Western Digital Part #/MPN: WD3000HLFS
DiscTech Item #: WDC-WD3000HLFS-RF-OE-DEG
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:4Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 300GB
Speed: 10,000RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 126
Average Seek Time: 4.2/4.7
Electrical Interface: SATA 300 - 3.0Gbps
On-Board Cache: 16MB
Western Digital WD3000HLFS / C580H / N965M 300GB 3.5in 3Gbps 10K RPM VelociRaptor SATA Enterprise HDD - Refurbished OEM
Western Digital WD3000HLFS / C580H / N965M 300GB 3.5" 3.0 Gbps 10000 RPM VelociRaptor Serial Advanced Technology Attachment Enterprise Hard Disk Drive - Refurbished OEM
Alt MPN: C580H, 0C580H, N965M, 0N965M
Compatibility:
This drive is compatible with any server that accepts 3.5"x1.0" (LFF Hard Drive) SATA Drives.
| Model Number | WD3000HLFS |
|---|---|
| Alt Model |
|
| Formatted Capacity | 300 GB |
| Formatted Capacity | 300,069 MB |
| User Sectors Per Drive | 586,072,368 |
| Bytes Per Sector | 512 |
| Data Transfer Rate (maximum) -Buffer to Host | 3.0 Gb/s max |
| Average Read Seek | 4.2 ms (average) |
| Track-to-track Seek | 0.7 ms (average) |
| Full Stroke Seek | 8.5 ms (average) |
| Average Latency | 5.5 ms (nominal) |
| Rotational Speed | 10,000 RPM |
| Buffer | 16 MB |
| Error Rate (non-recoverable) | 1 in 10e15 bits read |
| Contact Start/Stop Cycles (CSS) | 50,000 minimum |
| Height (in/mm, max) | 1.028/25.4 |
| Length (in/mm, max) | 5.787/147.0 |
| Width (in/mm, ± .01 in) | 4.00/101.6 |
| Weight (lb/g, ± 10%) | 1.08/489 |
| Spinup 12 V (± 10%) 5 V (± 5%) Power | 1.25 A 900 mA 19.5 W |
| Read/Write 12 V (± 10%) 5 V (± 5%) Power | 225 mA 675 mA 6.08 W |
| Idle 12 V (± 10%) 5 V (± 5%) Power | 200 mA 425 mA 4.53 W |
| Standby 12 V (± 10%) 5 V (± 5%) Power | 6 mA 70 mA 0.42 W |
| Sleep 12 V (± 10%) 5 V (± 5%) Power | 6 mA 70 mA 0.42 W |
| SHOCK | |
| Operating | 65 G(read) |
| Non-operating | 300 G |
| VIBRATION | |
| Operating Random> Linear | 10-300 Hz, 0.008g2/Hz (300 to 500 Hz) 10-300 Hz, 3.0G (0 to peak) |
| Non-operating Low Frequency High Frequency | 5-20 Hz, 0.195 inches (double amplitude) 10-300 Hz, 5.0G (0 to peak) |
| OPERATING TEMPERATURE AND HUMIDITY | |
| Temperature | 5°C to 60°C (41°F to 140°F) |
| Humidity | 5-95% RH non-condensing |
| Thermal Gradient | 20°C/hour (maximum) |
| Humidity Gradient | 20% hour (maximum) |
| NON-OPERATING TEMPERATURE AND HUMIDITY | |
| Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 5-95% RH non-condensing |
| Thermal Gradient | 30°C/hour (maximum) |
| ACOUSTICS (AVERAGE) | |
| Idle Mode | 29 dBA (Average) |
| Seek Mode | 36 dBA (Average) |
| RELIABILITY | |
| MTBF | 1,4000,000 Hours |
- 12V/77.5A
- 3.3VSB/6.0A
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: C580H 0C580H N965M 0N965M
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
