Western Digital WD7502ABYS Caviar RE3 SATA Hard Drive
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 750GB |
| Speed: | 7.2K RPM |
| Interface Types: | SATA |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SATA 300 - 3Gbps |
| RAM: | 32MB |
Description
Western Digital WD7502ABYS Caviar RE3 750GB 7.2K Enterprise SATA Hard Drive OEM 0G631F G631F WD7502ABYS-18A6B0 MY-0G631F-12555-94O-0199-A00 - Brand New
WD RE 7200 RPM hard drives are engineered to thrive in a high duty cycle RAID system while still offering traditional low cost-per-capacity desktop value. Designed and manufactured to server-class standards, WD RE drives provide RAID-specific, time-limited error recovery (TLER) to significantly reduce drive fallout caused by extended drive error-recovery processes and are tested to 1 million hours MTBF.
0G631F G631F WD7502ABYS-18A6B0 MY-0G631F-12555-94O-0199-A00
Specifications
| Specifications | |
|---|---|
| Model number | WD7502ABYS |
| Model Name | RE3 |
| Formatted Capacity | 750 Gbytes |
| Rotational Speed | 7,200 rpm |
| Default Buffer (cache) Size | 32 Mbytes |
| Performance | |
| External (I/O) Transfer Rate (max) | 300 MBytes/sec |
| Average Seek Time, Read | 8.9 msec typical |
| Average Seek Time, Write | 9.6 msec typical |
| Average Latency | 4.2 msec |
| Physical | |
| Form Factor(width) | 3.5-inch |
| Form Factor(height) | 1-inch |
| Height | 1.028 inch |
| Width | 4.0 inch |
| Length | 5.787 inch |
| Weight | 1.52 pounds |
| Electrical | |
| Power (Typical) | 8.4 watts |
| Power (Idle) | 7.8 watts |
| Environmental | |
| Max Operating Shock (2-msec) | 65 Gs |
| Max Nonoperating Shock (2-msec) | 250 Gs |
| Operating Vibration (max) | .75 Gs |
| Nonoperating Vibration (max) | 4.0 Gs |
| Operating Temperature (max) | 60 deg C |
| Operating Temperature (min) | 0 deg C |
| Nonoperating Temperature (max) | 70 deg C |
| Nonoperating Temperature (min) | -40 deg C |
| Acoustical | |
| Acoustics, Idle (sound power, typ) | 33 dBA |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: 0G631F G631F WD7502ABYS-18A6B0 MY-0G631F-12555-94O-0199-A00
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
