.
With on-the-fly hardware-based encryption, the Western Digital PC SA530 (SED models only) provides complete end-to-end encryption to the storage, system and infrastructure. It supports password protection, AES-256-bit encryption, TCG-OPAL 2.01 standard and PSID.
Lower Power, Higher Capacity and Thin Form Factors Offers Design Flexibility
The Western Digital PC SA530 is optimized for the demanding power management requirements of ultra-thin and small form factor products.
It features Device Sleep (DEVSLP), more frequent use of low-power modes, and faster transitions between various power modes. Also included for superior error recovery, DataGuard™ Client provides a robust on-the-fly error handling technology.
With a variety of design and integration options for manufacturers and systems builders, the Western Digital PC SA530 is available in either an SATA 2.5”/7mm cased or an M.2 2280 form factor, with capacities of 256 gigabytes (GB), 512GB, and 1 terabyte (TB).
Compatibility:
This drive is compatible with any server that accepts 7mm SATA SSDs
| Western Digital SA530 SATA SSD | ||
|---|---|---|
| Model: | SDASB8Y-256G | |
| SPECIFICATIONS & PERFORMANCE | ||
| POWER | ||
| RELIABILITY | ||
| ENVIRONMENTAL | ||
| PHYSICAL | ||
| Capacity | 256 GB | |
| Interface | SATA | |
| PCMark | 180K | |
| Sequential Read MB/s (Q=32, T=1) | 550 | |
| Sequential Write MB/s (Q=32, T=1) | 525 | |
| Random Read 4 KB IOPS (Q=32, T=4) | 95k | |
| Random Write 4 KB IOPS (Q=32, T=4) | 81k | |
| Endurance | 100 | |
| Average Active Power(mW) | 52 | |
| Supply Voltage | 3.3 V ± 5% | |
| Peak Power | 2.5 A (10 us) | |
| Low Power Mode PS3 (mW) | 50 | |
| Low Power Mode PS4 (mW) | 5.5 | |
| MTTF | Up to 1.75M hours | |
| Operating Temperatures | 32 °F to 158 °F (0 °C to 70 °C) | |
| Non-operating Temperatures | -67 °F to 185 °F (-55 °C to 85 °C) | |
| Operating Vibrations | 5.0 gRMS, 10–2000 Hz, 3 axes | |
| Non-operating Vibrations | 4.9 gRMS, 7–800 Hz, 3 axes | |
| Operating/Non-Operating Shock | 1,500 G @ 0.5 ms half sine | |
| Certifications | FCC, UL, TUV, KC, BSMI, VCCI | |
| Dimensions | 22 ± 0.15 mm x 80 ± 0.15 mm x 2.23 mm | |
| Weight | 7.2 ± 0.5 g | |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Certified 95
These products can not qualify as new, however, we have tested and evaluated their health, performance and usage statistics and determined that they have at least 95% of their designed service life remaining. e.g. in SSDs they are guaranteed to have at least 95% endurance remaining.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
