Western Digital Part #/MPN: WD1004FBYZ
DiscTech Item #: WDC-WD1004FBYZ-NP-OE-DEL
- New PullCondition Levels Explained
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Capacity: 1TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 184
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
Western Digital WD Re WD1004FBYZ 1TB 6Gbps 7.2K LFF SATA Hard Drive 1F0DG - New Pull OEM
WD Re™
Datacenter Capacity HDD
Performance-optimized high-capacity storage for high-intensity applications
Advanced drive technology that delivers consistent high performance in a multitude of applications, and with up to ten times the workload capability of desktop drives, the WD Re drive is the workhorse of WD’s datacenter portfolio. The WD Re drive is perfect for high-availability storage arrays that demand a robust storage device, and this drive’s high performance, capacity, and reliability make it ideal for data warehousing/mining and high-performance computing. The WD Re uses a SATA interface to provide maximum flexibility and compatibility.
DPN: 1F0DG / 01F0DG
Compatibility:
This drive is compatible with servers that accept 3.5"x1" (LFF) SATA drives.
| Specifications | |
|---|---|
| 512 native model number | WD1004FBYZ |
| Interface | SATA 6 Gb/s |
| Formatted capacity | 1TB |
| 512n/512e user sectors per drive | 1,953,525,168 |
| Native command queuing | Yes |
| Form factor | 3.5-inch |
| RoHS compliant | Yes |
| Performance | |
| Data transfer rate (max) - Buffer to host - Host to/from drive (sustained) | - 6 Gb/s - 184 MB/s |
| Cache (MB) | 128 |
| Rotational speed (RPM) | 7200 |
| Reliability/Data Integrity | |
| Load/unload cycles | 600,000 |
| Non-recoverable read errors per bits read | <1 in 10^15 |
| MTBF (hours) | 2,000,000 |
| AFR (%) | 0.44 |
| Power Management | |
| Average power requirements (W) - Sequential read - Sequential write - Random read/write - Idle | - 7.4 - 7.4 - 8.1 - 5.9 |
| Environmental Specifications | |
| Temperature (°C) - Operating - Non-Operating | - 5 to 60 - -40 to 70 |
| Shock (Gs) - Operating (2 ms, read/write) - Operating (2 ms, read) - Non-Operating (2 ms) | - 30 - 65 - 300 |
| Acoustics (dBA) - Idle - Seek (average) | - 25 - 28 |
| Physical Dimensions | |
| Height (in./mm, max) | 1.028/26.1 |
| Length (in./mm, max) | 5.787/147 |
| Width (in./mm, ± .01 in.) | 4/101.6 |
| Weight (lb/kg, ± 10%) | 1.41/0.64 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1F0DG 01F0DG
Weight: 1.8 lb
Warranty: 1 Year DiscTech
New Pull
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
