Western Digital WD500AZLX 500GB SATA Hard Drive

Western Digital Part #/MPN: WD5000AZLX

DiscTech Item #: WDC-WD5000AZLX-BN-2Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Capacity: 500GB

Speed: 7,200RPM

Interface Types: SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 150

Electrical Interface: SATA 600 - 6.0Gbps

On-Board Cache: 32MB

Western Digital WD Blue WD5000AZLX 500GB 3.5in 6Gbps 7.2K SATA HDD - Brand New

Western Digital WD Blue WD5000AZLX 500GB 3.5" 6.0 Gb/s 7200 RPM Serial Attached Technology Attachment Hard Disk Drive - Brand New

WD Blue™ PC Hard Drives

High Capacity, Proven Reliability
WD expands their award-winning desktop and mobile storage lineup with WD Blue PC hard drives. Extensively tested and built to WD’s high standards, WD Blue offers a wide variety of capacities - ranging from 250 GB to the massive 6 TB – in both desktop and mobile models. Drive WD Blue with confidence – our colors never fade.

Storage Capacity Up to 6TB
Boost your PC storage with WD Blue drives, the brand designed specifically for desktop and all-in-one PCs. The WD Blue family now delivers data storage capacities up to 6 TB.

Improve PC Performance
Pair a larger capacity drive with an SSD to give your desktop a performance and storage boost. The SSD maximizes speed of data access, while the WD Blue drive stores up to 6 TB of movies, games, files, applications and more.

Upgrade and Backup with Ease
WD hard drives come with free access to WD Acronis True Image. Backup and restore functions make it easy to save and retrieve your personal data without the need to reinstall the OS.

Trust in WD
Customers around the world know that WD’s reliability is legendary. Every WD Blue drive is designed, tested and built to last.

Future-Proof Your Storage
With better technology comes bigger storage needs. Cameras that record ultra-high definition video at 4K resolution at 30 frames per second require a ton of storage. Handling all that media is a snap with our 6 TB drive.

NoTouch Ramp Load Technology
Safely positions the recording head off the disk surface to protect your data.

Calculates optimum seek speeds to lower power consumption, noise and vibration.


  • WD Blue storage is tested and recommended for use in desktop and All-in-One PCs, notebooks, and external enclosures.
  • Desktop / Consumer RAID Environments - WD Blue PC Hard Drives are tested and recommended for use in consumer-type RAID applications (RAID 0 and RAID 1).*

* Business Critical RAID Environments – WD Blue PC Hard Drives are not recommended for and are not warranted for use in RAID environments utilizing Enterprise HBAs and/or expanders and in multi-bay chassis, as they are not designed for, nor tested in, these specific types of RAID applications. For all Business Critical RAID applications, please consider WD’s Enterprise Hard Drives that are specifically designed with RAID-specific, time-limited error recovery (TLER), are tested extensively in 24x7 RAID applications, and include features like enhanced RAFF technology and thermal extended burn-in testing.

The WD Advantage
WD puts our products through extensive Functional Integrity Testing (F.I.T.) prior to any product launch. This testing ensures our products consistently meet the highest quality and reliability standards of the WD brand. WD also has a detailed Knowledge Base with more than 1,000 helpful articles as well as helpful software and utilities.


This drive is compatible with any server that accepts 3.5inx1.0in SATA Drive.

WD Blue™ PC Hard Drives
Model NumberWD5000AZLX
InterfaceSATA 6 Gb/s
Advanced Format (AF)Yes/s
Form Factor3.5-Inch
RoHS CompliantYes
Data Transfer Rate Max
Buffer to Host6 Gb/s
Host to/from Drive (sustained)150 MB/s
Cache (MB)32
Rotational speed (RPM)7200 RPM Class
Reliability/Data Integrity
Load/Unload Cycles300,000
Non-recoverable Read Errors Per Bits Read<1 in 10^14
Power Management
12VDC ±10% (A, peak)2
Average Power Requirements (W)
Environmental Specifications
Temperature (°C)
Operating0 to 60
Non-operating-40 to 70
Shock (Gs)
Operating (2 ms, read/write)30
Operating(2 ms, read) 65
Non-operating (2 ms)350
Acoustics (dBA)
Seek (average)30
Physical Dimensions
Height (in/mm)1.028/25.4
Length (in/mm)5.787/147
Width (in/mm, ± .01 in)4/101.6
Weight(lb/kg, ± 10%)0.99/0.45

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Weight: 1.8 lb

Warranty: 2 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

2 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
